ZEROXCLUB INSTRUCTIONS MANUAL
ZEROXCLUB 10.1" Magnetic Solar Wireless
Backup Camera System
Model: BCX1002
Installation and Operation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCX1002 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZEROXCLUB BCX1002

  • Page 1 ZEROXCLUB INSTRUCTIONS MANUAL ZEROXCLUB 10.1" Magnetic Solar Wireless Backup Camera System Model: BCX1002 Installation and Operation Instructions...
  • Page 2 ZEROXCLUB INSTRUCTIONS MANUAL PLEASE NOTE: Thank you for your trust in ZEROXCLUB and it's our pleasure to have you to purchased our product! ZEROXCLUB is committed to providing the high quality products and the pleasant shopping experience.  Before operating this backup camera system, please read this instructions completely.
  • Page 3: Table Of Contents

    ZEROXCLUB INSTRUCTIONS MANUAL Table of Contents 1 WHATS IN THE PACKAGE ........................3 2 Introduction and Specifications .......................5 3 SYSTEM DESCRIPTION ........................6 3.1 Monitor ..........................6 3.2 Camera ..........................9 4 INSTALL GUIDE ..........................11 4.1 System Power Testing ......................11 4.1.1 Suggested Sequence for Installation ................
  • Page 4: Whats In The Package

    ZEROXCLUB INSTRUCTIONS MANUAL 1 WHATS IN THE PACKAGE The ZEROXCLUB backup camera system will work for you with the years of reliable service. Our monitors, cameras and cables are of the highest quality. Please check and ensure there is no damage on the shipping box when you received it.
  • Page 5 ZEROXCLUB INSTRUCTIONS MANUAL Monitor Backup Camera*2 Power Cable (Built in 32GB memory for Monitor card) Car Charger Antenna*4 Wall Charger with Type-C Cable*2 Bracket with Sticker for Suction Cup Mount Adapter for Suction Cup Monitor Mount...
  • Page 6: Introduction And Specifications

    ZEROXCLUB INSTRUCTIONS MANUAL 2 Introduction and Specifications The camera system is designed to monitor the road condition and ensures safety for your reversing and driving. The monitor is required to be connected to a 9-35 Volt Direct Current power source (Current limited 1~2A).
  • Page 7: System Description

    ZEROXCLUB INSTRUCTIONS MANUAL 3 SYSTEM DESCRIPTION 3.1 Monitor Power button (on top of the monitor) Turn on / off the monitor Memory Card Placement ( on the right side of the monitor) NOTE: Please note that pressing the power button to turn off the monitor will not turn off the camera.
  • Page 8: Monitor Menu

    ZEROXCLUB INSTRUCTIONS MANUAL 3.1.1 White Tag There is a protective cover on the screen, it will come off if you pull on the white tag. 3.1.2 Monitor Menu 1. Monitor System Menu Touch the icon on the right side of the screen to enter menu...
  • Page 9 ZEROXCLUB INSTRUCTIONS MANUAL Switch camera channels There are Two channels on the screen, you can swipe your finger left or right on the screen to change the camera channel or switch the screen to full / split screen mode. ② To pair a camera with a specific channel on the screen, please switch to single camera screen mode (Cam1 or Cam2) on the monitor, then follow the below 5.2.1 pairing method to pair the system.
  • Page 10: Camera

    ZEROXCLUB INSTRUCTIONS MANUAL 3.2 Camera 3.2.1 Two Charging Methods The camera supports USB-C charging (5V DC charging) and Solar charging. Due to the limitation of the solar panel area, solar charging is only an auxiliary means to extend the working time of the camera, and it is better to use Type-C charging as the main charging method.
  • Page 11 ZEROXCLUB INSTRUCTIONS MANUAL NOTICE a. Turn off the camera to save energy when you don’ t need it, such as overnight. b. Please fully charge the backup camera with USB-C cable before first use. The solar panel can be used as a tool to supply power to the battery, extend the working time of the backup camera and reduce the charging times.
  • Page 12: Install Guide

    ZEROXCLUB INSTRUCTIONS MANUAL 3.2.5 Type-C Charging port Please remove the cover of the charging port then plug the included type-C Charger into the port for charging. After charging, please close the cover of the charging port to prevent water ingress.
  • Page 13: Camera Installation

    ZEROXCLUB INSTRUCTIONS MANUAL  Metal Bracket Installation: Suction Cup Mount Installation:  4.3 Camera Installation With strong magnets at the bottom, you could installed the camera to metal surface of the vehicle.
  • Page 14: Power Monitor

    ZEROXCLUB INSTRUCTIONS MANUAL 4.4 Power Monitor Mount the antennas to ② Connect the power cord or Power the camera ① ③ monitor car charger to monitor and monitor Use Car Changer Use Power Cord 5 SYSTEM OPERATION The below picture is the main interface of the monitor, the operation is very simple.
  • Page 15: Pairing Operation

    ZEROXCLUB INSTRUCTIONS MANUAL Software Management System Main Menu and Sub-Menu Main-menu Sub-Menu Paring Pairing Start and Count Down from 30 Second Picture Brightness, Contrast, Hue, VOLUME(disable), AUTO-DIM Mir-flip Normal, Mirror, Flip, Mir-flip System Delay Time, Time, P-Line, Language Record RECORD, REWRITE, FORMAT...
  • Page 16: Picture Operation

    ZEROXCLUB INSTRUCTIONS MANUAL ② Please switch to single camera screen mode (CAM1 or CAM2) ③ Touch the icon to enter menu page, and then find and touch the “PAIRING” to enter the pairing mode. ④ There will count down from 30 second on screen during pairing, please turn on the camera within this time.
  • Page 17: Mir-Flip Operation

    ZEROXCLUB INSTRUCTIONS MANUAL Auto Dim: You could turn on/off the Auto Dim as needed.  5.4 MIR-FLIP Operation You can flip the image to front view, mirror view or inverted view  according to your needs. There are four options to flip the image on...
  • Page 18: Play Operation

    ZEROXCLUB INSTRUCTIONS MANUAL 5.6 PLAY Operation You can play the recorded videos on the monitor, or read the  memory card data on other devices to play. Enter the PLAY status, you will see all of the recorded video. ...
  • Page 19 ZEROXCLUB INSTRUCTIONS MANUAL How to turn on/off the Parking Guideline? A: MENU → SYSTEM → P-LINE→ ON/OFF. What is REWRITE? A: If the rewrite is turned on, the system will automatically overwrite the original recorded video once the memory card capacity is full.
  • Page 20: Troubleshooting

    ZEROXCLUB INSTRUCTIONS MANUAL 6.11 Q: The monitor emits smoke after connection. A: It might be due to the reverse connection of the positive and negative, and cause a short circuit. Please make sure the wiring is correct when installation. 6.12 Q: How to turn on the night vision of the camera? A: It will be automatically turned on in the dark environment.
  • Page 21: Warranty

    Contact Email: sales1@uszeroxclub.com 8 Warranty ZEROXCLUB provide 18 months warranty and 3 months replacement service. We also provide lifetime technical support to ensure the backup camera could be used for many years. If you are not satisfied or need any help with this product, please feel...
  • Page 22 ZEROXCLUB INSTRUCTIONS MANUAL Contact Person: Cindy Contact Email: sales1@uszeroxclub.com...
