Summary of Contents for Monarch Water MC-11
- Page 1 WATER SOFTENER INSTALL GUIDE MC-11...
- Page 2 The separate collection and recycling of your product and/ or its battery at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. MC-11 MC-14 MC-23 MC-30 Daily capacity is given in Litres @ 300ppm.
- Page 3 / MONARCH MC WATER SOFTENER PROGRAMMING & INSTALLATION INSTRUCTIONS Thank you for choosing our water softener. Please read the following carefully, which if followed correctly, should ensure the installation is trouble free. / A. PLANNING THE INSTALLATION • Always observe the water byelaws. •...
-
Page 4: Installation
/ F. INTEGRATED BYPASS OPERATION Outlet Inlet Meter hole Inlet Outlet handle handle UNIT IN BYPASS UNIT IN SERVICE POSITION NOT ALLOWED Ensure bypass handles are completely open when in service to ensure no unsoftened water passes through / INSTALLATION 1. - Page 5 / G. INTEGRATED BYPASS INSTALLATION (MMB063) 1. Remove both salt lid and main cover by lifting off the salt lid and sliding the back cover backwards and lifting off, this will allow access to the inlet and outlet connections. 2. Remove the flow meter cable by unclipping it from underneath the connector assembly. 3.
-
Page 6: Water Pressure Test
/ H. WATER PRESSURE TEST • It is IMPORTANT that a pressure check is carried out. • Low and high pressure can result in either damage to, or failure of the unit. • If daytime static water pressure* exceeds 3.5 bar (50psi) a 5 bar (70psi) pressure limiter should be fitted. -
Page 7: Inlet & Outlet Connections
/ J. INLET & OUTLET CONNECTIONS DRAIN CONNECTION - See Fig 2 (black elbow under head) • Remove both salt lid and main cover to access inlet and outlet connections. • Remove grey retaining clips and also BSP connection points. Connect hoses to male BSP connection points, tighten to seal, then reinsert BSP connection points back into valve body. -
Page 8: Electrical Connection
/ N. ELECTRICAL CONNECTION With the power off, connect the transformer – supplied – to a continuous electrical supply. Push the flying lead from the transformer into the adaptor on the lead coming from the controller. / O. OBTAIN YOUR WATER HARDNESS •... -
Page 9: Set Time Of Day
• Press Down button until number corresponds with chart below. • Press to confirm settings. / MC OVERIDE CHART 300ppm capacity MC-11 - 1900 MC-23 - 4180 MC-14 - 2850 MC-30 - 5700 • You have finished the programming. •... -
Page 10: Blending Control
• On all MC-11 / MC-14 / MC-23 / MC30 models, add 1 litre of water to the salt compartment on initial installation only. If at any time you see excess water in the salt compartment going down the overflow, please call your service provider. - Page 11 / Further Information • Do not worry if your softener regenerates during the day. This is the Customer Protect Programme initiating an additional mini regeneration, as the softener does not have enough soft water to last you until the next programmed regeneration. •...
- Page 12 / MONARCH WATER MC SOFTENER WARRANTY - Effective January 2023 This softener is fully covered by a 2 year parts and 1 year labour warranty for installation within mainland Great Britain from date of original purchase. Installations outside of these areas are automatically covered by a 12 months parts only ‘exchange’...
- Page 13 + 44 (0) 1986 784759 monarchwater.co.uk info@monarchwater.co.uk...
