INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
1203 Town Square
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is
installed properly, please read these instructions carefully before you begin. (Certain installations may require professional
help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
OBSERVE LOCAL PLUMBING AND BUILDING CODES
RECOMMENDED TOOLS & MATERIALS
Putty Knife
Adjustable Wrench
Regular Screwdriver
Channel Lock Pliers
Phillips Screwdriver
ROUGHING-IN DIMENSIONS:
FINISHED
WALL
9-5/8"
(244mm)
19-1/16"
(484mm)
10-3/4"
273mm
12-7/8"
327mm
FINISHED
FLOOR
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2019
S - Drop-In Sink
®
Hacksaw
Plumbers' Putty
or Caulking
FAUCET MOUNTING HOLES:
SINGLE HOLE, 4"(102mm)
OR 8"(203mm)
24"
(609mm)
1-3/4"
(45mm)
(191mm)
SUPPLIES
8"
AS REQ'D
203mm
1-1/4" O.D. WASTE
1-1/4" O.D. TAILPIECE
Pipe Wrench
Tubing Cutter
2-15/16"
(75mm)
2" MIN
(51mm)
34" MAX
BARRIER
(864mm)
7-1/2"
CLEARANCE
27" MIN
(686mm)
32-1/4"
(819mm)
SUGGESTED
SUGGESTED ADA INSTALLATION
Basin Wrench
Drill
Tape
Measure
25" MAX
(635mm)
COUNTER TOP
8" MIN
(203mm)
FREE
6" MAX
(152mm)
11" MIN
(279mm)
7302424-100 Rev 1 6/19
Level
Saber Saw
9" MIN
(229mm)
