- Page 1 SOF3000 HE INSTALL GUIDE...
- Page 2 / CAREFULLY SELECT THE POSITIONS FOR 1. 3 way tap – allow enough room to turn the tap for tightening. this also applies beneath the sink/ worktop when fixing the tap in position. 2. Tee type B507 saddle valve (if used) – allow enough access for your spanner when tightening both connections.
- Page 3 / INSTALLING THE TEE TYPE B507 SADDLE VALVE (IF USED) 5. Turn off your mains water supply and relieve the water pressure by opening a mains cold tap. 6. Remove 15mm of mains copper pipe where B507 is to be installed. 7.
- Page 4 / INSTALLING THE 3 WAY TAP Carefully select the site for your tap, allowing access below the sink/worktop for your spanner. 15. Drill the chosen position with a 32mm drill bit (or use pre-drilled sink hole). It is recommended to dot punch a sink top before actually drilling to prevent your drill from slipping.
- Page 5 / CONNECTING HOT AND COLD WATER 22. Connect the 2 brass fittings (right) to your 15mm hot and cold copper pipe. Applying sealant to olive as shown in the right hand picture above (installing tee type B507 saddle valve) 23. Tighten to seal using a spanner. 24.
