ASROCK Rack ROME2D32TM3 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ROME2D32TM3
User Manual
Version 1.0
Published May 2022
Copyright©2022 ASRock Rack INC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROME2D32TM3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK Rack ROME2D32TM3

Summary of Contents for ASROCK Rack ROME2D32TM3

  • Page 1 ROME2D32TM3 User Manual Version 1.0 Published May 2022 Copyright©2022 ASRock Rack INC. All rights reserved.

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree...
  • Page 4 Licensee’s intellectual property rights, to incorporate or otherwise utilize those comments and suggestions. TERMINATION OF THIS LICENSE. Intel or the sublicensor may terminate this license at any time if Licensee is in breach of any of its terms or conditions. Upon termination, Licensee will immediately destroy or return to Intel all copies of the Software.
  • Page 5 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant information based on regulation requirements.

  • Page 6: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installation of Memory Modules (DIMM) 2.4.1 DIMM Population for DDR4 2.4.2 DIMM Population for NVDIMM-N Expansion Slots (PCI Express Slots) Onboard Headers and Connectors Dr.
  • Page 7 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 NVMe Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Super IO Configuration 3.3.8 Serial Port Console Redirection 3.3.9 H/W Monitor 3.3.10 PCI Subsystem Settings 3.3.11 AMD CBS 3.3.12 AMD PBS...
  • Page 8 Security 3.5.1 Key Management Boot Screen 3.6.1 CSM Parameters Event Logs Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 9: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 10: Specifications

    1.2 Specifications ROME2D32TM3 Physical Status Form Factor Proprietary T-shape Dimension (W*D) 18.8607'' x 17.0149'' Processor System Supported CPU Support AMD EPYC™ 7003 and 7002 Series Processors Socket 1+1 Socket SP3 (LGA 4094) Max. Thermal 280 W Design Power (TDP) Chipset System on chip...
  • Page 11 CPU1_PVCCIN, CPU2_PVCCIN, PVDDQ_ ABCD,PVDDQ_EFGH,PVDDQ_IJKL,PVDDQ_ MNOP, 1.05V_PCH,1.8V_PCH, +BAT,PVNN_PCH, 3.3V,5V,12V,3.3VSB, 5VSB Server Management Controller ASPEED AST2500: IPMI2.0 with iKVM and vMedia support BIOS BIOS type AMI 256 Mb SPI Flash ROM Features ASRock Rack Instant Flash, ACPI 5.0, SMBIOS 2.3, Plug and Play (PnP)
  • Page 12 256Mb AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8 Support - ASRock Rack Instant Flash Support OS Microsoft® Windows®: - Server 2016 (64 bit) - Server 2019 (64 bit) - Server 2022 (64 bit) Linux®:...
  • Page 13 ROME2D32TM3 Operating Enviroment Temperature Operation temperature: 10°C ~ 35°C Non operation temperature: -40°C ~ 70°C NOTE: Please refer to our website for the latest specifications. This motherboard supports Wake from on Board LAN. To use this function, please make sure that the “Wake on Magic Packet from power off state” is enabled in Device Manager >...

  • Page 14: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 15: Motherboard Layout

    ROME2D32TM3 1.4 Motherboard Layout 48.26cm (19 in) AUX_PANEL1 DDR4_P2 FAN7_1 PANEL1 DDR4_P1 HSBP_PWR1 GPU_PWR1 DDR4_O2 DDR4_O1 FRNT_VGA1 DDR4_N2 FAN6_1 GPU_PWR3 DDR4_N1 DDR4_M2 FAN6 DDR4_M1 SLIM4 PCIE3 VGA1 PCIE_PWR2 PCIE2 CPU2 FAN5_1 SATA_SGPIO2 COM1 FAN5 ASPEED 2500 FAN8_1 SLIM6 SLIM5 IPMI_LAN1...
  • Page 16 Description PCIE Power Connector (PCIE_PWR2) PCIE 4.0 x32 Slot (PCIE2) PCIE 4.0 x16 Slot (PCIE3) Front VGA Header (FRONT_VGA1) GPU Power Connector (GPU_PWR3) GPU Power Connector (GPU_PWR1) Power Supply Unit Connector (PSU_CON1) System Panel Header (PANEL1) Auxiliary Panel Header (AUX_PANEL1) HDD Backplane Power Connector (HSBP_PWR1) 2 x 288-pin DDR4 DIMM Slots (DDR4_O2, DDR4_P2)* System Fan Connector (FAN7_1)
  • Page 17 ROME2D32TM3 No. Description System Fan Connector (FAN3) (for 2U system) 2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2)* Slimline x8 Connector (SLIM2) PWM Configuration Header (PWM_CFG1) System Fan Connector (FAN2_1) (for 1U system) System Fan Connector (FAN2) (for 2U system)
  • Page 18 No. Description Slimline x8 Connector (SLIM6) TPM Header (TPM1) Intelligent Platform Management Bus Header (IPMB1) BMC SMBus Header (BMC_SMB3) BMC SMBus Header (BMC_SMB2) BMC SMBus Header (BMC_SMB1) Clear CMOS Pad (CLRMOS1) Non Maskable Interrupt Button (NMI_BTN1) SATA SGPIO Connector (SATA_SGPIO2) * For DIMM installation and configuration instructions, please see p.20 (Installation of Memory Modules (DIMM)) for more details.

  • Page 19: Onboard Led Indicators

    ROME2D32TM3 1.5 Onboard LED Indicators...
  • Page 20 Item Status Description SB_PWR1 Green STB PWR ready FAN_LED7 FAN7_1 failed FAN_LED6 FAN6_1 failed FAN_LED5 FAN5_1failed FAN_LED8 FAN8_1 failed FAN_LED4 FAN4_1 failed FAN_LED3 FAN3_1 failed FAN_LED2 FAN2_1 failed FAN_LED1 FAN1_1 failed BMC_LED1 Green BMC heartbeat LED...

  • Page 21: I/O Panel

    ROME2D32TM3 1.6 I/O Panel No. Description No. Description VGA Header (VGA1) 1G LAN RJ-45 Port (LAN1)** Serial Port (RJ45) (COM1) 1G LAN RJ-45 Port (LAN2)** IPMI LAN Header (IPMI_LAN1)* USB 3.2 Gen1 Port (USB3_2) UID Switch (UID) USB 3.2 Gen1 Port (USB3_1) LAN Port LED Indications *There are two LED next to the LAN port.
  • Page 22 *There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 1G LAN Port (LAN1, LAN2) LED Indications Activity / Link LED Speed LED Status Description Status...

  • Page 23: Block Diagram

    ROME2D32TM3 1.7 Block Diagram PCIe Gen2 x2...

  • Page 24: Chapter 2 Installation

    Chapter 2 Installation This is a T-Shape Proprietary form factor (17” x 19”, 43.18 cm x 48.26 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 25: Installing The Cpu

    ROME2D32TM3 2.3 Installing the CPU 1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 27 ROME2D32TM3 Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.

  • Page 29: Installation Of Memory Modules (Dimm)

    ROME2D32TM3 2.4 Installation of Memory Modules (DIMM) This motherboard provides thirty-two 288-pin DDR4 (Double Data Rate 4) DIMM slots in two groups, and supports Eight Channel Memory Technology. CPU1 CPU2 DDR4_A1, B1, C1, D1, E1, F1, G1, H1 DDR4_I1, J1, K1, L1, M1, N1, O1, P1...

  • Page 30: Dimm Population For Ddr4

    2.4.1 DIMM Population for DDR4 Recommended Memory Configurations 1 CPU Configurations DIMM(S) CPU1 The symbol # indicates the slot is populated.
  • Page 31 ROME2D32TM3 2 CPU Configurations DIMM(S) CPU1 CPU2 The symbol # indicates the slot is populated.

  • Page 32: Dimm Population For Nvdimm-N

    2.4.2 DIMM Population for NVDIMM-N The followings are the NVDIMM population rules. • BIOS version 1.0.0.0 is required for NVDIMM-N enablement. • NVDIMMs can occupy a channel exclusively or share a channel with a standard DDR4 DIMM. • If sharing a channel, the NVDIMM module type must be the same as the DDR DIMM base module type and have the same DRAM width (x4 or x8, for example).
  • Page 33 ROME2D32TM3...

  • Page 34: Expansion Slots (Pci Express Slots)

    2.5 Expansion Slots (PCI Express Slots) There are 3 PCI Express slots on this motherboard. PCIE slot: PCIE1 (PCIE 4.0 Gen Z 8C x32 slot, from CPU1) is used for PCI Express x32 lane width cards. PCIE2 (PCIE 4.0 Gen Z 8C x32 slot, from CPU2) is used for PCI Express x32 lane width cards.

  • Page 35: Onboard Headers And Connectors

    ROME2D32TM3 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 36 Auxiliary Panel Header This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.7, No. 9) including front panel SMB, internet status indicator. AUX_PANEL1 +3VSB +3VSB LOCATORLED+ PLED- LOCATORLED- System Fault LED- System Fault LED+ HDLED- PWRBTN# LED_PWR LAN1_LINK RESET# SMB_DATA...
  • Page 37 ROME2D32TM3 Front USB 3.2 Gen1 Besides three default USB 3.2 Header Gen1 ports on the I/O panel, (19-pin FRNT_USB3_1) there is one USB 3.2 Gen1 (see p.7, No. 52) header on this motherboard. This USB 3.2 Gen1 header can FRNT_USB3_1 support one USB 3.2 Gen1 port...
  • Page 38 System Fan Connectors Please connect fan cables to the fan connectors and match the (for 2U system) (6-pin FAN1) black wire to the ground pin. (see p.7, No. 45) All fans support Fan Control. (6-pin FAN2) (see p.7, No. 39) (6-pin FAN3) (see p.7, No.
  • Page 39 ROME2D32TM3 BMC SMB Headers These headers are used for the (5-pin BMC_SMB1) SM BUS devices. (see p.7, No. 73) BMC_SMB_PRESENT_1_N Power (5-pin BMC_SMB2) BMC_SMBCLK (see p.7, No. 72) BMC_SMBDATA (5-pin BMC_SMB3) (see p.7, No. 71) SPI TPM Header This connector supports SPI...
  • Page 40 SATA Power Connector Please use a SATA power cable (4-pin HDD_PWR1) to connect this SATA Power (see p.7, No. 53) Connector and your SATA +12V HDD for supplying power from the motherboard, when using DC-IN mode without SATA power supply. Backplane Power Please connect a 12-pin power +12V...
  • Page 41 ROME2D32TM3 PWM Configuration This header is used for PWM Header configurations. (3-pin PWM_CFG1) (see p.7, No. 37) USB 3.2 Gen1 Connector (USB3_3) (see p.7, No. 64) Mini SAS HD Connector The Mini SAS HD connector (MSAS_HD0) supports SAS/SATA data (see p.7, No. 60) cables for internal storage devices.
  • Page 42 PDB Power Connector When a power distribution (5-pin CRPS_IN1) board is needed, use a power (see p.7, No. 55) cable to connect this connector and the PDB for power supply. Clear CMOS Pad This allows you to clear the (CLRCMOS1) data in CMOS.
  • Page 43 ROME2D32TM3 77 79 78 80...
  • Page 44 80-pin Defeinition Pin Defeinition GND_1 GND_12 RX_0+ TX_0+ RX_0- TX_0- GND_2 GND_13 RX_1+ TX_1+ RX_1- TX_1- GND_3 GND_14 SIDEBAND_7A SIDEBAND_0A SIDEBAND_4A SIDEBAND_1A SIDEBAND_A+ SIDEBAND_5A SIDEBAND_A- SIDEBAND_6A GND_4 GND_15 RX_2+ TX_2+ RX_2- TX_2- GND_5 GND_16 RX_3+ TX_3+ RX_3- TX_3- GND_6 GND_17 RX_4+ TX_4+ RX_4-...

  • Page 45: Dr. Debug

    ROME2D32TM3 2.7 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED...
  • Page 46 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 47 ROME2D32TM3 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 48 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 49 ROME2D32TM3 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 50 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 51: Identification Purpose Led/Switch

    ROME2D32TM3 2.8 Identification purpose LED/Switch With the UID button, You are able to locate the server you’re working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed,...

  • Page 52: Ssd Module Installation Guide (M2_1)

    2.9 M.2 SSD Module Installation Guide (M2_1) The Ultra M.2 Socket (M2_1, Key M) supports type 2242/2280 M.2 PCI Express module up to Gen4 x4 (64Gb/s). Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the screw.
  • Page 53 ROME2D32TM3 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location D by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut.

  • Page 54: Ssd Module Installation Guide (M2_2)

    2.10 M.2 SSD Module Installation Guide (M2_2) The M.2 Socket (M2_2, Key M) supports type 2242/2280 M.2 PCI Express module up to Gen4 x2 (32Gb/s). Installing the M.2 SSD Module Step 1 Prepare a M.2_SSD (NGFF) module and the screw. Step 2 Depending on the PCB type and length of your M.2_SSD (NGFF)
  • Page 55 ROME2D32TM3 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 56: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 57: Navigation Keys

    ROME2D32TM3 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 58: Main Screen

    3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 59: Advanced Screen

    ROME2D32TM3 3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, NVMe Configuration, ACPI Configura- tion, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, PCI Subsystem Settings, AMD CBS, AMD PBS, PSP Firmware Versions, Network Stack Configuration, Tls Auth Configuration, and Instant Flash.

  • Page 60: Cpu Configuration

    3.3.1 CPU Configuration SVM Mode Enable or disable CPU Virtualization. Node 0 Information View Memory Information related to Node 0. Node 1 Information View Memory Information related to Node 1.

  • Page 61: Chipset Configuration

    ROME2D32TM3 3.3.2 Chipset Configuration Onboard VGA Use this to enable or disable the Onboard VGA function. The default value is [Enabled]. Onboard LAN Use this to enable or disable the onboard LAN. The default value is [Enabled]. PCIE1 Link Width This allows you to select PCIE1 Link Width.
  • Page 62 SLIM3 Link Width This allows you to select SLIM3 Link Width. The default value is [x4x4]. SLIM4 Link Width This allows you to select SLIM4 Link Width. The default value is [x4x4]. SLIM5 Link Width This allows you to select SLIM5 Link Width. The default value is [x4x4]. SLIM6 Link Width This allows you to select SLIM6 Link Width.
  • Page 63 ROME2D32TM3 Restore AC Power Loss This allows you to set the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers.

  • Page 64: Storage Configuration

    3.3.3 Storage Configuration SATA Hot Plug Enable/disable the SATA Hot Plug Function.

  • Page 65: Nvme Configuration

    ROME2D32TM3 3.3.4 NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information.

  • Page 66: Acpi Configuration

    3.3.5 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. Ring-In Power On Use this item to enable or disable Ring-In signals to turn on the system from the powersoft- off mode.

  • Page 67: Usb Configuration

    ROME2D32TM3 3.3.6 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled]. (This item will be hidden when CSM is set to [Disabled].)

  • Page 68: Super Io Configuration

    3.3.7 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM). Serial Port Use this item to enable or disable the serial port. Serial Port Address Use this item to select an optimal setting for Super IO device. SOL Configuration Use this item to set parameters of SOL.

  • Page 69: Serial Port Console Redirection

    ROME2D32TM3 3.3.8 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information.

  • Page 70: Flow Control

    Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
  • Page 71 ROME2D32TM3 Out-of-Band Mgmt Port Microsof t Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this item to select the preferred terminal emulation type for out-of-band management.

  • Page 72: H/W Monitor

    3.3.9 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. Watch Dog Timer This allows you to enable or disable the Watch Dog Timer.

  • Page 73: Pci Subsystem Settings

    ROME2D32TM3 3.3.10 PCI Subsystem Settings SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.

  • Page 74: Amd Cbs

    3.3.11 AMD CBS CPU Common Options Use this item to configure CPU Common options. DF Common Options Use this item to configure DF Common options. UMC Common Options Use this item to configure UMC Common options. NBIO Common Options Use this item to configure NBIO Common options. FCH Common Options Use this item to configure FCH Common options.

  • Page 75: Amd Pbs

    ROME2D32TM3 3.3.12 AMD PBS Use this item to configure AMD CPM RAS related settings. iLA TraceMemoryEn Reserved 1M bytes MMIO space on 1M boundary when iLA TraceMemoryEn is enabled. SRIS mode debug Use this item to control SRIS mode debug.

  • Page 76: Psp Firmware Versions

    3.3.13 PSP Firmware Versions The PSP Firmware Verions displays the version information of PSP Recovery BL, PSP BootLoader, SMU FW, ABL, APCB, APDB, and APPB.

  • Page 77: Network Stack Configuration

    ROME2D32TM3 3.3.14 Network Stack Configuration Network Stack Use this item to enable or disable UEFI Network Stack. IPv4 PXE Support Use this item to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available.

  • Page 78: Media Detect Count

    Media detect count Number of times the presence of media will be checked. Use either +/- or numeric keys to set the value.

  • Page 79: Tls Auth Configuration

    ROME2D32TM3 3.3.15 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert.

  • Page 80: Instant Flash

    3.3.16 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive, floppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without preparing an additional floppy diskette or other compli- cated flash utility.

  • Page 81: Server Mgmt

    ROME2D32TM3 3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces.

  • Page 82: Bmc Network Configuration

    3.4.1 BMC Network Configuration Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No].

  • Page 83: Ipv6 Support

    ROME2D32TM3 The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/ipmi.asp...

  • Page 84: System Event Log

    3.4.2 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 85: Bmc Tools

    ROME2D32TM3 3.4.3 BMC Tools Load BMC Default Settings Use this item to load BMC default settings. KCS control Select the KSC interface state after POST end. If [Enabled] is selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS...

  • Page 86: Security

    3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 87: Key Management

    ROME2D32TM3 3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode.

  • Page 88: Authorized Signatures

    a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed Key Exchange Keys Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin)

  • Page 89: Forbidden Signatures

    ROME2D32TM3 Forbidden Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...
  • Page 90 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...

  • Page 91: Boot Screen

    ROME2D32TM3 3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order. Boot Option #2 Use this item to set the system boot order.

  • Page 92: Bootup Num-Lock

    Bootup Num-Lock If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled].

  • Page 93: Csm Parameters

    ROME2D32TM3 3.6.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows Server 2012 R2 or later ver- sions 64-bit UEFI and all of your devices support UEFI, you may also disable CSM for faster boot speed.

  • Page 94: Event Logs

    3.7 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 95 ROME2D32TM3 entries which utilize a multiple-event counter. The value ranges from 0 to 99 minutes. Log EFI Status Code Enable or disable the logging of EFI Status Codes as OEM reserved type E0 (if not already converted to legacy). Convert EFI Status Codes to Standard Smbios Type Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may be translated).

  • Page 96: Exit Screen

    3.8 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...

  • Page 97: Chapter 4 Software Support

    4.3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 98: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 99 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 100: Technical Support Procedures

    5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.

  • Page 102: Contact Information

    Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp ASRock Rack Incorporation e-mail: ASRockRack_sales@asrockrack.com...
