Argo Service Manual
SECTION FS
General Instructions............................................................................. FS-2
Fueling the Vehicle................................................................................ FS-3
Removing the Fuel Tank (All Models, except Avenger)..................... FS-4
Removing the Fuel Tank (Avenger Models) Supplement Pages........FS-4A
Vented Fuel System............................................................................... FS-4
Removing the Fuel Tank (6x6 Vehicles Prior to S7304).....................FS-7
Installing the Fuel Tank (All Models)..................................................FS-6
Installing the Fuel Tank (6x6 Vehicles Prior to S7304)......................FS-8
Inspecting the Fuel Tank and Fuel Line..............................................FS-6
Fuel Filter............................................................................................... FS-8
Ontario Drive & Gear Limited
PH.(519)- 662-2840 FAX (519)- 662-2421
Fuel System
Table of Contents
FS-1
Fuel System
www.odg.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argo Avenger Series
Summary of Contents for Argo Avenger Series
-
Page 1: Table Of Contents
Argo Service Manual Fuel System SECTION FS Fuel System Table of Contents General Instructions................FS-2 Fueling the Vehicle................FS-3 Removing the Fuel Tank (All Models, except Avenger)..... FS-4 Removing the Fuel Tank (Avenger Models) Supplement Pages..FS-4A Vented Fuel System................FS-4 Removing the Fuel Tank (6x6 Vehicles Prior to S7304).....FS-7... -
Page 2: General Instructions
Keep all open flame or spark away from the Argo while servicing the fuel system. Gasoline is extremely flammable, and can cause serious PERSONAL INJURY or DEATH. -
Page 3: Fueling The Vehicle
Never use gasoline containing methanol or white gas since engine or fuel system damage could occur. All models of the ARGO are equipped with a 32 litre (7.0 Imp. Gal., 8.4 U.S. Gal.) “see- thru” polyethelene fuel tank located underneath the driver’s seat. depending on loading and driving conditions, an ARGO can be driven for 7 to 12 hours on one tank of fuel. -
Page 4: Removing The Fuel Tank (All Models, Except Avenger
These deposits clog the fuel system and cause engine starting and operating problems. When storing the ARGO for 45 days or more, use ARGO Part No. 127-77 Fuel Stabilizer to treat fuel in the fuel tank and fuel containers. - Page 5 Argo Service Manual Fuel System IMPOR IMPORT T T T T ANT IMPOR IMPOR IMPOR Depending on the design of the fuel tank, earlier models may require that the tank be removed from the vehicle by pulling it from the seat frame into the rear compartment.
-
Page 6: Installing The Fuel Tank (All Models
FS-6 Slip the new or cleaned tank through the top of the seat support frame, or in from the rear compartment of the Argo. See IMPORTANT on previous page. Reconnect the filler hose to the tank and secure with the gear clamp. - Page 7 Argo Service Manual Fuel System cracks, breaks or punctures in all fuel lines and hoses. • cracked fuel filter casing • If any of these conditions exist, replace the affected component parts immediately. Removing the Fuel Tank (6x6 Vanguards prior to S7304) Drain the fuel tank.
-
Page 8: Fuel Filter
ARGO Part No. 125-64). On Conquest models the fuel filter is located in the fuel hose, next to the fuel tank. On all other Argo models the fuel filter is located at the engine. Replace the fuel filter after every 250 hours of operation or once a year. To replace the filter, loosen the gear clamps with a standard screw driver and pull the rubber fuel lines off of the filter. - Page 9 Argo Service Manual Fuel System SECTION FS Supplement Pages Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
- Page 10 Fuel System Argo Service Manual Ontario Drive & Gear ltd. www.odg.com/centaur (519) 662-2840 FAX (519) 662-2421...
- Page 11 Argo Service Manual Fuel System Removing the fuel Tank (Avenger) Drain any fuel that may be present in the fuel tank. Remove the seat to expose the storage tray & battery. Remove the battery. Drill out the 11 rivets that secure the tool box to the seat frame and remove.
- Page 12 Fuel System Argo Service Manual FS-3 FS-4 Slip the new or cleaned tank into the vehicle from the drivers compartment, recon- necting the filler hose to the tank at the same time and secure it with the gear clamp. IMPOR...
