Summary of Contents for Monarch Water PLUMBSOFT SE-11
- Page 2 The symbol opposite means that according to United Kingdom and European Union member countries laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.
-
Page 3: Planning The Installation
/ MONARCH PLUMBSOFT SERIES WATER SOFTENER PROGRAMMING & INSTALLATION INSTRUCTIONS Thank you for choosing our water softener. Please read the following carefully, which if followed correctly, should ensure the installation is trouble free. / A. PLANNING THE INSTALLATION • Always observe the water byelaws. •... -
Page 4: Water Pressure Test
Every Softener comes with the following; 4 x 24.6mm bre washers 1 x Total Hardness test kit 1 x Drain hose 1 x 10kg bag of tablet salt • For Combi boilers upgrade hoses to high-flow hoses. - see picture right •... -
Page 5: Inlet & Outlet Connections
/ H. INLET & OUTLET CONNECTIONS DRAIN CONNECTION - See Fig 2 (black elbow under head) • Remove both salt lid and main cover to access inlet and outlet connections. • Remove grey retaining clips and also BSP connection points. Connect hoses to male BSP connection points, tighten to seal, then reinsert BSP connection points back into valve body. -
Page 6: Electrical Connection
/ L. ELECTRICAL CONNECTION BY-PASS VALVE CLOSED With the power o , connect the transformer – supplied – Fig 3 to a continuous electrical supply. Push the ying lead from the transformer into the adaptor on the lead coming from the controller. / M. -
Page 7: Set Time Of Day
/ O. SET TIME OF DAY • Wait until display says Time of Day. If Time of Day is correct, skip to P. SET HARDNESS. • Press Up button to show ashing Hours. Please note it is a 24hr clock. •... - Page 8 / SALT FILL LEVEL FILL LEVEL / R. EXTRA REGENERATIONS • To start an automatic regeneration, press the left hand button and release, the display will count down form 15 to zero. If at any time you wish to cancel the count down, simply press again.
-
Page 9: Going On Holiday
/ GOING ON HOLIDAY? • We highly recommend you bypass your softener and turn o the electrics when going away on holiday. • Set the bypass to the ‘bypass’ position. (as per Fig 3 page 6) • Reverse the above and place bypass back in Service upon your return. (Fig 4 page 6) •... - Page 10 / Hints and Tips about your new water softener 1. Make sure the electricity supply is not turned o , unless on holiday mode. 2. Please ensure that any appliances (washing machine etc.) used during ‘Economy 7’ time, do not begin their cycle between 11pm and 5am.
- Page 11 / MONARCH WATER DOMESTIC WATER SOFTENER WARRANTY -E ective September 2022 This water softener is fully covered by 5 year parts and 2 years ‘at home’ labour warranty for installation within the hard water regions of mainland England as detailed on Monarch’s National Service Coverage Area, from date of original purchase.
- Page 12 / Monarch National Service Coverage Areas - E ective June 2020 All postcodes within England and Wales are automatically covered by a parts and labour guarantee as set out in the relevant brochure for the individual model/range. / IMPORTANT Water softeners sold outside of England and Wales are to be strictly covered by a parts only ‘exchange’...
- Page 13 sales@aquacure.co.uk + 44 (0) 1704 516 916...
