DSX 110, DSX 112, DSX 115
Active Speaker

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the the box pro DSX 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for thomann the box pro DSX 110

Summary of Contents for thomann the box pro DSX 110

  • Page 1 DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 11.10.2024, ID: 471967, 471968, 471969 (V3)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation and starting up........................ 12 4.1 Tips on handling speakers......................14 Connections and controls........................15 DSP functions............................19 Technical specifications........................22 7.1 Frequency response........................
  • Page 4 DSX 110, DSX 112, DSX 115 Active Speaker...

  • Page 5: General Information

    Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
  • Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.

  • Page 7: Safety Instructions

    Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 8 Safety instructions DANGER! Danger to life due to electric current! A short circuit could lead to a fire hazard and risk of death. Always use proper ready-made insulated triple-core mains cable with a safety plug. Do not modify the mains cable or the plug. In case of isolation damage, disconnect immediately the power supply and arrange repair.
  • Page 9 Safety instructions NOTICE! Damage to the device due to high voltages! The device can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess vol‐ tages can also cause a risk of injury and fires. Make sure that the voltage specification on the device matches the local power grid before plugging in the device.

  • Page 10: Features

    Features Features The active 2-way full-range speakers are characterized by the following features: Suitable for PA applications and DJ applications 1 × woofer: – DSX 110: 10-inch speaker (ferrite) with 1.4-inch voice coil – DSX 112: 12-inch speaker (ferrite) with 1.4-inch voice coil –...
  • Page 11 Features 35-mm stand flange High-quality wooden housing with carrying handles DSX 110, DSX 112, DSX 115 Active Speaker...

  • Page 12: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 13 Installation and starting up NOTICE! Potential property damage due to unsuitable stands! If the device is mounted on an unsuitable stand, there is a risk that the stand will fall over and cause damage. Only use stands whose maximum bearing capacity is at least as high as the weight of the device.

  • Page 14: Tips On Handling Speakers

    Installation and starting up 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area.

  • Page 15: Connections And Controls

    Connections and controls Connections and controls DSX 110 (item no. 471967) & ö DSX 110 POWER: 1400W ( PEAK ) & Power Input: 230V~50Hz Fuse: T3.15AL250V Auto Stand-by POWER DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 16 Connections and controls 1 [DSP] | Backlit display for DSP functions 2 [AUX IN] | Input line level player (e.g. MP3 player or CD player), designed as a 3.5-mm jack socket. The stereo signals are combined. 3 [INPUT 1] / [INPUT 2] | Mic/line input, designed as XLR/6.35-mm jack combo socket, balanced 4 [OUTPUT] | XLR panel plug, 3-pin, for the output of line-level signals.
  • Page 17 Connections and controls DSX 112 (item no. 471968) and DSX 115 (item no. 471969) & ö & Power Input: 230V~50Hz Fuse: T3.15AL250V DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 18 Connections and controls 1 [DSP] | Backlit display for DSP functions 2 [AUX IN] | Input line level player (e.g. MP3 player or CD player), designed as a 3.5-mm jack socket. The stereo signals are combined. 3 [INPUT 1] / [INPUT 2] | Mic/line input, designed as XLR/6.35-mm jack combo socket, balanced 4 [OUTPUT] | XLR panel plug, 3-pin, for the output of line-level signals.

  • Page 19: Dsp Functions

    DSP functions DSP functions Navigating the menu The device shows the overall volume. Turn the [MASTER VOL | PUSH FOR DSP] left or right to adjust the overall volume to between ‘–60 dB’ … ‘+10 dB’ . Press [MASTER VOL | PUSH FOR DSP] to call up the main menu and make the DSP settings. Turn [MASTER VOL | PUSH FOR DSP] left or right to select a menu item.
  • Page 20 DSP functions Menu level 1 Menu level 2 Function ‘SPEECH’ The sound programme for speech is activated. ‘DJ’ The sound programme for DJ applications gets acti‐ vated. ‘LOCATION’ ‘NORMAL’ The tone control for normal playback is activated. ‘MONITOR’ The tone control for stage monitors is activated. ‘HIGH EQ’...
  • Page 21 DSP functions Menu level 1 Menu level 2 Function ‘LED MODE’ ‘OFF’ Indicator LED switched off. ‘ON’ Indicator LED lights up permanently. ‘LIMITER’ Indicator LED lights up when overloaded. ‘LCD DIM’ ‘ON’ Backlight of the display is dimmed. ‘OFF’ Backlight of the display is normal. ‘BRIGHT’...

  • Page 22: Technical Specifications

    Technical specifications Technical specifications DSX 110 DSX 112 DSX 115 (item no. 471967) (item no. 471968) (item no. 471969) System Active 2-way full-range speaker Amplifier class D power amplifier and AB power amplifier Configuration Woofer 1 × 10-inch speaker (fer‐ 1 ×...
  • Page 23 Technical specifications DSX 110 DSX 112 DSX 115 (item no. 471967) (item no. 471968) (item no. 471969) Crossover frequency 3.0 kHz 2.8 kHz Output power 350 W 500 W Peak 1400 W 2000 W Sensitivity (1 W/1 m) 96 dB SPL 97 dB SPL 98 dB SPL Rated impedance...
  • Page 24 Technical specifications DSX 110 DSX 112 DSX 115 (item no. 471967) (item no. 471968) (item no. 471969) Weight 15.5 kg 19.1 kg 23.6 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Further information DSX 110 DSX 112 DSX 115 (item no.

  • Page 25: Frequency Response

    Technical specifications 7.1 Frequency response 7.1.1 DSX 110 Music dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 26 Technical specifications Live dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 27 Technical specifications Voice dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 28 Technical specifications dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 29 Technical specifications 7.1.2 DSX 112 Music dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 30 Technical specifications Live dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 31 Technical specifications Voice dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 32 Technical specifications dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 33 Technical specifications 7.1.3 DSX 115 Music dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 34 Technical specifications Live dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 35 Technical specifications Voice dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 36 Technical specifications dBSPL 20 Hz DSX 110, DSX 112, DSX 115 Active Speaker...

  • Page 37: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 38 Plug and connection assignment Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground DSX 110, DSX 112, DSX 115 Active Speaker...
  • Page 39 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 DSX 110, DSX 112, DSX 115 Active Speaker...

  • Page 40: Cleaning

    Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth.

  • Page 41: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 42 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
  • Page 44 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
