Installation Box
Installation Guide
Table 9: Wire/Connector Assignment for Plugs X11–X14
Pin
1
2
3
4
• Mating part: PROFIBUS X52 and X51 (female/male)
• Phoenix code number: SAC-2P-MSB/XX,XX-910/FSB SCO CT
• XX,XX is the cable length in [m, cm]
3.6 LCP Connector
The LCP cable is only used during installation/commissioning. The plug on the LCP connector must be mounted after use. Also refer
to the VLT® Decentral Drive FCD 302 Operating Guide.
8 | Danfoss A/S © 2021.07
Label
Brown
White
Blue
Black
AN378444290006en-000101 / 130R1214
Plugs
