  • Page 1 Original Instructions Version 1 PRESSURE WASHER 18100/97533...

  • Page 2: Table Of Contents

    User Manual for: 20V Pressure Washer WARNING! – Situations or actions that may result Stock No: 97533 (EU 91912), 18100 in personal injury or death. Part No: D20PW16BARKIT, D20PW16BAR CAUTION! – Situations or actions that may result in damage to the product or surroundings. 1.2 Revisions Important: –...

  • Page 3: Product Introduction

    This product is intended for domestic and infrequent clean vehicles, machinery and outside property. light-duty trade use. Any other application beyond the conditions established for use will be considered misuse. Draper Tools accepts no responsibility for improper use of this product. 3.2 Specification Stock No.

  • Page 4: Health And Safety Information

    • Only use the correct recommended Draper charger and corresponding battery pack with this product. WARNING! Disconnect the battery before Visit the Draper website for more information on the changing accessories, servicing or performing range of chargers and batteries available for use with any maintenance.

  • Page 5: Battery Packs

    • If the power supply cord is damaged, it must be replaced by Draper Tools, an authorised service agent or similarly 4.4 Battery packs qualified personnel in order to avoid a hazard. • This appliance is Class II† and is designed for • Before charging, read the instructions.

  • Page 6: Explanation Of Symbols

    4. Health and Safety Information 4.7 Explanation of symbols Battery Pack/Charger 130° Read the instruction manual Fuse protective device Wear face mask and safety glasses Polarity indication Keep out of the reach of children Direct current Class II construction Warning! (Double insulated) WEEE –...

  • Page 7: Identification And Unpacking

    If any part is occurred during shipment. damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual. (10)

  • Page 8: Packaging

    6. Battery Pack Charging Important! Only use Draper designated battery packs Warning! Check the condition of the charger and and chargers with this product. Use of any other battery prior to each charge. Do not use if there is third-party battery packs/chargers is considered misuse any sign of damage.

  • Page 9: Battery Pack Charge Status

    6. Battery Pack Charging 6.3 Battery Pack Charge Status - Fig. 2. • To check the battery charge status press the charge level indicator button (14.2). (14.2) Fig. 2 7. Preparing the Pressure Washer 7.1 Pressure Washer Assembly - Fig. 3. 1.

  • Page 10: Pressure Washer Assembly

    7. Preparing the Pressure Washer 3. Connect the hose (8) to the power nozzle (5) . Check the connection is secure by gently pulling the hose. - Fig. 5 & 6. Fig. 5 Fig. 6 4. Place the filter (10) end of the hose into a bucket or other clean water source.

  • Page 11: Operating Instructions

    8. Operating Instructions Important: Before operating this product, read and understand all the safety instructions listed in this manual. Ensure that the product is fully assembled and correctly prepared for use. 8.1 Battery Fitting - Fig. 8A. (14) • Slide the battery pack (14) onto the base of the handle.

  • Page 12: Detergent Bottle

    8. Operating Instructions 8.4 Detergent bottle - Fig. 11. • Use the detergent bottle (7) for deeper cleaning. • Use with either the long or short lance. Fig. 11 8.5 Safety Catch Button - Fig. 12. • The pressure washer gun is fitted with a safety catch to prevent accidentally operation.

  • Page 13: Maintenance And Troubleshooting

    9. Maintenance and Troubleshooting Important: Remove the battery pack from the tool before Do not operate it if you find damaged or worn parts. carrying out any adjustment, servicing or maintenance. Inspect the product for damaged or worn parts before each use.

  • Page 14: General Maintenance

    9. Maintenance and Troubleshooting 9.3 General Maintenance - Fig.16. - Fig.17. • Clean the moulded plastic housing of the machine • Push the lock and release lever (1) to the unlock using a soft brush and clean cloth. Do not use position to separate the handle from the power water, solvents or abrasives.

  • Page 15: Spares, Returns And Disposal

    • Do not dispose of batteries or cells in a charged condition. Li-ion * Waste Electrical & Electrical Equipment 11. Warranty Draper Tools products are guaranteed for 24 months - For more information visit drapertools.com/warranty. – 15 –...

  • Page 16: Contact Details

    Telephone Sales Desk: +44 (0) 23 8049 4333 General Enquiries: +44 (0) 23 8026 6355 General Fax: +44 (0) 23 8026 0784 Please contact the Draper Tools Product Helpline for repair and servicing enquiries. © Published by Draper Tools Limited © Published by Draper Tools Limited...
