Summary of Contents for thomann SYRINCS D18 Sub

  • Page 1 D18 Sub Active Speaker...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 21.11.2022, ID: 537820...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features............................... 12 Installation..............................13 4.1 Tips on handling speakers......................14 Connections and controls........................15 Technical specifications........................
  • Page 4 D18 Sub Active Speaker...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. D18 Sub...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Symbols And Signal Words

    General information Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
  • Page 8 General information Warning signs Type of danger Warning – high-voltage. Warning – danger zone. D18 Sub Active Speaker...

  • Page 9: Safety Instructions

    Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 10 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord). Do not modify the mains cable. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment.
  • Page 11 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.

  • Page 12: Features

    Features Features The device is characterized by the following features: 18" woofer Class D amplifier Connection options: XLR connectors for signal outputs (L+R and crossover), XLR/jack combo sockets for line input signals Phase switch Switchable x-over frequency for top speakers 90 / 120 Hz Tripod stand flange (M20) Two lateral carrying handles Multiplex plywood housing...

  • Page 13: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.

  • Page 14: Tips On Handling Speakers

    Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area.

  • Page 15: Connections And Controls

    Connections and controls Connections and controls ö OUTPUT 1 OUTPUT 2 CROSSOVER PHASE 230 V FUSE = T4AL 250V 120Hz 180° 110 V FUSE = T8AL 250V 90Hz 0° INPUT 1 INPUT 2 FRONT LED VOLUME PUSH PUSH POWER SIGNAL/LIMIT ON/L 230V~50 Hz 110V~60 Hz...
  • Page 16 Connections and controls 1 [OUTPUT 1]/[OUTPUT 2] | balanced line signal outputs, designed as XLR chassis plug 2 [CROSSOVER] | slide switch to toggle the x-over frequency, toggles between 90 Hz and 120 Hz 3 [PHASE] | slide switch for shifting the phase of the loudspeaker signal by 180°. This avoids unwanted cancellation effects in combination with other speakers.

  • Page 17: Technical Specifications

    Technical specifications Technical specifications Speaker 1 × 18" woofer 1 × 3" voice coil Input connections Voltage supply IEC chassis plug C14 Line signal 2 × XLR / 1/4" jack combo socket Input impedance -20 kΩ Output connections Line signal 2 ×...
  • Page 18 Technical specifications Fuse 230 V: 5 mm × 20 mm, 4 A, 250 V, slow-blow 110 V: 5 mm × 20 mm, 8 A, 250 V, slow-blow Dimensions (W × H × D) 784 mm × 647 mm × 660 mm Weight 41 kg Ambient conditions...
  • Page 19 Technical specifications Further information Construction type Direct emitter Multi-channel power amp Number of woofers High Cut fixed DSP display Truss-capable Stand flange Housing Wood Colour Black Casters Optional (item no. 415294) Cover D18 Sub Active Speaker...
  • Page 20 Technical specifications Frequency response dBSPL 20 Hz D18 Sub Active Speaker...

  • Page 21: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 22 Plug and connection assignment 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) D18 Sub Active Speaker...

  • Page 23: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 24 Notes D18 Sub Active Speaker...
  • Page 25 Notes D18 Sub Active Speaker...
  • Page 26 Notes D18 Sub Active Speaker...
  • Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
