Argo All 8X8 Service Manual
  1. Manuals
  2. Brands
  3. Argo Manuals
  4. Offroad Vehicle
  5. All 8X8
  6. Service manual

Argo All 8X8 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
2022
All 8X8 MODELS
All 6X6 MODELS
Manual No. TBD
Printed in Canada
2022/01/01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the All 8X8 and is the answer not in the manual?

Questions and answers

FERN DANIS
May 19, 2025

HOW TO REMOVE RADIATOR ON 2007 ARGO AVENGER KOHLER 26 HP

0
Dale Statson
February 18, 2025

What is the 2nd red caution light for on the dash of my Conquest 8x8 Argo?

0

Related Manuals for Argo All 8X8

Summary of Contents for Argo All 8X8

  • Page 1 SERVICE MANUAL 2022 All 8X8 MODELS All 6X6 MODELS Manual No. TBD Printed in Canada 2022/01/01...
  • Page 3 Argo Service Manual How to use this manual This manual is divided into general sections which are identified by a 2 Service Guide letter designation. Find the section you want in the guide on this General Information....GI page, and then turn to the Table of Contents on page 1 of that section.
  • Page 4 Argo Service Manual Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 5 ARGO MODEL SPECIFICATIONS......................GI-5 IDENTIFICATION AND LOCATION OF CONTROLS (AURORA............GI-10 IDENTIFICATION AND LOCATION OF CONTROLAS (FRONTIER)..........GI-11 INFORMATION LABELS (8X8)........................GI-12 INFORMATION LABELS (6X6)........................GI-13 ARGO TORQUE SPECIFICA TIONS......................GI-14 MAINTENANCE CHARTS..........................GI-18 SPECIAL TOOLS.............................GI-20 Ontario Drive & Gear Limited www.argoutv.com GI-1 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 6 All information contained in this service manual is based on the product specification records of Ontario Drive & Gear Ltd. If the ARGO that you are servicing differs from the specifications contained in this manual, contact Ontario Drive & Gear for information.
  • Page 7 GI INDEX MAIN INDEX NOTE Read your owner/operators manual before you operate your ARGO. It contains safe operating instructions and warns the user about potential hazards that can result in personal injury. Warnings are identified in the text by the following symbol:...
  • Page 8 Service Manual for Models from 2002 - 2017 A MESSAGE FROM THE PEOPLE WHO BUILD THE ARGO Ontario Drive & Gear Limited has been building ARGO vehicles since 1967. By listening carefully to our customers and responding to their needs, we have been constantly improving the ARGO and will continue to do so.
  • Page 9 Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission Fuel Capacity 27 L (7.1 U.S Gal.) Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes Drive Chains Double RC 50 & Single RC 60 Roller chain Electrical 12 volt D.C.
  • Page 10 Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission Fuel Capacity 27 L (7.1 U.S Gal.) Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes Drive Chains Double RC 50 & Single RC 60 Roller chain Electrical 12 volt D.C.
  • Page 11 Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission Fuel Capacity 27 L (7.1 U.S Gal.) Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes Drive Chains Double RC 50 & Single RC 60 Roller chain Electrical 12 volt D.C.
  • Page 12 Belt -driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission Fuel Capacity 27L (7.1 U.S. Gal.) Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes Drive Chains Single RC60 Roller Chain Electrical 12 volt D.C. AGM battery 385 cold cranking amps at 0 F; 20A charging system...
  • Page 13 Belt -driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission Fuel Capacity 27L (7.1 U.S. Gal.) Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes Drive Chains Double RC50 & Single RC60 Roller Chain Electrical 12 volt D.C.
  • Page 14 General Information Argo Service Manual GI INDEX MAIN INDEX IDENTIFICATION AND LOCATION OF CONTROLS - AURORA Ontario Drive & Gear Limited www.argoutv.com GI-10 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 15 General Information Argo Service Manual GI INDEX MAIN INDEX IDENTIFICATION AND LOCATION OF CONTROLS - FRONTIER Figure 1 - Frontier 700 EFI Figure 2 - Frontier 600 & 650 Briggs Carburated Ontario Drive & Gear Limited www.argoutv.com GI-11 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 16 Information about the use of the holding brake system, the use of the vehicle in water, correct fuelling procedures and placement of the floorpans has been provided on distinctive coloured labels fastened to the various locations on the Argo. Figure 1-1 Location of Information Labels - All Models Ontario Drive &...
  • Page 17 Information about the use of the holding brake system, the use of the vehicle in water, correct fuelling procedures and placement of the floorpans has been provided on distinctive coloured labels fastened to the various locations on the ARGO. Ontario Drive & Gear Limited www.argoutv.com GI-13 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 18 The following tables show "Standard" Torque Values for both imperial and metric fasteners. If there are any "Non-Standard" torque values specific to ARGO vehicle components, they will be called out during the service procedure in the related service section of this manual.
  • Page 19 General Information Argo Service Manual GI INDEX MAIN INDEX TORQUE SPECIFICATIONS Standard Torque Value for Imperial Fasteners THREAD SIZE - COARSE THREAD SIZE - FINE FASTENER TYPE/GRADE CONDITION Lubricated Grade 5 Anti-Seize, Threadlocker, 108 190 SAE J429 or Plain Steel...
  • Page 20 General Information GI INDEX MAIN INDEX Argo Service Manual TORQUE SPECIFICATIONS Standard Torque Value for Metric Fasteners THREAD SIZE - COARSE THREAD SIZE - FINE FASTENER TYPE/GRADE CONDITION Lubricated 121 167 236 Anti-Seize, Threadlocker, Grade 8.8 137 189 267 or Plain Steel...
  • Page 21 General Information Argo Service Manual GI INDEX MAIN INDEX TORQUE SPECIFICATIONS Standard Torque Value for Metric Fasteners THREAD SIZE - COARSE THREAD SIZE - FINE FASTENER TYPE/GRADE CONDITION Lubricated 125 177 Anti-Seize, Threadlocker, Grade 8.8 103 142 200 or Plain Steel...
  • Page 22 The intervals shown on the schedule are based on average operating conditions. Vehicles which are subjected to severe use and wet or dusty conditions will require more frequent servicing. Use only ARGO replacement parts to ensure safe operation of the vehicle and to comply with the warranty coverage.
  • Page 23 The intervals shown on the schedule are based on average operating conditions. Vehicles which are subjected to severe use and wet or dusty conditions will require more frequent servicing. Use only ARGO replacement parts to ensure safe operation of the vehicle and to comply with the warranty coverage.
  • Page 24 General Information Argo Service Manual GI INDEX MAIN INDEX SPECIALIZED TOOLS 11. 19628 Briggs Diagnostic Software and Inter- 1. 608-54 Bearing Removal Tool face Cable 2. 658-05 Needle Bearing Remover/Installer 12. 19624 Briggs Big Block Fuel Pressure 3. 658-06 Output Shaft Puller Test Adapter 4.
  • Page 25 General Information Argo Service Manual GI INDEX MAIN INDEX Ontario Drive & Gear Limited www.argoutv.com GI-21 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 26 General Information Argo Service Manual GI INDEX MAIN INDEX Ontario Drive & Gear Limited www.argoutv.com GI-22 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 27 General Information Argo Service Manual GI INDEX MAIN INDEX Extension Spacer Required for Invance Driven Clutch Disassembly/Reassembly. Used in conjuntion with 5055-0002 Clutch Tool. Make according to dimensions. Ontario Drive & Gear Limited www.argoutv.com GI-23 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 28 General Information Argo Service Manual GI INDEX MAIN INDEX HDi ADMIRAL Transmission Specialized Tools Specialized tools are now available for aiding in the disassembly and assembly of the ADMIRAL trans- mission. TOOL, PLANET CARRIER PIN PRESS TOOL, INPUT SHAFT PRESS...

  • Page 29: Table Of Contents

    SECTION EN Engine System Table of Contents GENERAL INSTRUCTIONS ............................EN-2 CURRENT ARGO ENGINES ............................EN-3 CHECKING THE ENGINE OIL LEVEL ........................EN-4 RECOMMENDED ENGINE OIL (KAWASAKI 800) ....................EN-5 RECOMMENDED ENGINE OIL (BRIGGS & STRATTON 850/950) ................. EN-6 RECOMMENDED ENGINE OIL (BRIGGS & STRATTON 600/650/700) ..............EN-6 CHANGING THE ENGINE OIL ............................

  • Page 30: General Instructions

    Detailed information on standard workshop and safety procedures, and general ser- vicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ARGO assumes no responsibility or liability for PER- SONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.
  • Page 31 MAIN INDEX Engine System EN INDEX Argo Service Manual CURRENT ENGINES USED IN VEHICLE PRODUCTION IMPORTANT For detailed servicing repairs, diagnostics and troubleshooting of these engines, please refer to the manufacturer’s full service guide. Briggs 700 EFI Briggs 650 Briggs 600...

  • Page 32: Checking The Engine Oil Level

    MAIN INDEX Engine System EN INDEX Argo Service Manual Checking The Engine Oil Level To check the oil during an operating period, shut the engine off, let it cool down and allow the oil time to drain into the sump before checking the oil level. Position the vehicle so the engine is level.
  • Page 33 MAIN INDEX Engine System EN INDEX Argo Service Manual Recommended Engine Oil Kawasaki 800 O. Throttle Body A. Dipstick P. Radiator Cap B. Dipstick Filler Tube Q. Radiator C. Oil Filler Cap R. Coolant Drain Plug D. Oil Drain Plug S.

  • Page 34: Recommended Engine Oil (Kawasaki 800

    MAIN INDEX Engine System EN INDEX Argo Service Manual Briggs & Stratton Big Block EFI 850/950 - Oil Type/Capacity Briggs: 2.3 L (2.4 qts.) A - Engine ID B - Spark Plug C - Air Cleaner D - Dipstick E - Oil Fill...

  • Page 35: Draining The Engine Oil

    Remove the oil from the engine by inserting a vacuum tube through the dipstick hole and using a vacuum pump such as the 638-02 TOPSIDER MVP VACUUM PUMP available through ARGO Oil Filter Replacement Change the oil filter every 100 hours during oil change.

  • Page 36: Air Filter (Kawasaki 800

    MAIN INDEX Engine System EN INDEX Argo Service Manual Air Filter (Kawasaki 800) The Kawasaki FD851D engine is equipped with a heavy duty high density paper air cleaner element surrounding a canister style inner element. Cleaning is not recommended, each element should be replaced when dirty.

  • Page 37: Air Filter (Briggs 850/950

    MAIN INDEX Engine System EN INDEX Argo Service Manual Air Filter (Briggs Big Block 850/950) Briggs Big Block EFI engines are equipped with a foam pre-cleaner and dry paper air filter element housed in an air cleaner assembly attached to the throttle body.

  • Page 38: Spark Plugs

    MAIN INDEX Engine System EN INDEX Argo Service Manual Spark Plugs - Briggs 491055S (850/950) Spark Plugs - Briggs 496018S (600/650/700 EFI) Spark Plugs - Kawasaki 92070-7004 (800) Spark Plug Torques: Kawaski 800 - 18.5 ft·lb (25 Nm) Briggs 850/950 - 180 lb-in (20 Nm) Briggs 600/650/700 - 180 in.
  • Page 39 MAIN INDEX Engine System EN INDEX Argo Service Manual IMPORTANT Refer to the diagram for detailed information on the engine mounting hardware. Removing The Kawasaki 800 Engine From The Vehicle 1. Disconnect the battery positive (+) and negative (-) cables from the battery.

  • Page 40: Lifting The Engine From The Vehicle (Kawasaki 800

    Engine System EN INDEX Argo Service Manual 12. There are only four (4) bolts & lock washers securing the engine to the main frame front & rear. Take note of which holes in the engine mounting frame are used for installation later.
  • Page 41 MAIN INDEX Engine System EN INDEX Argo Service Manual 13. Attach the overhead hoist to the engine. There are lift hooks provided on each engine. 14. Slowly and gently raise the engine through the hood area with the overhead hoist.
  • Page 42 MAIN INDEX Engine System EN INDEX Argo Service Manual 6. Reconnect fuel vent from fitting on engine. 7. Reconnect the intake hose from the air filter cannister. 8. Reconnect the throttle cable at the engine cable retainer. 9. Reconnect the ground cable at the engine.
  • Page 43 MAIN INDEX Engine System EN INDEX Argo Service Manual 1. Disconnect the battery positive (+) and negative (-) cables from the battery. 2. Remove the heat deflector shield covering the muffler . 3. Locate the tailpipe assembly and detach the connecting springs between the tailpipe assembly and muffler.

  • Page 44: Lifting The Engine From The Vehicle (Briggs 850/950

    MAIN INDEX Engine System EN INDEX Argo Service Manual Lifting The Engine From The Vehicle CAUTION This procedure requires the use of an overhead hoist. Do NOT attempt to lift out by hand. Ensure all components attached to the engine have been detached. This may include any accessories that may be installed to the vehicle.
  • Page 45 MAIN INDEX Engine System EN INDEX Argo Service Manual 2. Slowly and gently lower the engine through the hood area. Some maneuvering is re- quired as the engine does not necessarily drop straight in. Avoid damage to any vehicle components as well as the upper body.

  • Page 46: Removing The Briggs 650/700 Efi

    MAIN INDEX Engine System EN INDEX Argo Service Manual Refer to the diagram for detailed information on the engine mounting hardware. Removing The Briggs 650/700 Efi Briggs Engine From The Vehicle. 1. Disconnect the battery positive (+) and negative (-) cables from the battery.

  • Page 47: Lifting The Engine From The Vehicle (Briggs 650/700 Efi

    MAIN INDEX Engine System EN INDEX Argo Service Manual 13. Remove all four (4) mounting bolts using a 9/16" socket and ratchet. Lifting The Engine From The Vehicle CAUTION This procedure requires the use of an overhead hoist. Do NOT attempt to lift out by hand.
  • Page 48 MAIN INDEX Engine System EN INDEX Argo Service Manual 13. Attach the overhead hoist to the engine. There are lift hooks provided on each engine. 14. Slowly and gently raise the engine through the hood area with the overhead hoist.
  • Page 49 MAIN INDEX Engine System EN INDEX Argo Service Manual 8. Reconnect the throttle cable at the engine cable retainer. 9. Reconnect the ground cable at the engine. 10. Reconnect the fuel line and return fuel line from the engine. 11. Locate the tailpipe assembly and reattach to the muffler with connecting springs.
  • Page 50 MAIN INDEX Engine System EN INDEX Argo Service Manual 5. Disconnect the ground cable at the engine. 6. Disconnect the throttle cable at the engine cable retainer. 7. Disconnect fuel vent from fitting on engine. 8. Disconnect engine connector plugs in the main wire harness located at the front of the engine.
  • Page 51 MAIN INDEX Engine System EN INDEX Argo Service Manual 12. Attach the overhead hoist to the engine. There are lift hooks provided on each engine. 13. Slowly and gently raise the engine through the hood area with the overhead hoist.
  • Page 52 MAIN INDEX Engine System EN INDEX Argo Service Manual 8. Reconnect the fuel line and return fuel line from the engine. 9. Reconnect the wiring to the starter motor 10. Locate the tailpipe assembly and reattach to the muffler with connecting springs.
  • Page 53 Electrical System Argo Service Manual ES INDEX MAIN INDEX SECTION ES Electrical System Table of Contents GENERAL INSTRUCTIONS.......................... ES-3 BATTERY................................. ES-4 CLEANING THE BATTERY TERMINALS AND CABLE CONNECTIONS ..........ES-7 ELECTRICAL SYSTEM FUSES ........................ES-7 FUSE PANEL RELAY AND FUSE LOCATIONS ..................ES-7 REMOVING THE BATTERY .........................
  • Page 54 Electrical System Argo Service Manual ES INDEX MAIN INDEX TACH EXTENSION WIRE HARNESS ....................... ES-35 FRONITER/AURORA GAUGE PLUG PIN MAP ..................ES-36 ES-2 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...

  • Page 55: General Instructions

    Detailed information on standard workshop and safety procedures, and general servicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ARGO assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.

  • Page 56: Battery

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Battery - AGM Battery - ARGO (Yuasa) The battery is located under the hood on the right hand side of the vehicle at the dash (intake side of vehicle) AGM batteries look different than other battery types. They are more compact because there is no free electrolyte making them more “volume efficient”...
  • Page 57 Electrical System Argo Service Manual ES INDEX MAIN INDEX The battery must be out of the vehicle and placed on a level surface. Remove electrolyte container from the plastic storage bag. Remove the strip of caps. Put the strip aside as you will use it later to seal the battery cells. For...
  • Page 58 Electrical System Argo Service Manual ES INDEX MAIN INDEX Remove the empty electrolyte container from the battery. Fully insert the strip of sealing caps (previously removed from the electrolyte container) into the battery filling ports. Make sure the strip of caps is fully inserted and flush with the top of the battery.

  • Page 59: Cleaning The Battery Terminals And Cable Connections

    NEGATIVE (-) post and the red POSITIVE (+) cables to the POSITIVE (+) posts. Damage to the electrical system will occur if the cables are reversed. Electrical System Fuses All models of the ARGO are equipped with push-in type automotive fuses. The fuses protect the electrical circuits of the vehicle.

  • Page 60: Battery Inspection

    Electrical System Argo Service Manual ES INDEX MAIN INDEX NOTE Keep the battery charged. Never allow the battery to become drained by unnecessary use of the headlights or over cranking of the engine. If the battery is dead or the electrical charge is low, re-charge it with a 12 volt battery charger.

  • Page 61: Removing The Headlamp Bulb

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Installing the Battery 1. Place the battery back into the battery compartment. Orient the battery so the Positive Terminal (+) is to the installer’s right. 2. Fasten the main power cable to the positive battery terminal first and cover with the red rubber insulator boot.

  • Page 62: Removing The Headlamp Lens Assembly - Aurora Models

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Clip the new bulb assembly into the wire harness. Reaching in through the engine access area, align the bulb assembly with the headlamp housing. Push in and turn 1/4 turn clockwise.

  • Page 63: Removing The Headlamp Lens Assembly - Frontier Models

    Electrical System Argo Service Manual ES INDEX MAIN INDEX 3. Pull the headlight lens assembly out through the hood area of the engine compartment and place on a clean work bench for disassembly. 4. Replace each lens as required. Installing The Headlight Lens Assembly 1.
  • Page 64 Electrical System Argo Service Manual ES INDEX MAIN INDEX 1. From the engine compartment side, disconnect the wiring from the head lamp. 2. Drill out and remove the three (3) rivets securing the headlight assembly to the front bucket. NOTE Exhaust side Light Bucket will require moving some exhaust duct shielding out of the way for access to head lamp assembly.

  • Page 65: Removing The Tail Light

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Removing The Tail Light 1. Drill out the rivets securing the rear tail light buckets to the upper body. 2. Pull the rear tail light bucket from the vehicle and unplug tail light wire connection.
  • Page 66 Electrical System Argo Service Manual ES INDEX MAIN INDEX Removing Starter Motor - Kawasaki 800 IMPORTANT This procedure will require the removal of the engine from the vehicle for best access to the starter motor mounting fasteners. It will also ensure proper alignment during installation and proper torque values for the starter motor bolts.
  • Page 67 Electrical System Argo Service Manual ES INDEX MAIN INDEX Removing Starter Motor - Briggs 600, 650 & 700 IMPORTANT This procedure will require the removal of the engine from the vehicle for best access to the starter motor mounting fasteners. It will also ensure proper alignment during installation and proper torque values for the starter motor bolts.
  • Page 68 Electrical System Argo Service Manual ES INDEX MAIN INDEX Removing Starter Motor - Briggs 850/950 IMPORTANT This procedure will require the removal of the engine from the vehicle for best access to the starter motor mounting fasteners. It will also ensure proper alignment during installation and proper torque values for the starter motor bolts.
  • Page 69 Electrical System Argo Service Manual ES INDEX MAIN INDEX Digital Gauge Packages - Aurora and Frontier Aurora Gauge Frontier Gauge ES-17 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...

  • Page 70: Calibrating The Digital Gauge Package - Aurora

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Calibrating the Digital Gauge Package Aurora Digital Gauge Package 1. With key switch off, hold both “Select” and “Adjust” buttons down simultaneously. 2. Turn the key to the run position until you see the letter “adj” and then release both but- tons.
  • Page 71 Electrical System Argo Service Manual ES INDEX MAIN INDEX 8. Set to 11.2V for low voltage warning. Push Select button 9. Set to T-1 for temperature reading Aurora 800 models only. 10. Set to "Off" for temperature reading for all models except Aurora 800 Models. Push Select button.

  • Page 72: Calibrating The Digital Gauge Package - Frontier

    Electrical System Argo Service Manual ES INDEX MAIN INDEX 12. Set clock. Push Select button 13. Set display brightness between 5-1 to 5-5. Push Select button. 14. Exit the setup by turning the key off. Calibrating the Digital Gauge Package Frontier Digital Gauge Package 1.
  • Page 73 Electrical System Argo Service Manual ES INDEX MAIN INDEX 6. Set the fuel system to "On" and push the Select button. 7. Set the low voltage charge warning to 11.2V. Push the Select button. 8. Set the time on the clock. Push the Select button.

  • Page 74: Replacing The Alternator V-Belt - 800 Kawasaki Model

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Replacing The Alternator V-Belt - 800 Kawasaki Models Only 1. Remove the vehicle firewall. See Removing The Firewall Panel in the Vehicle Body section of this service guide. 2. Locate the alternator on the right side of the engine beneath the radiator.
  • Page 75 Electrical System Argo Service Manual ES INDEX MAIN INDEX 108-76 WASHER 112-101 HHCS 108-67 LOCKWASHER 112-22 HHCS 6. Disconnect the wiring from the alternator. 7. Using a 17mm Socket, locate and remove the two bolts securing the alternator to the powerpack frame.

  • Page 76: Dash Panel Switches And Gauge

    Electrical System Argo Service Manual ES INDEX MAIN INDEX 2. Reinstall the V-Belt over both pulleys and tighten the adjustment bolt by turning it clockwise. Do not overtighten the belt or allow it to be too loose. The V-belt should be tightened enough that it deflects no more then 1/8"...
  • Page 77 Electrical System Argo Service Manual ES INDEX MAIN INDEX Speedometer Sensor The speedometer sensor is located on the right hand side of the vehicle at the mid sprocket on 6x6 models and the front sprocket on 8x8 models. This sensor picks up the signal from a 15 tooth wheel speed sensor disc attached to the axle.

  • Page 78: Wiring Schematic (Models 800, 850, 950

    Electrical System Argo Service Manual ES INDEX MAIN INDEX Wiring Schematics:600-0054 (Models 800/850/950) Print To 11x17 Paper Wiring Schematics:600-0054 (Models 800/850/950) Print To 11x17 Paper ES-26 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 79 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-241 Harness Adapter for 800 Kawasaki - Print To 11x17 Paper ES-27 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 80 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0054 Wire Harness Connectors and Colour Codes - Print To 11x17 Paper ES-28 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 81 Electrical System Argo Service Manual ES INDEX MAIN INDEX Wiring Schematics:600-0246 (Models 650/700) Print To 11x17 Paper ES-29 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 82 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0246 Wire Harness Connectors and Colour Codes - Print To 11x17 Paper PART NUMBER 600-0246 DESCRIPTION: HARNESS, MAIN ES-30 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 83 Electrical System Argo Service Manual ES INDEX MAIN INDEX Wiring Schematics:600-0191 (Model 600's) Print To 11x17 Paper ES-31 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 84 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0191 Wire Harness Connectors and Colour Codes - Print To 11x17 Paper ES-32 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 85 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0008 EU Wire Harness Schematic (600 EU Models) - Print To 11x17 Paper ES-33 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 86 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0008 EU Wire Harness Connectors and Colour Codes - Print To 11x17 Paper ES-34 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 87 Electrical System Argo Service Manual ES INDEX MAIN INDEX 600-0327 Tach Extension Wire Harness - Required For 600's SN 19801-19983 ES-35 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 88 Electrical System Argo Service Manual ES INDEX MAIN INDEX Frontier Gauge Plug Pin Map Aurora Gauge Plug Pin Map ES-36 Ontario Drive & Gear Limited www.argoutv.com PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 89 Brake System Argo Service Manual BR INDEX MAIN INDEX SECTION BR Brake System Table of Contents GENERAL INSTRUCTIONS...........................BR-3 CHECKING THE HYDRAULIC BRAKE FLUID LEVEL (STEERING BRAKES ) ........BR-4 HYDRAULIC BRAKE PAD INSPECTION (STEERING BRAKES) ..............BR-5 REPLACING THE STEERING BRAKE PADS ....................BR-6 BRAKE PAD INSPECTION PROCEDURE - (SERVICE BRAKE PADS) AURORA ........BR-6...
  • Page 90 Brake System Argo Service Manual BR INDEX MAIN INDEX INSTALLING THE STEERING BRAKE DISC (AURORA MODELS) ............. BR-21 REMOVING THE SERVICE BRAKE DISC (AURORA MODELS ONLY) ............. BR-22 INSTALLING THE SERVICE BRAKE DISC (AURORA MODELS) ..............BR-23 REMOVING THE STEERING BRAKE DISC (FRONTIER MODELS auto idler chain tensioner....BR-23 INSTALLING THE STEERING BRAKE DISC (FRONTIER MODELS auto idler chain tensioner ....

  • Page 91: General Instructions

    Detailed information on standard workshop and safety procedures, and general ser- vicing operations is not included in this manual, which has been prepared to as- sist qualified service personnel. ARGO assumes no responsibility or liability for PERSONAL INJURY or VEHICLE DAMAGE which results from any servicing procedure performed, including those instructions outlined in this manual.

  • Page 92: Checking The Hydraulic Brake Fluid Level (Steering Brakes

    Fluid Level/Condition. NOTE The intervals shown in the Argo Maintenance Schedule Chart (found in the General In- formation section of this service manual) are based on average operating conditions. Vehicles which are subject to more severe use, wet or dusty conditions, will require more frequent servicing.

  • Page 93: Hydraulic Brake Pad Inspection (Steering Brakes

    Argo Service Manual BR INDEX MAIN INDEX If the brake fluid is below this level: 2. Add only fresh clean Argo Brand Brake Fluid - DOT 4 (Argo Part No.130-108) to the correct level. 3. Replace the cover on each master cyl- inder, making sure the rubber gaskets are properly seated before tightening.

  • Page 94: Replacing The Steering Brake Pads

    Brake System Argo Service Manual BR INDEX MAIN INDEX Replacing The Steering Brake Pads Brake pads are easily replaced by removing the single bolt securing them within the brake calliper assembly and pulling each pad up and out of the calliper.

  • Page 95: Service Brake Bedding In Procedure

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Rotate the caliper up and past the ROPS mounting bracket to access and remove the hex head bolts securing the pads in the caliper. 4. Slip out the brake pads from the caliper.

  • Page 96: Checking Hydraulic Brake Fluid Level (Handle Bar Master Cylinder

    10kph, then release the brake and accelerate back to 20kph. Do not bring the Argo to a full stop (unless required for safety reasons). Bringing the ARGO to a full stop when the brakes are hot may cause the brake pad to imprint itself on the rotor.

  • Page 97: Brake Fluid Inspection

    Inspecting The Brake Fluid Condition (Steering Brake Master Cylinders) Maintenance Schedule- Inspect every 50 hours of vehicle operation. Use only Dot 4 brake fluid. Other brake fluids may not be compatible with ARGO brake components and operating temperatures. 1. Locate the master cylinders in the engine compartment.

  • Page 98: Changing The Brake Fluid (Steering Brakes

    Brake System Argo Service Manual BR INDEX MAIN INDEX Inspect the condition of the brake fluid and replace if: the fluid appears cloudy  the fluid appears discoloured  the fluid contains particles of dirt, rust, water, or other contaminants ...

  • Page 99: Bleeding The Hydraulic Brake System (Service Brakes) Aurora

    Brake System Argo Service Manual BR INDEX MAIN INDEX 2. Locate the bleed screw on the hydraulic service brake caliper. Attach a transpar- ent hose to the bleed screw and run to a container to collect the used fluid for disposal later.

  • Page 100: Hydraulic Brake Calipers Maintenance Schedule

    Maintenance Schedule - Inspect every 50 hrs. of vehicle operation CAUTION The brakes must be inspected regularly by a qualified authorized Argo dealer/Tech- nician. Damaged or leaking calipers can seriously impair the ARGO steering/brak- ing capability. Severe personal injury or property damage could result from a dam- aged or poorly adjusted brake system.

  • Page 101: Removing The Hydraulic Brake Caliper - Aurora Steering Brakes

    Brake System Argo Service Manual BR INDEX MAIN INDEX Removing The Hydraulic Brake Caliper - Aurora Steering Brakes 1. Perform the servicing procedure, Removing The Firewall WARNING Use the appropriate PPE when working with hydraulic brake fluid. Do not allow brake fluid to contact your eyes, skin or clothes.
  • Page 102 5. Replenish the master cylinder to the full level mark and secure the cover and rubber gasket. 6. Clean any stray brake fluid that might have found its way on to the brake disc with brake cleaner. Brake fluid on the brake disc can seriously affect braking capabilities of the ARGO vehicle.

  • Page 103: Installing The Hydraulic Brake Caliper - Service Brakes (Aurora

    Brake System Argo Service Manual BR INDEX MAIN INDEX Installing The Hydraulic Brake Caliper - Service Brakes (Aurora) 1. Attach the brake line to the new caliper and torque to 20-22 FT LBS. (27.12 Nm),orienting the hose in the same direction as previously installed.

  • Page 104: Installing The Hydraulic Steering Brake Caliper - Frontier Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Remove the two (2) SHCS,M8x1.25x65 Gr12.9 Znm, two (2) Lockwasher 5/16 Split- Ring Bnz and two (2) Washer .34x.70x.06 Zn bolts securing the steering calipers to the transmission housing. 4. Remove the Steering Brake Caliper using a 6mm hex head socket wrench.

  • Page 105: Hydraulic Brake Hose Maintenance Schedule

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. While holding the small nut on the plunger piston, thread the larger nut out to lengthen the plunger pin, or in to shorten it. 4. Ensuring that the steering bar is parallel with the dash of the vehicle, adjust the plung- er pin until it comes close to contacting the steering arm.

  • Page 106: Removing The Rmci Assembly (Aurora & Eu 600 Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX 1. Remove cover and gasket seal from the master cylinder reservoir. 2. Disconnect the hose from the caliper. Place a catch tray under the free end of the hydraulic hose and allow the hose and master cylinder reservoir to drain.

  • Page 107: Installing The Rmci Assembly (Aurora & Eu 600 Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX Installing The RMCI Assembly (Aurora & EU 600 Models) 1. Install the replacement RMCI Assembly and torque nuts to 76 in.lbs.(8.58 Nm). 2. Reconnect the brake line installing two (2) new copper washers. Torque to 20-22 FT LBS.

  • Page 108: Installing The Rmci Assembly (Frontier Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX Installing The RMCI Assembly (Frontier Models) 1. Install the replacement RMCI Assembly and torque nuts to 76 in.lbs.(8.58 Nm) 2. Reconnect the brake lines installing two (2) new copper washers at each fitting.

  • Page 109: Installing The Steering Brake Disc (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX NOTE If removing the LEFT side brake disc you will need to remove both Drive Belt and Driven Clutch to successfully work on and remove the brake disc. Brake lines do NOT have to be disconnected from the brake calipers.

  • Page 110: Removing The Service Brake Disc (Aurora Models Only

    Brake System Argo Service Manual BR INDEX MAIN INDEX 1. Perform the servicing procedure, Installing The Hydraulic Brake Caliper - Service Brakes (Aurora) 2. Perform the servicing procedure, Installing The Hydraulic Brake Caliper - Steering Brakes 3. Perform the servicing procedure, Installing The Driven Clutch (if the left side brake disc was serviced) 4.

  • Page 111: Installing The Service Brake Disc (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX Installing The Service Brake Disc (Aurora Models) 1. Slip the replacement Service Brake Disc back to the output shaft and sandwich be- tween the two couplers. 2. Align the holes in the Service Brake Disc with that of the couplers and reinstall the Bolt, Shoulder M10x45 securing with the Lockwasher 5/16 Split-Ring Bnz and Locknut, Nylon M8x1,25mm Zn8.

  • Page 112: Installing The Steering Brake Disc

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Remove the Parking Brake Caliper from the caliper bracket using a 1/2" socket and a 1/2" open end wrench. 4. Perform the servicing procedure, Remov- ing The Idler Chain (Frontier Models - Auto Idler Chain Adjust).
  • Page 113 Brake System Argo Service Manual BR INDEX MAIN INDEX 2. Apply anti-seize compound to the out put shaft spline. 3. Align the splines of the brake disc with those of the output shaft and slide the brake disc on to seat up against the shoulder of the shaft.

  • Page 114: Removing The Steering Brake Disc

    Brake System Argo Service Manual BR INDEX MAIN INDEX 11. Reinstall the firewall and secure with five (5) HHCS 5/16-18x1.25 GR5 Zinc and five (5) Washer .34x.70x.06 ZINC. Removing The Steering Brake Disc (Frontier Models - Manual Idler Chain Adjust).

  • Page 115: Installing The Steering Brake Disc

    Brake System Argo Service Manual BR INDEX MAIN INDEX L i d e 7. Remove the Steering Brake Disc. 8. Perform the servicing procedure, Brake Disc Inspection. Installing The Steering Brake Disc (Frontier Models - Manual Idler Chain Adjust). 1. Before installing the Steering Brake Disc, inspect the splines of the output shaft for any damage.

  • Page 116: Adjusting The Emergency/Parking Brake (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX 7. Perform the servicing procedure, Installing The Idler Chain (Frontier Models - Manual Idler Chain Adjust). 8. Perform the servicing procedure, Installing The Steering Brake Caliper. 9. Perform servicing procedure, Installing The Parking Brake Caliper.

  • Page 117: Adjusting The Emergency/Parking Brake (Frontier Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX Parking Brake System (Frontier Models) Adjusting the Emergency/Parking Brake 1. Remove the firewall. 2. Ensure the parking brake lever is fully 3. Locate the Parking Brake Adjustment Bracket near the bottom of the transmis- sion.

  • Page 118: Removing The Parking Brake Pads (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX Removing The Parking Brake Pads (Aurora Models) The Parking Brake Disc and Caliper is located on the right hand side of the transmission on Aurora Models. 1. Remove the hood from the vehicle.

  • Page 119: Removing The Parking Brake Pads (Frontier Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX 2. Reconnect the parking brake cable to the parking brake arm. 3. To seat the new pads and stretch the cable, apply the parking brake 5-6 times to full on and off.

  • Page 120: Removing The Parking Brake Disc/Caliper (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX MAIN INDEX 5. Locate the Live Side Brake Housing and turn upside down to remove 2nd brake pad from the housing cavity. Please note that there is also a washer placed beneath the brake pad.

  • Page 121: Installing The Parking Disc Brake/Caliper (Aurora Models

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Remove the retaining ring securing the Parking Brake Disc to the shaft. 4. Remove one (1) SHCS 5/16x1.25 ZINC, and one (1) SHCS 5/16-18x3.25 ZINC, securing the Parking Brake Caliper to the transmission housing.
  • Page 122 Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Apply some anti-seize compound to the splines of the Parking Brake Disc shaft. 4. Locate the Parking Brake Disc and insert it between the brake pads in the caliper be- fore installing it back to the shaft.

  • Page 123: Steering Bar Assembly

    Brake System Argo Service Manual BR INDEX MAIN INDEX Steering Bar Assembly 612-107 HANDLEBAR ASM 112-47 SHCS 117-29 LOCKNUT, NYLON 108-47 WASHER 105-16 BUSHING, OILITE 110-17 KEY 10311C SHAFT, STEERING 110-17 KEY 105-16 BUSHING, OILITE 10379C STEERING ARM 108-47 WASHER 103-17 HHCS Removing The Steering Shaft.

  • Page 124: Installing The Steering Shaft

    Brake System Argo Service Manual BR INDEX MAIN INDEX 3. Drop the shaft into the front compartment of the vehicle and remove to a clean work surface for further disassembly if required. IMPORTANT New oilite bushings installed to the steering column will require reaming for steering shaft fit.
  • Page 125 MAIN INDEX Clutch System Argo Service Manual SECTION CS Clutch System Table of Contents GENERAL INSTRUCTIONS..........................CS-2 AUTOMATIC TORQUE CONVERTER SYSTEM..................CS-2 MAINTENANCE INFORMATION ........................CS-3 DRIVE BELT MAINTENANCE SCHEDULE ....................CS-3 DRIVE BELT INSPECTION..........................CS-4 REMOVE THE DRIVE BELT (INVANCE) ..................... CS-4 INSTALL THE DRIVE BELT (CVTECH/INVANCE) ..................CS-5...

  • Page 126: General Instructions

    At top no load speed the belt should run near or to the top of the driver clutch. CAUTION Worn or dirty clutch components, or a worn drive belt will make the ARGO unreli- able and unsafe to operate. Ontario Drive & Gear Limited www.argoutv.com...

  • Page 127: Maintenance Information

    Clutch System Argo Service Manual Maintenance Information The maintenance information provided in this manual refers to an ARGO vehicle operating under normal conditions and use. Service more often when the vehicle is used under heavy duty applications. Servicing of the Automatic Torque Converter system is necessary when: A drop in vehicle performance occurs: •...

  • Page 128: Drive Belt Inspection

    CS INDEX MAIN INDEX Clutch System Argo Service Manual Drive Belt Inspection The drive belt transmits power from the driver clutch (on the engine) to the driven clutch (on the transmission). These components are located on the left side of the engine compartment.

  • Page 129: Invance Driven Clutch Drive Belt Adjustment

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 2. Locate the 6mm x 1.0 threaded hole in the clutch face. This hole is provided to assist in spreading the driven clutch sheaves by threading a 6mm x 1.0 thread bolt in through the face.

  • Page 130: Removing The Driven Clutch (Invance

    CS INDEX MAIN INDEX Clutch System Argo Service Manual IMPORTANT Loosen set screws uniformly 1/2 turn at a time. It is crucial that the clutch faces re- main true and parallel to each other around the entire circumference of the clutch.

  • Page 131: Clutch Maintenance

    CS INDEX MAIN INDEX Clutch System Argo Service Manual Clutch Maintenance Disassembly and repair of the driver and driven clutch requires special tools. The follow- ing indicates that clutch service might be required: • a drop in vehicle performance • the clutch does not shift smoothly •...

  • Page 132: Driver Clutch Removal (Cvtech

    CS INDEX MAIN INDEX Clutch System Argo Service Manual Driver Clutch Removal (CVTECH) 1. Remove the engine access cover. 2. Perform the servicing procedure, Removing the Firewall, 3. Perform the servicing procedure, Removing the Drive Belt. 4. Remove the fastener securing the Driver Clutch to the PTO and slide the clutch from the shaft.

  • Page 133: Reassembling The Driver Clutch (Cvtech

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 4. Remove the cap, spring and spring guide washer. Slip off the Sliding Flange. Re-assembling the Driver Clutch (CVTECH) 1. Slip on the Sliding Flange followed by the spring guide washer.

  • Page 134: Disassembling The Driven Clutch (Cvtech

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 4. Re-install the nylon block and weight assemblies into the sliding flange. Orient the block with the rounded side up. 5. Re-install the cap and secure with flat washer and nut. Torque to 100 FT. LBS.
  • Page 135 CS INDEX MAIN INDEX Clutch System Argo Service Manual 1. Place the Specialized Clutch Tool, 5055-0002, into an aluminum jawed vise. 2. Place nylon bushing into clutch shaft to centre clutch on the threaded rod. 3. Slip the nylon fork over the threaded rod and rest up against the steel washer on top of the spring.
  • Page 136 CS INDEX MAIN INDEX Clutch System Argo Service Manual 5. Remove nylon fork, steel washer and spring. 6. Be aware of the Plastic Spring Protector assembled to the top of spring. 7. Remove the moveable face. 8. Bushings are non-replaceable in moveable face.

  • Page 137: Assembling The Driven Clutch (Cvtech

    CS INDEX MAIN INDEX Clutch System Argo Service Manual Assembling The Driven Clutch (Invance) 1. Place the Fixed Face to the Specialized Clutch Tool, 5055-0002, shaft facing up. 2. Assemble Shim Washer over shaft of fixed face. 3. Slip the moveable sheave over the fixed shaft and let come to rest on the lower sheave.
  • Page 138 CS INDEX MAIN INDEX Clutch System Argo Service Manual 4. Place the nylon centering tool into the top of the fixed shaft. 5. Install clutch spring with plastic spring protector assembly to the top. 6. Place steel washer to top of plastic spring protector.

  • Page 139: Removing The Drive Belt (Itds Clutch System

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 9. Install retaining ring into ring groove of fixed pulley shaft. Instance Torque Drive System Clutches (ITDS)I NSTANCE TORQUE DRIVE SYSTEM & TIRES WARNING Do not attempt to adjust, repair or replace the drive belt, clutches or any moving part while the engine is running.

  • Page 140: Installing Drive Belt (Itds Clutch System

    CS INDEX MAIN INDEX Clutch System Argo Service Manual Installing The Drive Belt (ITDS Clutch System) CAUTION This procedure requires as specialized tool to spread the driven clutch sheaves. 1. Remove the bolt securing the driven clutch to the input shaft and insert it through a piece of flat bar stock (may or may not require some flat washers).

  • Page 141: Driver Clutch Disassembly (Itds Clutch System

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 3. Perform the servicing procedure, Removing the Drive Belt (ITDS Clutch System) 4. Remove the fastener securing the Driver Clutch to the PTO and slide the clutch from the shaft. NOTE The driver clutch must be slid from the PTO with the mounting bolt hardware within the clutch.
  • Page 142 8. Remove 500-0121 Plate Moveable-Drive to expose 500-0119-003 Roller, Drive weights. IMPORTANT All 600/650/700/850/950 ARGO models utilize 53g weights. 800 ARGO Models uti- lize 35g weights. This can be distinguished by the larger hole in the 800 model clutch rollers.

  • Page 143: Driver Clutch Reassembly (Itds Clutch System

    CS INDEX MAIN INDEX Clutch System Argo Service Manual 11. Locate 500-0115 Vespel Washer installed to the other side of the 500-0116 Cup, Spring Drive. 12. Slip 500-0114 Bearing, Drive-Idler from the fixed shaft. Driver Clutch Reassembly (ITDS) 1. Slip the 500-0114 Bearing, Drive-Idler on to the shaft of the fixed face. Orient the bearing with the spring clip facing down.
  • Page 144 CS INDEX MAIN INDEX Clutch System Argo Service Manual 3. Install the 500-0117-004 Spring, Drive to the fixed shaft. 4. Install the 500-0120 Sheave, Moveable Drive with rollers to the fixed shaft. 5. Place 500-0121 Plate, Moveable Drive to the top of the 500-120 Sheave Moveable Drive.
  • Page 145 CS INDEX MAIN INDEX Clutch System Argo Service Manual Driven Clutch (ITDS) Replacing The Nylon Rollers (ITDS Driven Clutch) 1. Locate the nylon 500-135 Roller, Driven and bend the 500-0136 Tab Lock, Driven- 10mm, away from the 500-0137 M10x1.25 bolt head.
  • Page 146 MAIN INDEX Wheels, Axles & Chains Argo Service Manual SECTION WA Wheels, Axles & Chains Table of Contents GENERAL INSTRUCTIONS..........................WA3 LUBRICATION INFORMATION ........................WA4 DRIVE CHAIN LUBRICATION .........................WA4 IDLER CHAIN (FRONTIER MODELS ONLY) ....................WA4 IDLER CHAIN ADJUSTMENT - SELF-ADJUST IDLER CHAIN (FRONTIER) ........WA4 IDLER CHAIN ADJUSTMENT - MANUAL ADJUST (FRONTIER) ............WA5...
  • Page 147 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual SECTION WA Wheels, Axles & Chains Table of Contents IDLER SHAFT INSPECTION - MAINTENANCE SCHEDULE (FRONTIER MODELS) ..... WA-18 REMOVING THE IDLER SHAFT (FRONTIER MODELS) ..............WA-19 INSTALLING THE IDLER SHAFT (FRONTIER MODELS) ..............WA-20 REMOVING THE IDLER SHAFT (AURORA MODELS) ................

  • Page 148: General Instructions

    Detailed information on standard workshop and safety procedures, and general ser- vicing operations is not included in this manual, which has been prepared to assist qualified service personnel. ARGO assumes no responsibility or liability for PER- SONAL INJURY or VEHICLE DAMAGE which results from any servicing proce- dure performed, including those instructions outlined in this manual.

  • Page 149: Lubrication Information

    Drive Chain Lubrication The ARGO vehicle is equipped with roller chains to each axle. Lubricate the chains every 10 hours or more frequently in dirty or wet conditions with an Aerosol Chain Lube (or use ARGO brand Chain Lube (part no. 130-100).

  • Page 150: Idler Chain Adjustment - Manual Adjust (Frontier)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual Idler Chain Adjustment - Manual Adjust (Frontier) A loose or improperly adjusted idler chain can result in damage to the chain or sprockets. During the new vehicle break-in period, check the idler chain adjustment before operating the vehicle and after the first 2 hours of operation.

  • Page 151: Installing The Idler Chain - Manual-Adjust(Frontier)

    7R Vice Grips to hold the ends of the chain together while inserting the connecting link. There may be no slack in the idler chain, making installation of the connecting link difficult without this tool. Modified Vice Grips can be ordered from your ARGO dealer (ARGO Part No. 658-08).

  • Page 152: Installing The Idler Chain-Self Adjust (Frontier)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 3. Remove the cotter pins from the connecting link. Remove the outside plate and tap out the connecting link. 4. Remove the idler chain from the vehicle. Installing The Idler Chain-Self Adjust (Frontier) 1.

  • Page 153: Outer Axle Flange & Bearing Lubrication

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual CAUTION Do not use regular oil or grease to lubricate the idler chains. Regular oil or grease will be thrown off the idler chains during normal operation, and contaminate the brake pads or discs.

  • Page 154: Inner Axle Bearing Lubrication

    Grease with a small amount of a lithium based, NLGI #2 or 3 mineral oil based grease, (such as Shell Alvania #3) or ARGO Brand Multi-Purpose Grease Part No. 130- 105) Apply every 50 hours of operation, if vehicle has been used in water for extended periods of time or whenever major maintenance is performed on the vehicle.

  • Page 155: Output Shaft Coupler Lubrication (Aurora Models Only)

    Lubricate every 25 hours with a lithi- um based, NLGI #2 or 3 mineral oil based grease, (such as Shell Alvania #3 or ARGO Brand Multi-Purpose Grease Part No. 130- 105). Wipe off excess.

  • Page 156: Installing A Drive Chain

    Use a pair of modified 7R Vice Grips to hold the ends of the chain together while inserting the connecting link. Some drive chains have no slack, and replacement of the connecting link is difficult without this tool. Modified Vice Grips can be ordered from ARGO, Part No. 658-08. 3. Replace the outside plate and spring clip.

  • Page 157: Drive Chain Take-Up System Inspection (Semi-Self Adjust)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual IMPORTANT Check that the cam assembly is progressing properly. Check for proper chain tensioner operation every 10 hours of vehicle operation, when the drive chains are being lubricated. Each step of the cam...

  • Page 158: Replacing A Slider Block (Scissor Style Chain Tensioner)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 6. Perform the servicing procedure, Installing The Drive Chain. 7. Pull up on the cam assembly to allow it to take up as much chain slack as possible. 8. Replace the floor pans.

  • Page 159: Assembling The Chain Tensioner System (Semi-Self Adjust)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 3. Slip the one torsion spring off the cam, and remove the second torsion spring from the frame assembly by removing the cotter pin that secures it. Assembling the Chain Tensioner System (Semi-Self Adjust) 1.
  • Page 160 MAIN INDEX Wheels, Axles & Chains Argo Service Manual 5. Insert the extended length of the torsion spring, assembled to the cam, into the hole of the welded tab on the frame. At the same time, place the same side of the cam's shaft into the tensioner systems guide.

  • Page 161: Disassembling The Chain Tensioner System (Scissor Style )

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 10. Perform the servicing procedure, Installing the drive chain. Disassembling The Chain Tensioner System (Scissor Style Chain Tensioner) 1. Release the spring tension on the tensioner arms and fold the upper tensioner block back out of the way.

  • Page 162: Assembling The Chain Tensioner System (Scissor Style)

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 3. Pull the pin from the tensioner arms and remove the arms and spring assembly from the vehicle 4. Lay out the components on a clean work surface. 5. Perform the servicing procedure, Chain Tensioner Slider Block Inspection 6.
  • Page 163 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 3. Insert the Tensioner Pin through the arm assemblies and into the bushing weldment on the frame. 4. Secure with the Hair Pin. 5. Pull up the tensioner spring and clip it over the tensioner arm. Employ a hook style tool to grab the spring end and ease installation.

  • Page 164: Removing The Idler Shaft (Frontier Models

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual If any of these conditions are noted, replace the idler shaft immediately. Inspect all the idler shaft fittings for: • seized or worn bearings • loose set screws at the bearings •...

  • Page 165: Installing The Idler Shaft (Frontier Models

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 1. Perform the servicing procedure, Removing the Firewall. 2. Perform the servicing procedure, Removing the Front Floor Pan. 3. Perform the servicing procedure, Removing the Driven Clutch, (Left side idler shaft only).
  • Page 166 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 2. Install one Idler Sprocket to the shaft with the sprocket's collar facing down (Left hand idler shaft). 3. Install one Idler Sprocket to the shaft with the sprocket's collar facing up (Right hand side idler shaft).
  • Page 167 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 6. Install the Inner Idler Shaft Bearing Flange, Bearing and Greasable Flange assembly to the inner frame location. Loosely attach the assembly with (4) Locknut, Nylon 3/8- 16, Flanged and Flat Washers.

  • Page 168: Removing The Idler Shaft (Aurora Models

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 10. Align set screws with Idler Shaft countersink and install. Apply LOCTITE blue to set screws and secure tightly. 11. Tighten down all flange hardware and torque to 35FT. LBS (47.4Nm) 12.
  • Page 169 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 2. Perform the servicing procedure, Removing The Drive Belt (if the left side Output Shaft is being serviced). 3. Perform the servicing procedure, Removing The Driven Clutch (if the left side Output Shaft is being serviced).

  • Page 170: Removing An Axle/Sprocket/Bearing (Without Bearing Extension

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 6. Perform the servicing procedure, Installing The Driven Clutch (if the left side Idler Shaft was being serviced). 7. Perform the servicing procedure, Installing The Drive Belt (if the left side Idler Shaft was being serviced).

  • Page 171: Installing An Axle/Bearing/Sprocket (Without Bearing Extension

    MAIN INDEX Wheels, Axles & Chains Argo Service Manual 5. Remove all hardware securing the flanges of both inner and outer bearings. 6. Pull the axle from the vehicle. If necessary use a soft faced mallet to knock the axle at the hub, from behind.
  • Page 172 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual IMPORTANT Align the grease zerk on the bearing flange with the grease hole in the bearing while installing the axle to the vehicle 8. On the inside of the vehicle, slip on each...

  • Page 173: Removing An Axle/Bearing/Sprocket (With Bearing Extension

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 12. Align each of the final drive sprockets as shown in the Drive Chain and Sprocket Orientation Charts. Ensure retaining clips are snapped into the grooves on the axles and positioned on each side of the sprocket(s) assemblies to minimize flotation along the shaft under vehicle application.

  • Page 174: Installing An Axle/Bearing/Sprocket (With Bearing Extension

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 4. Remove the tire from the axle. 5. Remove all hardware securing the flanges of both inner and outer bearings. 6. Pull the axle from the vehicle. If necessary use a soft faced mallet to knock the axle at the hub, from behind.
  • Page 175 WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual 8. Align the grease zerk on the bearing flange with the grease hole in the bear- ing while installing the axle to the ve- hicle 9. On the inside of the vehicle, slip on the...

  • Page 176: Drive Chain And Sprocket Orientation (8X8 Models

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual Drive Chain and Sprocket Orientation (8x8 Models)* *Bearing Extensions may or may not be present depending on model. WA-31...

  • Page 177: Drive Chain And Sprocket Orientation (6X6 Models

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual Drive Chain and Sprocket Orientation (6x6 Models) * *Bearing Extensions may or may not be present depending on model. WA-32...

  • Page 178: Removing The Inner Bearing

    WA INDEX MAIN INDEX Wheels, Axles & Chains Argo Service Manual Removing the Inner Bearing 1. Perform the servicing procedure, Removing an Axle, steps 1 through 8. The axle needs to be pulled from the inner bearing to be serviced. The axle assembly should be pulled completely at this point so that the old gasket at the outer bearing flange may be replaced with a new one.
  • Page 179 MAIN INDEX Transmission Argo Service Manual SECTION TR Transmission Table of Contents GENERAL INSTRUCTION ........................TR-2 TRANSMISSION OIL..........................TR-3 OIL LEVEL INSPECTION ......................... TR-4 CHECKING THE TRANSMISSION OIL LEVEL (34-100) ..............TR-4 CHECKING THE TRANSMISSION OIL LEVEL (34-200) ..............TR-4 CHANGING THE TRANSMISSION OIL - 34-100 ..................
  • Page 180 Do not attempt to move the gearshift from the neutral starting position until the en- gine idles down completely. The Argo is equipped with an automatic clutch that is activated by engine speed. If the engine idle speed is too high, the transmission will grind during gear engagement.

  • Page 181: Transmission Oil

    Inspecting the condition and level of oil in the transmission must be done on a regular basis. Do not operate the ARGO if the transmission oil level on the dipstick is above or below the grooved indicator. Damage to the transmission or a reduction in vehicle performance could occur.

  • Page 182: Oil Level Inspection

    Inspect the transmission oil on a daily basis. CAUTION Do not run the ARGO if the oil level in the transmission shows above or below the mark on the dipstick. Damage to transmission components could occur. Checking the Transmission Oil Level...

  • Page 183: Changing The Transmission Oil - 34-100

    TR INDEX MAIN INDEX Transmission Argo Service Manual Changing the Transmission Oil - 34-100 Remove firewall to access the drain plug located at the bottom of the transmission. Drain the transmission oil into a suitable container and dispose of the oil at a disposal site.

  • Page 184: Removing The Transmission (34-100

    13. Tilt the transmission back towards the drivers compartment and lift it from the power pack frame. Argo Transmission Disassembly - 34-100 1. Drain oil and unthread the 4 fasteners securing the shifter lever assembly to top end of the transmission and remove the lever.

  • Page 185: Separating The Transmission (34-100

    WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 3. Remove the oil seal from the input shaft. 4. Remove the retaining ring from the input shaft. 5. Remove the retaining rings from both output shafts. There may or may not be shims below the retaining rings.
  • Page 186 TR INDEX MAIN INDEX Transmission Argo Service Manual 3. Shift manually to top position with a pry bar (High Gear) and remove roll pin from the shift block on the high/low shift shaft. 4. Place shift shaft back into neutral.
  • Page 187 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 10. Place the reverse shift shaft block back down against the housing (out of reverse). 11. Remove the hi/lo shift shaft from the housing. TR-9...

  • Page 188: Disassembling The Input Shaft (34-100

    WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Disassembling The Input Shaft 1. Using an arbor press, remove the smaller ball bearing from the end of the input shaft. 2. Remove the retaining ring at the reverse gear.

  • Page 189: Disassemble The Spline Shaft Drive Gear Assembly (34-100

    TR INDEX MAIN INDEX Transmission Argo Service Manual Disassemble the Spline Shaft Drive Gear Assembly 1. Remove the bearing and high gear from the spline shaft at the arbor press. 2. Remove low gear, reverse gear, drive gear and bearing from the spline shaft using the the arbor press.
  • Page 190 TR INDEX MAIN INDEX Transmission Argo Service Manual 4. To remove the reverse shift shaft and reverse idler gear from the housing, first remove the retaining clip located above the reverse idler. 5. Raise the reverse idler up and remove the retaining clip found below.

  • Page 191: Disassembling The Differential (34-100

    TR INDEX MAIN INDEX Transmission Argo Service Manual Disassembling The Differential 1. Secure the Differential by the Output shaft on the cage side within a vise. A vise equipped with aluminum jaws must be used to avoid any damage to the out-put shaft.
  • Page 192 TR INDEX MAIN INDEX Transmission Argo Service Manual 7. Remove the Retaining Ring that secures the second Sun Gear to the Output Shaft on the Gear Plate side. See following page. 8. Slip the Sun Gear from the Output Shaft Gear Plate side.

  • Page 193: Transmission Component Inspection (34-100

    WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 11. Remove all (12) Oilite Bushings from both Cage and Gear Plate using 658-05 Needle Bearing Remover/Installer. NOTE This procedure will also push out the Output Shaft Bearing that has more than likely re- mained assembled to both of these components.
  • Page 194 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Inspect all transmission components and look for: Broken or badly worn teeth • worn out or seized up bearings • badly worn spline shafts • cracks in the transmission housing or cover •...
  • Page 195 Bearings Unless the ARGO technician has determined to his/her own satisfaction that the bearings are suitable to reuse, it is recommended that all bearings be replaced when rebuilding a transmission.

  • Page 196: Reassembling Thetransmission (34-100

    WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Reassembling the Transmission 1. Lay out all components of the 34-100 "Classic" Transmission on a clean work surface. TR-18...
  • Page 197 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual TR-19...

  • Page 198: Assembling The Idler Gear Bore Assembly (34-100

    WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Assembling the Idler Gear Bore Assembly 1. Install the 34-109 High Gear to the short side of the 34-112 Splined Shaft. IMPORTANT Install the High Gear with the machined shoulder up.
  • Page 199 TR INDEX MAIN INDEX Transmission Argo Service Manual 5. Install the 34-123 Drive gear to the top of the previously installed Reverse Gear. 6. Press on the 101-01 bearing to the end of the shaft, shielded side up. Do not install this 101-01 Bearing to the end of the shaft if the differential assembly has the high ratio 3.3 Gear Plate.
  • Page 200 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Reassembling the 34-130 Input Shaft 1. Install the first half of the 107-14 Retaining Ring to the machined groove at the High Gear Pinion location. 2. Interlock the second half of the 107-14 Retaining Ring into the previously installed one.
  • Page 201 TR INDEX MAIN INDEX Transmission Argo Service Manual 3. Locate the 108-85 Retaining Thrust Washer and slip it over the input shaft (cupped side towards retaining ring) and up against the retaining ring assembly. 4. Install the High Gear Pinion on to the Input Shaft (dog teeth facing towards the Thrust Washer).
  • Page 202 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 5. Slip a 108-79 Thrust Washer to the other side of the High Gear Pinion and secure with a 107-02 Retaining Ring. 6. Slip the Dog Clutch to the Input Shaft.
  • Page 203 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 9. Secure the Reverse Gear Pinion with a 107-15 Retaining Ring. TR-25...
  • Page 204 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Assembling the Differential 1. Install all 105-03 Oilite Bushings into both 34-122 cage and 34-124 Gear Plate. Photo TR-58 & 59 2. Blow all foreign debris from the Cage and Gear Plate.
  • Page 205 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual NOTE Use a specialized spacing tool to secure the previously installed 101-15 Bearing inside the Aluminum Cage while the Output Shaft is press into place. 5. Orient the 34-14 Sun Gear as in with the higher shoulder side facing up.
  • Page 206 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 8. Wipe down the 2 34-98 Output Shaft and assemble to the Gear Plate using the same method as described for the Aluminum Cage. 9. Orient the 2 34-14 Sun Gear as in instruction 8 and install and secure it with a 107-04 Retaining Ring using the same method as described for the Aluminum Cage in instruc- tion 10.
  • Page 207 TR INDEX MAIN INDEX Transmission Argo Service Manual 10. Set the assembled 34-122 Aluminum Cage into an assembly stand. 11. Install (3) 105-23 Hollow Dowl Pins into the mounting holes of the aluminum cage. 12. Install (6) 34-13 Pinions into the Oilite Bushings of the Aluminum Cage alternating the Pinions in an up and down manner.
  • Page 208 TR INDEX MAIN INDEX Transmission Argo Service Manual 13. Assemble the Gear Plate to the Aluminum Cage. Align the top of the Pinions in the Cage, with the Oilite Bushings in the Gear Plate. 14. Seat the Gear Plate to the Aluminum Cage using a soft faced mallet.
  • Page 209 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Assembling Transmission Components to Housing 1. Apply some LOCTITE pipe sealant to the threads of the 103-02 drain plug and install into the housing. 2. Start the 34-114 Reverse Shift Shaft into the housing boss.
  • Page 210 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual IMPORTANT O-Ring installed to the machined groove located near the end of the reverse shift shaft and require these extra steps to install it. Continue to push the reverse shift shaft through the housing until the machined groove for the O-ring location is visible to the outside of the housing.
  • Page 211 TR INDEX MAIN INDEX Transmission Argo Service Manual iii Push the reverse shift shaft back through the housing ensuring that you don't damage the O-ring as re-enters the housing. 7. Pull the Reverse Shift Shaft up until the lower retaining ring groove location is visible.
  • Page 212 TR INDEX MAIN INDEX Transmission Argo Service Manual 11. Install the 104-40 Dowel Pin to secure the Reverse Shift Shaft. 12. Assemble the 34-115 Reverse Shift Block to the Reverse Shift Shaft by aligning the keyway with the previously installed Dowel Pin.
  • Page 213 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 14. Install a 106-03 Retaining Ring to top groove of the Housing. 15. Press and install the 101-03 bearing into the Housing. NOTE If the differential consists of the high ratio 3.3 Gear Plate, it will be advantages to install the 101-01 Bearing into the cover as well at this point to avoid any interference later when installing the assembled Idler Gear Bore Assembly.
  • Page 214 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 18. Next, push the Reverse Shift Shaft and Block down against the Housing boss (out of reverse). Install (3) 109-05 Steel Balls into the Hi/Low Shift Shaft cavity of the Housing, and push each one into the machined hole at the Reverse Shift Shaft.
  • Page 215 TR INDEX MAIN INDEX Transmission Argo Service Manual 19. Install the 34-113 Hi/Low Shift Shaft into the Housing with the 3 machined gates facing to the outside of the housing and the 1 machined gate facing the Reverse Shift Shaft.
  • Page 216 TR INDEX MAIN INDEX Transmission Argo Service Manual Place the transmission into the neutral position. Secure the Hi/Lo Shift Fork to the Shift Shaft using a 104-39 Spring Pin. 26. Install a 106-03 Retaining Ring to the top groove of the 34-101 Left Transmission...
  • Page 217 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 28. Press a 101-03 & 101-16 Bearing into the Left Transmission Housing. 29. Apply Black 598 LOCTITE RTV Silicon Gasket Maker around the perimeter of the Transmission Housing 30. Press the Left Hand Housing to the Right Hand Housing at the arbor press. Tap with a soft face mallet while pressing at the output shaft area.
  • Page 218 TR INDEX MAIN INDEX Transmission Argo Service Manual 32. Install the 102-05 Oil Seal to the Input Shaft. 33. Install the 102-03 Oil Seal to the Output Shaft. Seat below the Retaining Ring groove. 34. Seat a 106-03 Retaining ring to the machined groove just above the previously installed Oil Seal.
  • Page 219 TR INDEX MAIN INDEX Transmission Argo Service Manual Install a 101-05 Bearing to the Output Shaft. 36. Repeat Steps 36 through 38 for the other Output Shaft. 37. Using the Output Shaft puller, pull each of the Output Shafts. Install a 114-04 Shim under the 107-02 Retaining Ring at the Output Shaft on the Left Side Housing.
  • Page 220 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual 38. Locate the shift lever opening and place the transmission shift blocks in the neutral pos- tion. 39. Place the 113-11 O-ring into the 34-118 Shifter Plate. 40. Assemble the 34-117 Shift Lever to the Shifter Plate. Apply a small amount of axle grease to the ball area of the shifter lever.
  • Page 221 WA INDEX TR INDEX MAIN INDEX Transmission Argo Service Manual Install the CE-035 Dipstick. 43. Fill the transmission with 1.1 L (38.7 oz of 80 W 90 Gear Lube HYPOY-C or ARGO brand 75W90 Synthetic lube (Part No.130-104). TR-43...
  • Page 222 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 34-200 Transmission Disassembly 1. Locate the E-brake disc on the transmission. Remove the outer retaining ring. 2. Slip off the e-brake disc Take this opportunity to inspect it. Inspect the drum surface, the spline or any cracks that may be present. 3. Remove the inner Retaining Ring. 4. Disconnect the extension spring from the spring mount bracket. 5. Loosen off the fasteners securing the shift lever clamp to the high/lo shift shaft and slide it off of the shift shaft. The spring mount bracket will come off attached to the shift clamp. See following page.
  • Page 223 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 6. Remove the 2 fasteners that are securing the second spring mount bracket to the transmission housing. Set this bracket aside to a clean work area. 7. Loosen off the 4 fasteners securing the shift lever clamp to the forward reverse shift shaft. Be aware when removing this assembly that there is a small ball and spring located in behind the detent plate. As you pry the shift block with...
  • Page 224 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 8. On earlier transmissions, as you slide the shifter assembly off of the shaft, be prepared to catch the ball in your hand. (Later transmissions utilize a contained ball and spring in- sert threaded into the housing). Remove the spring from the transmission housing(earlier transmissions) This ball and spring provides the shift gate notches you feel when you are shifting from forward to neutral to reverse. 9. Place the transmission to the transmission holding fixture and remove all fasteners se- curing the right hand housing to the left hand side. NOTE Fasteners used in the top half of the transmission are shorter than the ones used in the lower half of the transmission 10.
  • Page 225 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 11. Once the right hand housing is free from the left hand housing,separate and place on the bench. . 12. Remove the threaded rod from each of the three locations on the right hand housing. NOTE Generally the right hand output shaft stays with the right hand housing. The sun gear from that assembly may come into contact with one of the bearings left in the housing.
  • Page 226 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 13. Next locate and remove each of the retaining rings that are securing the hi/lo shift shaft in the housing. 14. Pull the hi/lo shift shaft from the transmission. As the shift shaft is pulled from the transmission,remove both shift forks, spring, washers and spacer as well. NOTE You may find it beneficial to install half of a 34-232 shift fork on to the reverse shift shaft, this will ease in helping to pull out the shift shaft from the housing.
  • Page 227 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 16. Remove the retaining ring securing the spacer on top of the 45 tooth helical pinion of the idler shaft assembly. Remove the spacer as well. 17. From below the transmission tap on the steering brake differential shaft to remove it from the housing. NOTE Raise the helical gear pinion from the idler shaft to allow for clearance when pulling the steering differential assembly from the housing. Move the steering differential as- sembly to a clean work area.
  • Page 228 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 18. Temporarily place the spacer back on to the helical gear pinion and secure with the retaining ring. 19. Place a pry bar under the helical gear pinion and gently pry upwards. 20. Remove the 27 tooth helical pinion below as well as the spacer. NOTE Note the remaining 35 tooth helical gear below in the housing. This will be removed at a later stage. Ontario Drive & Gear Limited www.argoutv.com...
  • Page 229 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 21. Remove the forward reverse shift shaft. Remove the retaining rings that are securing the shift shaft in the housing. 22. Gently pull the shift shaft from the housing along with the shift forks, spring, spacer and washers. 23. Pull the Reverse Idler Shaft from the housing. 24. Using a soft faced mallet, gently tap the input shaft from the housing. Ontario Drive & Gear Limited www.argoutv.com TR-51 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 230 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 25. Place the input shaft assembly on a clean work bench. 26. Remove the 35T helical gear. 27. Remove the transmission from the stand and set it upright. Locate the retaining ring on the output shaft. Remove this retaining ring. 28. Taking the housing to a press, remove the left hand side output shaft assembly. Ontario Drive & Gear Limited www.argoutv.com TR-52 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 231 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 29. Using a drift punch, gently tap the output shaft outer bearing from the housing. 30. Remove the output shafts inner retaining ring and remove the inner retaining ring of the brake shaft assembly. 31. Remove the flanged bushing from the bearing of the idler shaft assembly. 32. Using a drift punch, gently tap the outer bearing of the brake shaft assembly from the housing. 33. Flip the left hand housing over to remove the remaining outer retaining rings. Ontario Drive & Gear Limited www.argoutv.com TR-53 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 232 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 34. Remove all seals from the housing. 35. Remove the remaining idler shaft bearing using an internal bearing puller. 36. Remove both shift shaft bushings from the housing. 37. Locate the right hand side transmission housing and remove the retaining ring at the output shaft. Ontario Drive & Gear Limited www.argoutv.com TR-54 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 233 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 38. Take the housing to a press and push out the right hand side output shaft assem- bly. 39. Remove the inner retaining ring of the brake shaft assembly. 40. Using a drift punch gently tap out the outer bearing of the brake shaft assembly. 41. Turning the housing over, remove the second retaining ring at the brake shaft assem- bly and remove the seal. Ontario Drive & Gear Limited www.argoutv.com TR-55 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 234 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 42. Place the transmission housing back on to the stand to remove the idler shaft bearing 43. Flipping the housing back over, remove the retaining ring at the idler shaft location. 44. Remove the idler shaft seal. 45. Remove the outer output shaft bearing. 46. Remove the retaining ring to the inside of the seal at the output shaft location. 47. Flip the housing over and remove the second retaining ring at the outside of the seal Ontario Drive & Gear Limited www.argoutv.com TR-56 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 235 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 48. Remove the output shaft seal. Disassembling the Input Shaft. 1. Lay out the input shaft assembly on a clean work surface. 2. Take input shaft to press and remove bearing from the end of shaft. 3. Remove the retaining ring located beneath the bearing and slip off the spacer. Ontario Drive & Gear Limited www.argoutv.com TR-57 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 236 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 4. Remove the thrust washer. 5. Remove the reverse pinion. 6. Slip off the forward/reverse shift collar. 7. Flip the input shaft around to remove the two bearings that are located one on top of the other. Install a bearing removal tool between the two bearings and take to the press to remove the first bearing. 8. Remove the spacer located between the two bearings. Ontario Drive & Gear Limited www.argoutv.com TR-58 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 237 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 9. Place the bearing removal tool beneath the second ball bearing and use the press to remove. 10. Slide the bearing from the shaft. 11. Remove the retaining ring securing the forward pinion. 12. Slip the forward pinion off of the input shaft. IMPORTANT Please take note that there is a thrust washer located on both sides of the for- ward pinion.

  • Page 238: Disassembling The Idler Shaft (34-200

    TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual Clean all components in a varsol bath or an environmentally safe solution before Inspecting for any damaged or worn parts. Disassembling the Idler Shaft Assembly 1. Lay out the idler shaft assembly on a clean work surface. 2. Remove the 35 tooth helical gear. 3. Remove the spacer. . 4. Slide off the 27 tooth helical pinion and note the machined recess on the one side. 5. Next locate the retaining ring securing the 31 tooth helical pinion.
  • Page 239 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 7. Slide off the thrust washer. 8. Slide off the 31 tooth helical pinion. Take note of the thrust washer located to the dog tooth side. 9. Slide the hi lo/shift collar from the idler shaft. 10. Flipping the idler shaft to the other side, locate and remove the retaining ring securing the spacer below. Ontario Drive & Gear Limited www.argoutv.com TR-61 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 240 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 11. Remove the spacer. 12. Slide the 45 tooth helical pinion from the idler shaft. Photo 12 Clean all components in a varsol bath or environmentally safe cleaning solution and lay out on a clean work bench for inspection. Disassembling the Brake Shaft Assembly (Steering Differential Assembly) 1. Set the brake shaft assembly to a clean work surface. . 2. Secure the differential into a aluminum jawed vice. 3. Install a bearing removal tool to remove the ball bearing from the one end of the dif- ferential. See following page. NOTE There is a the shim washer beneath the ball bearing.
  • Page 241 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 4. Remove the 46 tooth spur pinion. Gently pry off with a pry bar. 5. Remove the thrust washer located below the spur pinion. Shim Washer Ontario Drive & Gear Limited www.argoutv.com TR-63 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 242 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 6. Remove four fasteners securing the 55 tooth helical gear. 7. Using a pry bar gently pry the helical gear from the differential cage. Note the dowel bushings at each fastener location. NOTE Each planet gear is staggered one up and one down. 8. Pull up and remove the brake shaft. 9. Remove each planetary gear. Ontario Drive & Gear Limited www.argoutv.com TR-64 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 243 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 10. Remove the two fasteners securing the 67 tooth helical gear to the differential cage. NOTE Each fastener has a dowel bushing and lockwasher. 11. Remove the 67 tooth helical gear. Take note of the two machined areas on the gear 180 degrees from each other. This will be important when the differential is reas- sembled. 12. Press the second brake shaft (located on the differential cage side), out of both ball bearing and 46 tooth spur pinion below. Photo 18 Ontario Drive & Gear Limited www.argoutv.com TR-65 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 244 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual IMPORTANT Take note of the shim washer above the spur pinion. 13. Remove the thrust washer from the cage below. 14. Remove the needle bearings from both differential cage and 55 tooth helical gear plate using specialized bearing remover tool P/N 608-54. 15. Press out each of the four oilite bushing from the 5 tooth helical gear. 16. Press out each of the four oilite bushing from the differential cage.
  • Page 245 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 17. Wash all components is a varsol bath or environmentally friendly solution and lay out for inspection. Disassembling the Reverse Idler Shaft 1. Remove the retaining ring securing the 20 tooth idler pinion on the reverse shift shaft. 2. Slide the idler pinion off of shaft along with the thrust washer installed above it. 3. Remove the thrust washer from the shaft located behind the idler pinion. 4. Remove the retaining ring. 5. Clean all components in a varsol bath or environmentally friendly cleaning solution and lay out on a clean work bench for inspection.
  • Page 246 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual Disassembling The Left Hand Side Output Shaft Assembly 1. Place the left hand side output shaft assembly into the assembly/disassembly fixture and remove the planetary stub shaft. This stub shaft requires a specialized socket tool to unthread it from the output shaft. 2. Pull the stub shaft and tapered needle from the assembly. 3. Remove the planetary hub. 4. Remove the second tapered bearing. Ontario Drive & Gear Limited www.argoutv.com TR-68 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 247 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 5. Slip the tapered bearing off the previously removed stub shaft and separate the spacer from the bearing. 6. Press the output shaft from the sun gear and ball bearing. 7. Locate each of the 21 tooth planet gears. Remove the retaining rings that secure each of them to the planet carrier pins. Ontario Drive & Gear Limited www.argoutv.com TR-69 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 248 TR INDEX MAIN INDEX Transmission 34-200 Argo Service Manual 8. Slip each planet gear off the carrier pins and set aside each flat washer located to the top of each one. Remove each needle bearing from the planet carrier pins. 9. Place the output shaft to the arbor press and remove each of the planet carrier pins. 10. Remove the retaining clip above the needle bearing and slip the needle bearing off of the output shaft. Disassembling The Right Hand Side Output Shaft 1. Locate the right hand side output shaft assembly and repeat steps 6 through 11 of Disassembling The Left Hand Side Output Shaft Assembly Ontario Drive & Gear Limited www.argoutv.com TR-70 PH.(519)- 662-2840 FAX (519)- 662-2421...
  • Page 249 TR INDEX MAIN INDEX Argo Service Manual Transmission Admiral Transmission Assembly RIGHT OUTPUT SHAFT ASSEMBLY TR-71...
  • Page 250 TR INDEX MAIN INDEX Argo Service Manual Transmission Position Output Shaft on special fixture on press. Install 105-26 Bushing into end of shaft using a special fixture. Note: Bushing must go in all the way to the bottom of the bore.
  • Page 251 TR INDEX MAIN INDEX Argo Service Manual Transmission Apply 60941 Loctite on middle of the pin and press through the output shaft until the retaining ring touches the shaft. Note: If pin is pressed too hard against the shaft it will crack. Repeat for other three pins. Wipe off excess loctite.
  • Page 252 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 101-83 Needle Bearing, 106-31 Retaining Ring, 34-207 Spur Gear, and 101-73 Ball Bearing, Note: Once pressed together, 34-207 Spur gear should spin freely. TR-74...
  • Page 253 TR INDEX MAIN INDEX Argo Service Manual Transmission LEFT OUTPUT SHAFT ASSEMBLY Assemble same as right side. Using 34-216 Output Shaft instead of 34-226 Output Shaft and no 105-26 Bushing. TR-75...
  • Page 254 TR INDEX MAIN INDEX Argo Service Manual Transmission Components: 101-76 Tapered Roller Bearing, 114-22 Spacer, 34-218 Planetary stub shaft, 34-219 Planetary Hub, 34-216 Output Shaft Press 101-76 Bearing Cups into the 34-219 Planetary Hub using a special fixture. Photo 1. Note: Bearing Cups need to be installed with cup facing upwards so that the bearing cones can be installed later.
  • Page 255 TR INDEX MAIN INDEX Argo Service Manual Transmission Slide (1) 101-76 Bearing Cone onto 34-218 Stub Shaft with cone facing threaded side. Take the output shaft to the vise, clamp with shaft facing down. (Make sure you use aluminum vise attachments).
  • Page 256 TR INDEX MAIN INDEX Argo Service Manual Transmission Thread 34-218 Stub Shaft with 101-76 Bearing Cone into the 34-216 Output Shaft. Torque to 100 ft lbs. Check endplay with dial indicator (.0005 to .0025) If endplay is not enough, use required shim size.
  • Page 257 TR INDEX MAIN INDEX Argo Service Manual Transmission Upper Differential Assembly Components 101-84 Needle Bearing, 101-40 Ball Bearing, 103-69/P2 Bolt 105-23 Dowel, 105-27 Bushing, 105-28 Dowel bushing, 108-03/P2 Lockwasher, 108-94 Thrust washer, 112-64 Bolts, 114-16 Shim, 34-201 Brake shaft, 34-202 Planet gear, 34-203 Spur pinion, 34-204 Helical gear, 34-205 Helical gear, 34-206 Differential Cage Ontario Drive &...
  • Page 258 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 105-27 Bushings into 34-204 Helical Gear and 34-206 Differential Cage from the inside of both the helical gear and cage. This can be identified by having a big counter bore for the 101-84 Needle Bearing which can also be installed with the writing on the bearing facing upwards.
  • Page 259 TR INDEX MAIN INDEX Argo Service Manual Transmission Slide 34-205 Helical Gear onto differential cage with inside slots facing up. Install 105-28 Dowel Bushings into slots on helical gear and cage. Apply 2760 Red LOCTITE to the threads of both 103-69 Bolts and to the threads of the mounting holes in the aluminum cage where they will be installed, and install with 108-03 Lockwashers.
  • Page 260 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 105-23 Dowels into top of cage by gently tapping with a hammer. Install 34-201 Brake Shaft in the 34-206 Differential Cage, followed by the 34-202 Planetary Gears which need to be staggered (one up and one down).
  • Page 261 TR INDEX MAIN INDEX Argo Service Manual Transmission Install another 34-201 Brake Shaft. Note: When installing the second 34-201 Brake shaft, shaft must be centered in the cage otherwise next step will be difficult. Drop on the 34-204 Helical Gear and align the bushings with the 34-202 Planetary Gears.
  • Page 262 TR INDEX MAIN INDEX Argo Service Manual Transmission Note: Any resistance due to parts being too tight, do not force. If this occurs, disassemble and check parts for interference. Install 112-64 Bolts with 2760 Loctite applied to the threads of the fasteners as well as the internal threads of the aluminum cage to which they will be installed.
  • Page 263 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 108-94 Washer onto the end of the 34-201 Brake Shaft Photo 22 followed by a 34-203 Spur Gear, 114-16 Washer and press on a 101-40 Ball Bearing. Repeat for the other side of differential assembly.
  • Page 264 TR INDEX MAIN INDEX Argo Service Manual Transmission INPUT SHAFT ASSEMBLY Components 101-01 Ball Bearing, 101-88 Ball Bearing, 101-89 Ball Bearing 101-90 Needle Bearing, 105-32 Bushing, 106-25 Retaining Ring, 106-27 Retaining Ring, 108-98 Washer, 114-17 Washer, 114-18 Spacer, 114-19 Spacer, 34-213 Input Shaft, 34-214 Reverse...
  • Page 265 TR INDEX MAIN INDEX Argo Service Manual Transmission Press 105-32 Bushing into 34-215 Forward Pinion. Install a 108-98 Washer onto left side of input shaft. Slide the 34-215 Forward Pinion onto left side of input shaft. Install another 108-98 Washer onto left side of input shaft followed by a 106-27 Retaining Ring.
  • Page 266 TR INDEX MAIN INDEX Argo Service Manual Transmission Press 101-88 Ball Bearing on next. Install 114-19 Spacer. Press 101-89 Bearing on next. Note: When pressing on 101-88 and 101-89 Bearings hold shaft assembly in press on the 34-215 Pinion. Press 101-90 Needle Bearing into the 34-214 Reverse Pinion.
  • Page 267 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 34-224 Shift Collar on right side of input shaft. Note: Shift collar must slide freely on shaft and fully engage with forward pinion. Install 34-214 Reverse Pinion, followed by the 114-17 Washer, 114-18 Spacer, and a 106-25 Retaining Ring.
  • Page 268 TR INDEX MAIN INDEX Argo Service Manual Transmission Press 101-01 Bearing onto shaft. TR-90...
  • Page 269 TR INDEX MAIN INDEX Argo Service Manual Transmission REVERSE IDLER SHAFT ASSEMBLY Components 101-87 Needle Bearing, 106-25 Retaining Ring, 108-99 Thrust Washer, 34-220 Idler Pinion, 34-221 Shift Shaft Reverse Press 101-87 Needle Bearing into the 34-220 Idler Pinion. TR-91...
  • Page 270 TR INDEX MAIN INDEX Argo Service Manual Transmission Install (1) 106-25 Retaining Ring into a groove, then slip on a 108-99 Thrust Washer. Slide on the 34-220 Idler Pinion that has the 101-87 Needle Bearing installed on to shaft. Note: Step on 34-220 Idler Pinion must face towards the end of the 34-221 Shaft that is the shortest.
  • Page 271 TR INDEX MAIN INDEX Argo Service Manual Transmission IDLER SHAFT ASSEMBLY Components: 108-96 Spacer, 34-209 Helical pinion, 106-28 Retaining ring, 34-210 Helical Pinion, 105-31 Bronze Bushing, 108-98 Thrust Washer, 34-223 Shift Collar, 34-208 Idler Shaft Press 105-31 Bronze Bushing into 34-210 Helical Pinion.
  • Page 272 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 108-98 Thrust Washer onto left side (longer side) of 34-208 Idler Shaft. Slide 34-210 Helical Pinion on the shaft. Install another 108-98 Washer. Install the 106-28 Retaining Ring. TR-94...
  • Page 273 TR INDEX MAIN INDEX Argo Service Manual Transmission Slide 34-209 Helical Pinion onto the idler shaft, followed by the 108-96 Spacer. Slide the 34-223 Shift Collar onto the idler shaft. Note: Shift Collar must slide freely on idler shaft and not get tight.
  • Page 274 TR INDEX MAIN INDEX Argo Service Manual Transmission HOUSING COVER ASSEMBLY Put the Right Output Shaft Assembly on the press. Install a 106-24 Retaining Ring into the bottom groove in the 34-228 Cover and 106-05 in the bottom groove of the upper differential bore in the cover.
  • Page 275 TR INDEX MAIN INDEX Argo Service Manual Transmission Put a small amount of oil on the inside of the 102-33 Oil Seal and put seal on end of shaft and press down. Note: Make sure oil seal spring is facing the inside of the transmission. To insure that spring stays on seal, press seal on shaft as far as possible by hand.
  • Page 276 TR INDEX MAIN INDEX Argo Service Manual Transmission Press 101-81 Ball Bearing onto housing and shaft. Install 106-23 Retaining Ring onto the output shaft. TR-98...
  • Page 277 TR INDEX MAIN INDEX Argo Service Manual Transmission HOUSING PRE-ASSEMBLY Components 101-81 Ball Bearing, 102-33 Oil Seal, 106-05 Retaining Ring, 106-23 Retaining Ring, 106-24 Retaining Ring Install 106-24 Retaining Ring into the largest hole opening on inside groove of housing. .
  • Page 278 TR INDEX MAIN INDEX Argo Service Manual Transmission Put a small amount of oil on the inside of the 102-33 Oil Seal, and put seal on end of shaft and press down. Note: Make sure oil seal spring is facing the inside of the transmission. To insure that spring stays on seal, press seal on shaft as far as possible by hand.
  • Page 279 TR INDEX MAIN INDEX Argo Service Manual Transmission Install 106-24 Retaining Ring into second groove of housing right in front of the oil seal. Press 101-81 Ball Bearing onto housing and shaft. Install 106-23 Retaining Ring onto the output shaft.
  • Page 280 TR INDEX MAIN INDEX Argo Service Manual Transmission TRANSMISSION ASSEMBLY Install 105-33 Flanged Bushing into both holes in housing from the inside. Install 104-03 Dowel Pins into holes in the housing. Install 101-73 Ball Bearing into housing followed by 105-30 Flanged Bushing.
  • Page 281 TR INDEX MAIN INDEX Argo Service Manual Transmission Note: If input shaft needs to be pressed into housing you must use a special fixture that pushes on the 34-215 Forward Pinion or else transmission may not spin freely. Install reverse idler shaft assembly with the flats on the 3/8" holes facing towards the inside of the transmission.
  • Page 282 TR INDEX MAIN INDEX Argo Service Manual Transmission Put a second 34-232 Shift Fork in the clutch of the input shaft and in between the reverse idler shaft assembly. Slide the 34-231 Shift Shaft back into the 34-221 Shaft. Make sure the shaft is all the way in by looking at the retaining ring groove.
  • Page 283 TR INDEX MAIN INDEX Argo Service Manual Transmission Install Idler Shaft Assembly; make sure to align the spline on shaft with the 34-211 Helical Gear. Note: Shaft must be pressed into 105-30 Flanged Bushing. Press a 105-29 Bushing into the 34-212 Helical Pinion, then drop it on top of the idler shaft.
  • Page 284 TR INDEX MAIN INDEX Argo Service Manual Transmission Slide a 34-231 Shift Shaft into housing and install (1) 127-186 Spring, (2) 12731594 Washers and (1) 34-232 Shift Fork. Once the shift fork is aligned in the Shift Collar have the shift shaft stick out 1/4" past the end of the fork, Photo 18, then install another 34-232 Shift Fork on the other side of the shift collar followed with a 114-21 Spacer.
  • Page 285 TR INDEX MAIN INDEX Argo Service Manual Transmission Install (2) 106-30 Retaining Rings on the 34-231 Shift Shaft. Note: Special tool is not required to install any of the retaining rings. Make sure that transmission spins in every gear, shifts with ease and does not spin when in neutral.
  • Page 286 TR INDEX MAIN INDEX Argo Service Manual Transmission Run a bead of 598 Gasket Maker around the matting surface on the housing and go around all of the holes. Fit cover assembly overtop of the housing assembly and press down on both idler shaft bearing bore, and the upper differential bearing bore, until cover is all the way down.
  • Page 287 TR INDEX MAIN INDEX Argo Service Manual Transmission Install (6) 112-143 Bolts and (6) 108-05 Lockwashers at the top end of the transmission. Torque all of the bolts to 20 ft-lbs. Press in a 101-86 Sealed Bearing onto the Idler shaft. Note: Bearing must not be pressed in too far or it will hit the 34-207 Gear.
  • Page 288 TR INDEX MAIN INDEX Argo Service Manual Transmission Press in a 102-37 Oil Seal on the end of the idler shaft. May have to release air or seal may come back off. Press in a 102-37 Oil Seal on the Differential shaft.
  • Page 289 TR INDEX MAIN INDEX Argo Service Manual Transmission Press on a 101-86 Sealed Bearing on the end of the Differential Shaft. Take transmission out of the press and put it on the bench. Pull both shafts of the steering differential with the output shaft puller tool to seat.
  • Page 290 TR INDEX MAIN INDEX Argo Service Manual Transmission EXTERNAL SHIFTING DEVICES Install a 102-36 Seal on both shift shafts. Insert a 34-32 Spring, and a 109-05 Steel Ball, into blind hole on the housing (earlier transmissions). Current transmissions utilize a 34-258 Plunger, Ball-Nose Spring assembly that is threaded into the housing at this location.
  • Page 291 TR INDEX MAIN INDEX Argo Service Manual Transmission Loosely bolt together (2) 34-236 Shift Clamps with (4) 112-184 Bolts. Insert a 34-235 Shift Lever into the two shift clamps, and install on the shift shaft. Tighten bolts until shift clamp assembly is almost clamping on the shift shaft.
  • Page 292 TR INDEX MAIN INDEX Argo Service Manual Transmission Install a 34-242 Spring Mount Bracket onto the other shift shaft. Loosely bolt together (2) 34-236 Shift Clamps with (4) 112-184 Bolts. Tighten bolts until shift clamp assembly is almost clamping on the shift shaft.
  • Page 293 TR INDEX MAIN INDEX Argo Service Manual Transmission Bolt the Switch Bracket to the transmission with (2) 112-47 Bolts with Blue 243 LOCTITE and torque them to 16 ft-lbs. Install the High-Low shifting stops by installing (2) 112-195 Bolts and (4) 117-92 Nuts.
  • Page 294 TR INDEX MAIN INDEX Transmission Argo Service Manual Re & Re Transmission From The Vehicle (34-200) ADMIRAL Removing the Transmission 1. Perform the Servicing Procedure, Removing the Front Floor Pan. 2. Perform the Servicing Procedure, Removing the Firewall. 3. Perform the Servicing Procedure, Removing the Drive Belt.
  • Page 295 TR INDEX MAIN INDEX Transmission Argo Service Manual 11. Disconnect the cable from the e-brake assembly. 12. The transmission is secured to the vehicle frame with two (2) HHCS 1/2-13X3.00 GR5 ZN Bolts and Lockwashers to the right side of the transmission (front and rear), and two (2) HHCS 1/2-13X1.25 GR5 ZN Bolts and Lockwashers to the left side of...
  • Page 296 TR INDEX MAIN INDEX Transmission Argo Service Manual NOTE Install only Four (4) Fasteners (leaving one (1) out for now). Secure with Lockwashers and Nuts. Torque to 22 FT.LBS. (30.0 Nm) 4. Perform the servicing procedure, Installing The Steering Brake Disc (Aurora Models).
  • Page 297 TR INDEX MAIN INDEX Transmission Argo Service Manual 3. With the transmission still in High Gear, adjust the High Stop Pin such that it is mak- ing contact with the shift block. Lock into position with jam nut. IMPORTANT Do not adjust stop screw too far in. Screw is adjusted just enough to contact the shift block.

This manual is also suitable for:

All 6x6

Table of Contents

Save PDF
