Installation Box
Installation Guide
• Mating part: Motor X2 (male)
• Phoenix code number: KXC-K0341/XX,XX
• XX,XX is the cable length in [m, cm]
3.3 X11/X12/X13/X14 Photocell M8 Female
For non-used connectors. Keep blind plugs installed to connectors at all times to keep the enclosure tight.
General ratings:
• 30 V DC, maximum 1 A
• Front/screw mounting IP66, UL type 4
• Tightening torque: 0.1–0.2 Nm (0.9–1.8 in-lb)
Table 7: Wire/Connector Assignment for Plugs X11–X14
Pin
1
2
3
4
• Mating part: Sensor X11–X14 (male)
• Phoenix code number: SAC-4P-M 8MS/XX,XX-PUR/M8FS 34CP
• XX,XX is the cable length in [m, cm]
3.4 X51 PROFIBUS M12 Male
General ratings:
• 30 V DC, maximum 1 A
• Front/screw mounting IP66, UL type 4
• Tightening torque: 0.2–0.3 Nm (1.8–2.7 in-lb)
Table 8: Wire/Connector Assignment for Plugs X11–X14
Pin
1
2
3
4
• Mating part: PROFIBUS X52 and X51 (female/male)
• Phoenix code number: SAC-2P-MSB/XX,XX-910/FSB SCO CT
• XX,XX is the cable length in [m, cm]
3.5 X52 PROFIBUS M12 Female
For non-used connectors. Keep blind plugs installed to connectors at all times to keep the enclosure tight.
General ratings:
• 30 V DC, maximum 1 A
• Front/screw mounting IP66, UL type 4
• Tightening torque: 0.2–0.3 Nm (1.8–2.7 in-lb)
