Evaluation Board User Guide
1 0 C4, C5, C24, C25
2 0 C7
3 0 C35, C36
4 0 L2
1 4 E1, E2, E4, E5
2 9 E3, E6-E13
3 2 J1, J2
4 1 JP1
5 4 MH1-MH4
6 2 MP1, MP2
7 1 XJP1
analog.com
OPTIONAL CIRCUIT COMPONENTS
CAP., OPTION, 0805
CAP., OPTION, 0603
CAP., OPTION, 0402
IND., OPTION, 0603
HARDWARE – FOR EVALUTATION CIRCUIT ONLY
CONN.,BANANA JACK,FEMALE,THT,NON-
INSULATED,SWAGE,0.218"
TEST POINT,TURRET,0.064" MTG.
HOLE,PCB 0.062" THK
CONN.,UMC,RCPT,STR,50 OHM SMD
CONN.,HDR,MALE,2x3,2mm,VERT,ST,THT
STANDOFF, NYLON, SNAP-ON,0.375"
CBL ASSY U.FL-SMA JACK-PLUG 3"
CONN.,SHUNT,FEMALE,2 POS,2.54mm
EVAL-LT8624S-AZ-IBB
KEYSTONE, 575-4
MILL-MAX, 2308-2-00-80-00-
00-07-0
SAMTEC, RSP-122811-01
WURTH ELEKTRONIK,
62000621121
KEYSTONE, 8832
PULSE ELECTRONICS,
W9003M
SAMTEC, SNT-100-BK-G
Rev A 6 of 9
