Safety

OPERATING INFORMATIONS

Symbol Meaning
Permitted or not permitted position of the suspension eye in the
baffle when gripping on slopes (left view).
Permitted or not permitted position of the suspension eye in the
baffle when gripping on slopes. Right view.
Gripping process displayed correctly and incorrectly (left view).
Gripping process displayed correctly and incorrectly. Right view.
Step sequence Gripping (A, B) and depositing (C, D). Left view.
See also chapter "Operation".
Step sequence Gripping (A, B) and depositing (C, D). Right View.
See also chapter "Operation".
54500005 7 / 25
Order-No. Size
29040790 130x65 mm
29040791 130x65 mm
29040792 50x150
29040793 50x150 mm
29040794 90x120 mm
29040795 90x120 mm
GB
