- Page 1 Reversed 2015/2016 Integrated Multimedia&Navigation System Lexus NX series Installation Quide Quick Instruction...
-
Page 2: Table Of Contents
Make sure not damage car interior fore installation sassemble O- riginal Radio's Steps of disassemble original radio TFT kit Installation of h- Steps of install navi box with cables ost unit and wir- Assemble new Steps of assemble new product product Lexus NX series... -
Page 3: Product And Accessories
Two.Product and accessories Product and accessories list(please check):TFT kit(1pcs)*Navi box(1pcs)* Front panel plastic(1pcs)*cabels(5pcs)screws:M5*10*10mm（7pcs） screws:TM5*16mm(2pcs) left and right buckles(2pcs) Installation tools Three. Cross big screwdriver (M6*150MM) 8 mm/10 mm sleeve driver Cocking tool Cross small screwdriver Cross big screwdriver (M6*260MM) Lexus NX series... -
Page 4: Preparation Be- Fore Installation
Note: Put a towel on the surround of original car radio to prevent damaging the vehicle internal. Five.Disassemble original radio's TFT kit 1.Insert the tool from the gap to remove the left baffle slightly 2.Insert the tool from the gap to remove the right baffle slightly Lexus NX series... -
Page 5: Di Sassemble O
3.Insert the tool from the gap to remove the right front air vent slightly 4.Insert the tool from the gap to remove two baffles under ACC slightly 5.Insert the tool from the gap to remove two baffles of armrest box Lexus NX series... - Page 6 P, and the gear component is pushed back 7.Force the upper left and right to take out the central console silver fra- me component 8.Use No. 8 sleeve to remove the left and right screws on the display screen Lexus NX series...
- Page 7 LCD screen. 10.Take off the air conditioning unit slightly forward and take off plug wire 11.Use No. 10 sleeve to remove the left and right screws of the CD player Lexus NX series...
-
Page 8: Installation Of H
12.take the CD player out and take off plug wire Six.Installation of host unit and wires : 1.Take out navigation box and use 8mm sleeve to lock the 4pcs screws 2.Insert the line into the original PCB board and buckle it Lexus NX series... - Page 9 Navigation System Installation Guide Installation of host unit and wires 3.USB wire placement position and power harness 4.GPS installation position 5.Put CD player back Lexus NX series...
-
Page 10: Assemble New Product
7. Insert the wire plug and install the air conditioning unit slightly forward Seven, Assemble new product Tak two buckles from original rear plastic cover and put them into new cover.Use screw driver to take 2 screws out from sliver frame compon- ents and take off the from panel Lexus NX series... - Page 11 2.Put the new plastic shims to buckle on the left and right side of silver frame components 3.Use small screwdriver to lock the screws on left and right side 4.Put the new TFT screen into sliver frame kit. Lexus NX series...
- Page 12 Navigation System Installation Guide Assemble new product 5.Plug the wires into new TFT kit 6.Use magnetic M6*250mm srewdriver to lock 2pcs screws 7.Put on the baffles which is under ACC and left side of ACC Lexus NX series...
- Page 13 Navigation System Installation Guide Assemble new product 8.Put on the left baffle 9.Put on air vent and right baffle 10.Put on new front baffle Lexus NX series...
- Page 14 Lexus NX series Android 6.0 4G(Optional) Screen Upgrate Original Car GUI...
