Summary of Contents for thomann SYRINCS D8 Column
- Page 1 D8 Column Active Speaker...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 16.12.2024, ID: 545264 (V2)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation..............................11 4.1 Setup..............................12 4.2 Tips on handling speakers......................12 Connections and controls........................13 Technical specifications........................19 Plug and connection assignment....................25 Cleaning............................... - Page 4 D8 Column Active Speaker...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions DANGER! Danger to life due to electric current! Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device when covers, safety equipment or optical components are missing or damaged. WARNING! Possible hearing damage due to operating the device at a high volume! The device can produce volume levels that, when operated at a high volume, may cause temporary or permanent hearing impair‐...
- Page 9 Safety instructions NOTICE! Damage to the device due to high voltages! The device can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess vol‐ tages can also cause a risk of injury and fires. Make sure that the voltage specification on the device matches the local power grid before plugging in the device.
-
Page 10: Features
Features Features Special features of the device: Active full-range column system Power amplifier Class D 1 × 8” woofer with 1.5” voice coil, 6 × 2.75” satellite speakers Bluetooth® 5.0 receiver Inputs: 2 × XLR/jack combo socket, 2 × 6.35 mm jack socket, 1 × 3.5 mm jack socket, 1 ×... -
Page 11: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 12: Setup
Installation 4.1 Setup The D8 Column system consists of an 8” woofer (installed in the subwoofer module) and six 2.75” satellite speakers (installed in the column speaker module). The individual elements can be connected to one another with the plug-in system. The following setup variations are pos‐ sible: 1 ×... -
Page 13: Connections And Controls
Connections and controls Connections and controls ö HIGH HIGH HIGH MONO STEREO LINK IN (LEFT) PAIR POWER/LIMIT LEVEL LEVEL LEVEL LEVEL LEVEL & CH3/4 CH5/6 MASTER D8 Column Active Speaker... - Page 14 Connections and controls / [AUX] | Switch for selecting the audio source (Bluetooth® or AUX device) for channel 5/6 2 [STEREO (LEFT)] / [MONO] / [LINK IN] | The output level is controlled via the input channel level. Use the toggle switch to select the appropriate mode: [STEREO (LEFT)] | The system becomes the master of the left channel;...
- Page 15 Connections and controls 6 [MASTER] | Rotary control for adjusting the overall volume 7 [LEVEL] | Rotary control for adjusting the volume of the input signal for the corresponding channels 8 [HIGH] / [LOW] | Rotary control for adjusting the EQ effect for the corresponding channels 9 [EFFECT] | Rotary control for adjusting the reverb effect for the corresponding channels in microphone mode D8 Column Active Speaker...
- Page 16 Connections and controls Back L/MONO LINK IN LINK OUT LINE LINE (From Master LINK OUT) (To 2nd LINK IN) CH3/4 CH5/6 LINK IN FUSE T5 A/250V 100-240V~50/60Hz Power Consump on 250W D8 Column Active Speaker...
- Page 17 Connections and controls 10 [AUX] | 3.5 mm jack socket for connecting an external audio device (smartphone, tablet or PC) 11 [LINK IN] | Link input, designed as an XLR panel plug, 3-pin Use the toggle switch (2) to select the [LINK IN] mode. The right channel is used. 12 [OUT] | Link output, designed as an XLR panel socket, 3-pin, for connecting another D8 column system The output level is regulated via the input channel level.
- Page 18 Connections and controls 17 Fuse 18 Rubber panel plug for the power supply D8 Column Active Speaker...
-
Page 19: Technical Specifications
Technical specifications Technical specifications 84 mm 82 mm 84 mm 82 mm 340 mm 430 mm D8 Column Active Speaker... - Page 20 Technical specifications System Active 2-way speaker Amplifier class Configuration Woofer 1 × 8” speaker (ferrite) with 1.5” voice coil Tweeter 6 × 2.75" satellite speaker (neodymium) with 0.75" voice coil Input connections MIC/GTR/LINE 2 × XLR/jack combo socket (balanced) Line 2 ×...
- Page 21 Max. transmission power 1.6 mW or +2 dBm Max. range 10 m Standard Version 5.0 Name Syrincs D8 column Codecs PCM, ADPCM, CBR, VBR Playback formats Power consumption 250 W Fuse 5 mm × 20 mm, 5 A, 250 V, slow blow...
- Page 22 Technical specifications Spacer element 84 mm × 824 mm × 82 mm Weight Bass 10.6 kg Satellite, spacer element 3.6 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) D8 Column Active Speaker...
- Page 23 Technical specifications Further information Housing material Polypropylene Housing colour Black Crossover points 2-way Monitor inclination Media player Microphone input Transport bag Included Mic preamp Rechargeable battery opera‐ tion App control USB connection SC card slot Truss-capable Stand flange D8 Column Active Speaker...
- Page 24 Technical specifications Frequency response D8 Column Active Speaker...
-
Page 25: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 26 Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding D8 Column Active Speaker...
- Page 27 Plug and connection assignment XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) D8 Column Active Speaker...
-
Page 28: Cleaning
Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth. -
Page 29: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 30 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
