Digimate LTV-3203 User Manual

Digimate ltv-3203: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Introduction ......................................................................2
Warnings and cautions ......................................................3
.......................................................6
Remote control hand unit ...................................................8
..............................................................13
Television installation ......................................................23
Troubleshooting ..............................................................25
............................................26
Specifications .................................................................27
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTV-3203 and is the answer not in the manual?

Questions and answers

Related Manuals for Digimate LTV-3203

Summary of Contents for Digimate LTV-3203

  • Page 1: Table Of Contents

    Contents Introduction ..............2 Warnings and cautions ............3 Main unit descriptions ............6 Remote control hand unit ...........8 The OSD menus ..............13 Television installation ............23 Battery installation & replacement for remote control unit ..24 Troubleshooting ..............25 Computer compatibility chart ..........26 Specifications ..............27...

  • Page 2: Introduction

    Introduction Thank you very much for your purchase of our LCD TV/Monitor. It serves as a normal color TV and PC monitor. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference.

  • Page 3: Warnings And Cautions

    Warnings and cautions Warning High voltages are used in the operation of this product. Do not remove the back cover of the cabinet. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture.
  • Page 4 Warnings and cautions Minimum distances 10cm 10cm Caution If the television is to be built into a compartment or similarly enclosed, the minimum distances must be 20cm maintained. Heat build-up can reduce the service life of your television, and can also be dangerous. Caution Never stand on, lean on, push suddenly the product or its stand.
  • Page 5 Warnings and cautions Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from the AC outlet. Caution Avoid exposing the main unit to direct sunlight and other source of the heat.

  • Page 6: Main Unit Descriptions

    Main unit descriptions Control location 1.Power button 2.TV/AV button (TV/AV) 3.Menu button (MENU) 4.Volume down button ( V -) 5.Volume up button ( V + ) 6.Program down button ( P- ) 7.Program up button ( P+ ) 8.Power indicator 9.Remote sensor MENU TV/AV...
  • Page 7 Main unit descriptions Caution 1.VIDEO,S-VIDEO share audio input R1,L1. 2.VIDEO,S-VIDEO can not be inserted together. 3.DVI,VGA,YPbPr share audio input R2,L2. 4.YPbPr can also accepts signal of YCbCr format. 5.Do not switch the Mains Switch to on until the light of the Power Indicator disappears.

  • Page 8: Remote Control Hand Unit

    Remote control hand unit 1.[Power] or : Turn the display on/off 2.[V+/V-]: Press [V+] to increase volume. Press [V-]to decrease volume.[V+] also can cancel the Mute mode, reference [MUTE] key. [V+/V-] also are used as arrow keys when operating in the menu. [V-] function as ,[V+] function as ,[V+] function as 3.
  • Page 9 Remote control hand unit 5.[MUTE]: Press this key, the sound is cut; Press key again or [V+] key, mute is cancelled. 6.[CALL]: Display the following information: Mute (1) The current program number or signal source. (2) The picture mode (3) The sound effects mode (4) The mode of sleep (5) The stereo mode 7.
  • Page 10 Remote control hand unit 10. [ZOOM]: Switch the size of the picture in the sequence as following ZOOM FULL 4:3 SUBTITLE ZOOM ZOOM FULL SUBTITLE In YPbPr mode, this function only work for 480i ,576i input. 11. [|/||]:For the signal from antenna,change A2\NICAM mode A2 mode: MONO STEREO MONO A2 bilingualism mode...
  • Page 11 Remote control hand unit 13. |P| : By repeatedly pressing this key, picture effects will change as follows: USER STANDARD MOIVE VIVID USER 04:28:18 |S| : By repeatedly pressing this key, sound effects will change as follows: USER VOICE MUSIC THEATER 15.
  • Page 12 Remote control hand unit Teletext keys: 19. [SUBTITLE]:This is a multiplexed key of subtitle and subcode. Directly press this key in TV mode , the key functions as subtitle, which calls out the subtitle page. If already entered text mode via [TEXT] key, this key functions as subcode . Subcode pages are subsections of long teletext pages that can only be displayed on the screen one section at a time.

  • Page 13: The Osd Menus

    The OSD menus OSD main menu is called out by first time pressing menu key. The main menu contains 3 parts: a icon column, a menu title and a menu item box. At first time the menu is called out, the icon column menu title upper icon pops out and the menu title indicates as picture menu.
  • Page 14 The OSD menus A.In the state of that the input source is TV, VIDEO, S-VIDEO YPbPr YCbCr 1.The picture menu a.The following picture is the sketch map of the picture menu. b. The definition of each option: 1.Brightness: Change the value of brightness with the key in the rang of 0 to 100.
  • Page 15 The OSD menus 2. The sound menu a. The following picture is the sketch map of the sound menu. b. The definition of each option: 1.Volume: Change the value of volume with the key in the rang of 0 to 100. 2.Balance: Change the value of balance with the key from -50 to 50,usually 0 is recommended.
  • Page 16 The OSD menus 9.The advance option including: (1). DUB.DBE: Select a bass enhancement mode from DUB, DBE or BBE and also could cancel the function of bass enhancement. * Some models do not have choice of BBE. (2) HP volume: Change the value of head phone volume with the key in the rang of 0 to 100.
  • Page 17 The OSD menus 3. The feature menu a. The following picture is the sketch map of the feature menu. b. The definition of each option: 1.Source OSD: Set the function of source OSD on or off. If set to on, source is always indicated on the left top. 2.Language: Select the language of the OSD menu from English, Traditional Chinese, Spanish and French.
  • Page 18 The OSD menus 4.Timer: Some options about auto shut down could be set in this item. Including sleep timer on or off, shut down time, power on time and the power on program. On/off timer only take effect when the RTC is set to on in Real Time Clock submenu. 5.TXT Language: The Teletext language could be selected in this item.
  • Page 19 The OSD menus 8.PIC MISC:Advanced picture settings which respectively improve picture quality. Settings in this menu may take significant effects only for some particular picture. Sometimes dis-professinal user can not find difference to toggle functions on off. To switch on LTI(luminance transient improvement) usually makes picture a little bit sharper, while CTI(chrominance transient improvement) clarify edge of coloured area.
  • Page 20 The OSD menus 4. The installation menu a. The following picture is the sketch map of the installation menu. b. The definition of each option: 1.Program NR: switch the program by the sequence of program number increase or Decrease by using the key 2.Color system: select the color system from Pal-443, SECAM, UNKNOWN, AUTO and NTSC-443 by using the key 3.Sound System: select the sound system from AUTO, BG, I,...
  • Page 21 The OSD menus 7.Skip: When it is ON, the current program would be skipped while changing channel with [P+/P-] keys; but it still could be achieved through digit keys. A skipped program number displays in red. You can set those weak signals or certain programs not likely to watch to skip on.
  • Page 22 The OSD menus B.In the state of that the input source is VGA, DVI 1.Display NO SYNC in the middle screen without signal input. The blue light glitters. [menu]and number key is unavailable. Switch to NO SYNC other source by [TV/AV],[P+/P-],[QV]. System goes to standby after 15 minutes of no signal waiting.

  • Page 23: Television Installation

    Television installation Connect antenna or video facility 1.Use 75 coaxial cable plug or 300-75 impedance converter to plug in antenna input terminal on the rear of the cabinet. 2.Connect the video facility to the audio, video in jack on the rear of the cabinet.

  • Page 24: Battery Installation & Replacement For Remote Control Unit

    Battery installation & replacement for remote control unit The remote control uses two 1.5V AA batteries. For battery installation and replacement are as following: 1. Turn the remote control unit upside down. Press down the grip of battery compartment and slide the color in the direction of the arrow.

  • Page 25: Troubleshooting

    Troubleshooting Before arranging for service, firstly know the status and then check simply as follows: Problems Check No picture or sound. Check if the power supply is plugged in and the power switch is on. Picture is OK, no sound. Check if the volume control is set to the minimum or mute.

  • Page 26: Computer Compatibility Chart

    Computer compatibility chart Resolution Frequency (Hz) Resolution Frequency (Hz) 640 * 400 70,85 1280 * 768 60,75 720 * 400 70,85 1280 * 960 60,75,85 640 * 480 VGA 60,66,72,75,85 1280 * 1024 SXGA 60,75,85 800 * 600 SVGA 56,60,72,75,85 1600 * 1200 UXGA 60,65,70,75 1024 * 768 XGA...

  • Page 27: Specifications

    Specifications Items Relevant illustrations MIX lifetime backlight 50,000 hours Number of Pixels 1366X 768 pixel Channel and frequencies VHFL: 46.25 to 168.25 MHz; VHFH: 175.25 to 463.25 MHz; UHF: 471.25 to 863.25 MHz. Color standard PAL, NTSC(AV), SECAM Sound standard D/K, BG, I, L/L Features Teletext...
  • Page 28 ..
  • Page 31 Minimum distances 10cm 10cm 20cm...
  • Page 32 75WCoaxial cable Mixer...
  • Page 33 Features Source OSD Language English Child Lock Timer Txt Language Pan European Txt E/W West Real Time Clock Pic Misc Blue Screen Move Action Exit Installation Program NR Color system AUTO Sound System AUTO Auto Store Frequency 384.25MHZ Skip Lock Move Action Exit...
  • Page 34 TV/AV MENU...
  • Page 35 S-VIDEO EARPHONE Pr/Cr Pb/Cb VIDEO SERVICE ANTENNA SCART 1 SCART 2...
  • Page 36 2.TV/AV 3.0 9 -/-- 4.QV 5.MUTE 6.CALL 7.ZOOM 8.|/||...
  • Page 39 Features Source OSD Language English Child Lock Timer Txt Language Pan European Txt E/W West Real Time Clock Pic Misc Blue Screen Move Action Exit...
  • Page 47 VGA DVI...
  • Page 48 Features Source OSD Language English Child Lock Timer Txt Language Pan European Txt E/W West Real Time Clock Pic Misc Blue Screen Move Action Exit Installation Program NR Color system AUTO Sound System AUTO Auto Store Frequency 384.25MHZ Skip Lock Move Action Exit...
  • Page 49 04:20:10 User Personal INCR MONO SLEEP 80...
  • Page 50 Installation Program NR Color system AUTO Sound System AUTO Auto Store Frequency 384.25MHZ Skip Lock Move Action Exit Features Source OSD Language English Child Lock Timer Txt Language Pan European Txt E/W West Real Time Clock Pic Misc Blue Screen Move Action Exit...
  • Page 52 640 * 400 70,85 1280 * 768 60,75 720 * 400 70,85 1280 * 960 60,75,85 640 * 480 VGA 60,66,72,75,85 1280 * 1024 SXGA 60,75,85 800 * 600 SVGA 1600 * 1200 UXGA 56,60,72,75,85 60,65,70,75 1024 * 768 XGA 60,70,75,85...
