Summary of Contents for Digimate L-1725
-
Page 2: Table Of Contents
17.0 TFT Active Matrix LCD Panel User Manual Table of Content Table of Content...…2 Safety Instructions ...…3 View of Monitor ... 4 Unpacking ... 6 Warning ... 6 Cleaning Notes... 7 Precaution ... 7 Features... 7 Hardware Installation ... 8 Hardware Installation Step by Step... -
Page 3: Safety Instructions
Safety Instructions Please read these safety instructions carefully. Please keep this User‘s Manual for later reference. Please disconnect this equipment from connecter before cleaning. Don‘t use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning. Make sure the voltage of the power source when you try to connect the equipment to the power outlet. -
Page 4: View Of Monitor
17.0 TFT Active Matrix LCD Panel User Manual View of Monitor Front View (1) Back View (2) English 4... - Page 5 17.0 TFT Active Matrix LCD Panel User Manual View of Monitor 15° Side View (3) English 5...
-
Page 6: Unpacking
Make sure that the system power is turned off. Plug the signal cable to the signal connector at the rear of PC. Plug adapter output cable to the jack at the rear of LCD monitor and the power cord to the adapter. -
Page 7: Cleaning Notes
With DDC1/DDC2B compliance, the monitor is plug and play compatible to Windows 95/98/me/2000/XP. Space Saving: The monitor is designed with 280 mm indepth to provide you with more hand room for desk working space. Side-by-Side : The monitor comes with 17.7 mm trimmed down frame to offer side-by-side operation 17.0 TFT Active Matrix LCD Panel User Manual... -
Page 8: Hardware Installation
Hardware Installation Be careful to your LCD monitor. It’s very delicate and easy to break. Turn off LCD’s and PC’s power before installation. Follow the installation step by step described below. Input 【1】 【2】 【1】DC-IN：This is for connecting the power cable 【2】AUDIO-IN：This can be connected to the audio-out connector of any sound resource. -
Page 9: Hardware Installation Step By Step
1. Turn your monitor upside down carefully with panel facing you to locate all connector port. Plug in signal cable to VGA-IN of the monitor and the other side of the cable to the computer. Connect the audio cable to AUDIO-IN on the monitor, and the other side to computer line out. - Page 10 17.0 TFT Active Matrix LCD Panel User Manual Hardware Installation Step by Step 4. Plug power cord onto DC adapter. 5. Plug the DC cable from power adapter onto the DC-IN on monitor. 6. Congratulations! You have just completed the hardware installation. English 10...
-
Page 11: Angle Of Inclination
17.0 TFT Active Matrix LCD Panel User Manual Angle of Inclination In normal condition LCD lay back 0˚ ~ 15˚ (positive and negative 2˚) English 11... -
Page 12: Monitor Setup Button
Menu control button Auto Adjust OSD Menu There 5 keys for user to set up the monitor, including “ “AUTO”, ” <▼> Down”, ” <▲> Up”. Please refer to the introduction below. “ Power”: Turn the LCD power on and off. When the power is on, the light turns green, and standby in the color of orange. -
Page 13: Troubleshooting
Troubleshooting If you encounter any trouble in using the monitor, make sure your monitor is properly installed according to the following steps before you call for service. ˙ There is no picture on the screen. Check: 1. Power saving mode. Press any key and move the mouse to deactivate the mode. -
Page 14: Color Adjust
17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) BRIGHTNESS: Adjust the difference between light and dark area. BRIGHTNESS COLOR ADJUST: Adjust the RED, GREEN, and BLUE colors of the display Click “ENTER” to adjust the R.G.B. -
Page 15: Color Temp
17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) COLOR TEMP: Adjust the color temperature of the display COLOR TEMP BACK : Return to the Main Menu Screen BACK COLOCK: Adjust the re-flash ratio of the vertical scanning area. -
Page 16: Auto Adjust
OSD (On-Screen Display) Menu Mode (PC Mode) AUTO ADJUST: Automatically adjust the re-flash ratio of both vertical and horizontal scanning areas of the display H. POSITION: Adjust the horizontal viewing area of the display V. POSITION: Adjust the Vertical viewing area of the display BACK : Return to the Main Menu Screen... -
Page 17: Osd Color
17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) OSD H. POS: Adjust the Horizontal position of the OSD OSD H. POS OSD V. POS: Adjust the Vertical position of the OSD OSD V. POS OSD TIME: Adjust the displaying time of the OSD OSD TIME... - Page 18 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) OSD ALPHA: Adjust the Alpha volume of the OSD displaying OSD ALPHA BACK: Return to the Main Menu Screen BACK LANGUAGE: Change the language support to the language displaying of the OSD.
- Page 19 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) VOLUME: Adjust the sound volume of the embedded speaker of the display VOLUME MUTE: Silence the embedded speaker of the display MUTE BACK : Return to the Main Menu Screen BACK English 19...
-
Page 20: Display Mode
Display Mode Resolution Horizontal Frequency (KHz) 640X350 (50Hz) 640X350 (60Hz) 640X350 (70Hz) 720X400 (50Hz) 720X400 (60Hz) 720X400 (70Hz) 640X480 (50Hz) 640X480 (60Hz) 640X480 (66Hz) 640X480 (72Hz) 640X480 (75Hz) 800X600 (50Hz) 800X600 (60Hz) 800X600 (72Hz) 800X600 (75Hz) 832X624 (75Hz) 1024X768 (60Hz) 1024X768 (70Hz) 1024X768 (72Hz) 1024X768 (75Hz) -
Page 21: Specification
Specification LCD Panel Type Viewing Angle Contrast Ratio Brightness Response Time Display Colors Max Resolution Pixel Pitch Input Signals RGB Analog Compatibility Connector RGB Analog Audio In Audio Out Power Power AC input Voltage DC input Voltage Consumption Power saving mode Internal Speaker User Interface LED Indicator...
