Installation Box
Installation Guide
4 Installation
4.1 Mounting the Installation Box
Potentially lethal voltage is present on the installation box.
-
Mount the correct branch circuit protection fuses and the inverter before connecting the installation box to mains.
Procedure
1.
Mount the installation box on a flat, solid surface.
2.
Connect the PE terminal to ground.
3.
Connect the motor cable to plug X2 on the installation box.
4.
Connect the mains cable to plug X1 on the installation box.
Danfoss A/S © 2021.07
N O T I C E
Installation
AN378444290006en-000101 / 130R1214 | 9
