8400/F8400 Exit Device Installation Instructions Table of Contents Table of Contents Overall Door preparation Prepare strike Drill door for exit device Verify door width Install chassis, exit device and trim Install covers, end cap, end cover Verify door height Latches 1.10...
8400/F8400 Exit Device Installation Instructions Overall Overall #426 PATENTED: STANDARD RODS SHIPPED strike FOR 7’ DOORS. U.S. PATENT NO. 4,819,976 8’ PACKAGE AVAILABLE. MUST 12-24 BE NOTED AT TIME OF F.H.P.M.S. ORDERING. FOR DOORS OVER Strike angle 8’, ORDER ETR PACKAGE...
8400/F8400 Exit Device Installation Instructions Door preparation Prepare strike Door preparation NOTE: SURFACE OF DOOR WHERE EXIT DEVICE IS TO BE INSTALLED MUST BE FLAT. PROPER REINFORCEMENT OF DOOR IS ALSO REQUIRED. NOTE: BEFORE STARTING INSTALLATION: For less bottom rod devices delete bottom latch 1.
8400/F8400 Exit Device Installation Instructions Drill door Verify door width Install chassis, exit device, and trim Drill door for exit device 1.4.1 Refer to carton label for model and trim numbers before drilling. 1.4.2 Prepare door by using the template enclosed (tape to door).
8400/F8400 Exit Device Installation Instructions Install covers, end cap, end cover Verify door height Latches Install covers, end cap, end cover 1.7.1 Install top and bottom latch cases using screws as noted 1.7.3 Install top and bottom strikes using fasteners as noted on the spotting template.
8400/F8400 Exit Device Installation Instructions Install chassis cover Options: cylinder dogging 1.10 Install chassis cover Install chassis cover, latch covers and endcover using (10) 8-32 x 1/4” [6] THPHMS and end cap with (2) #8 x 1” [25] PHFHTS screws.
Page 8
DORMA USA, Inc. T: 800-523-8483 www.dormakaba.us...
