Summary of Contents for Monarch Water Pro-Flo CS Series
- Page 1 CS RANGE INSTALL GUIDE CS100 CS150 CS200 CS300...
- Page 2 The symbol opposite means that according to United Kingdom and European Union member countries laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.
-
Page 3: Planning The Installation
/ MONARCH PRO-FLO SERIES WATER SOFTENER PROGRAMMING & INSTALLATION INSTRUCTIONS Thank you for choosing our water softener. Please read the following carefully, which if followed correctly, should ensure the installation is trouble free. / A. PLANNING THE INSTALLATION • Always observe the water byelaws. •... -
Page 4: Installation
/ F. INTEGRATED BYPASS OPERATION Outlet Inlet Meter hole Inlet Outlet handle handle UNIT IN BYPASS UNIT IN SERVICE POSITION NOT ALLOWED Ensure bypass handles are completely open when in service to ensure no unsoftened water passes through / INSTALLATION 1. - Page 5 / G. INTEGRATED BYPASS INSTALLATION (MMB063) 1. Remove both salt lid and main cover by lifting off the salt lid and sliding the back cover backwards and lifting off, this will allow access to the inlet and outlet connections. 2. Remove the flow meter cable by unclipping it from underneath the connector assembly. 3.
- Page 6 / H. WATER PRESSURE TEST • It is IMPORTANT that a pressure check is carried out. • Low and high pressure can result in either damage to, or failure of the unit. • If daytime static water pressure* exceeds 3.5 bar (50psi) a 5 bar (70psi) pressure limiter should be fitted.
-
Page 7: Inlet & Outlet Connections
/ J. INLET & OUTLET CONNECTIONS - See Fig 2 • Remove the main cover to access inlet and outlet connections. • Remove grey retaining clips and also BSP connection points. Connect hoses to male BSP connection points, DRAIN ELBOW tighten to seal, then reinsert BSP connection points back into valve body. -
Page 8: Electrical Connection
/ N. ELECTRICAL CONNECTION With the power off, connect the transformer – supplied – to a continuous electrical supply. Push the flying lead from the transformer into the adaptor on the lead coming from the controller. / O. OBTAIN YOUR WATER HARDNESS •... -
Page 9: Set Time Of Day
/ Q. SET TIME OF DAY • Wait until display says Time of Day. If Time of Day is correct, skip to R. SET HARDNESS. • Press Up button to show flashing Hours. Please note it is a 24hr clock. •... -
Page 10: Blending Control
/ TABLET SALT FILL LEVEL FILL LEVEL / S. EXTRA REGENERATIONS • To start an automatic regeneration, press the left hand button and release, the display will count down from 15 to zero. If at any time you wish to cancel the count down, simply press again. - Page 11 / MONARCH WATER CS SOFTENER WARRANTY - Effective January 2023 This softener is fully covered by a 2 year parts and 1 year labour warranty for installation within mainland Great Britain from date of original purchase. Installations outside of these areas are automatically covered by a 12 months parts only ‘exchange’...
- Page 12 + 44 (0) 1986 784759 monarchwater.co.uk info@monarchwater.co.uk...
