PM Series Power Module
MODELS
PM-12-40, PM-12-70
PM-24-20, PM-24-35
PM-48-10, PM-48-18
TABLE OF CONTENTS
TOPIC
QUICK REFERENCE CONTENTS................................................. 3
OVERVIEW....................................................................................... 3
AC POWER QUALITY AND EMI COMPATIBILITY.................. 3
A) AC Power Quality............................................................3
B) EMI (Electro-magnetic Interference)..............................4
C) Other Factors...................................................................4
INSTALLATION............................................................................... 4
A) Materials Provided.......................................................... 5
B) Mounting..........................................................................5
C) a.c. Input Wiring and Voltage Selection..........................6
D) d.c. Output Wiring...........................................................8
E) Parallel Wiring.................................................................10
F) Chassis Grounding........................................................... 12
OPERATION..................................................................................... 12
A) a.c. Input.......................................................................... 12
B) d.c. Output....................................................................... 12
C) Cooling Fans.................................................................... 13
D) Remote Shutdown............................................................ 13
E) Local/Remote Alarm........................................................14
OPTIONS........................................................................................... 15
A) Charger Function Board................................................. 15
B) d.c. Quick Connect Kit.................................................... 16
C) a.c. Input Transient Suppressor...................................... 17
TROUBLESHOOTING.....................................................................18
SPECIFICATIONS............................................................................ 20
P.O. Box 1306
California 92663
Power Supply/Battery Charger
INSTALLATION / OPERATION MANUAL
Regulation
d.c. Fuses
Gel/Lead Acid Selector
Telecom Power Products
www.newmartelecom.com
PAGE
M-PMSER-A
As of MAY 2004
Phone: 714-751-0488
Fax: 714-957-1621
E-Mail: sales@newmarpower.com
Advertisement
Related Manuals for NewMar PM Series
Summary of Contents for NewMar PM Series
-
Page 1: Table Of Contents
PM Series Power Module Power Supply/Battery Charger INSTALLATION / OPERATION MANUAL MODELS PM-12-40, PM-12-70 PM-24-20, PM-24-35 PM-48-10, PM-48-18 TABLE OF CONTENTS TOPIC PAGE QUICK REFERENCE CONTENTS..........3 OVERVIEW..................3 AC POWER QUALITY AND EMI COMPATIBILITY....3 A) AC Power Quality............3 B) EMI (Electro-magnetic Interference)......4... -
Page 2: Quick Reference Contents
QUICK REFERENCE CONTENTS The front and rear panel features of the Power Modules are illustrated below, along with the page num- ber where information on each particular feature is located. FIGURE 1: Power Module Front Panel (all models): PM "ON' Cooling Fans, Input Switch/ Indicator LED,... -
Page 3: I) Overview
OVERVIEW The PM Series Power Module is a uniquely adaptable communication equipment power source which functions as either power supply or battery charger for 12, 24 or 48 volt d.c. systems positive, negative or floating ground. Power Modules may be employed singly or in combination, enabling the installer to scale the system output from 560 to 6,000 watts per rack. -
Page 4: B) Emi (Electro-Magnetic Interference)
INSTALLATION Two notes regarding nomenclature used in this manual 1) For the sake of brevity the PM Series Power Module is referred to simply as the PM (meaning all models, generically). 2) Where installation differences exist, reference is made to 560 watt or 1,000 watt models. -
Page 5: A) Materials Provided
560 watt models refers to: PM-12-40 PM-24-20 PM-48-10 1,000 watt models refers to: PM-12-70 PM-24-35 PM-48-18 Note: This section covers only mounting, input and output wiring. Two installation options, Remote Shutdown wiring and Local/Remote Alarm wiring, are covered in those sections in the OPERATION portion of this manual. -
Page 6: C) A.c. Input Wiring And Voltage Selection
C) a.c. Input Wiring and Voltage Selection 1) 560 Watt Models Only Input Wiring: These models are provided with an IEC power cord (in the installation kit) with a NEMA 5-15 plug for a 115V a.c. outlet on one end and a molded socket at the other which fits the entry module at the rear of the PM. - Page 7 FIGURE 4: a.c. Input Wiring Compartment (PM rear view; 1,000 watt models) Remove these screws for access a.c. Input Wiring Compartment Cover a.c Input Terminal Wiring a.c. Input Connector/Adaptor GND NEUT (115V or 230V) (LEFT) (CENTER) (RIGHT) 1) The a.c. input wiring compartment cover on the rear of the unit must be detached but not removed, so that the a.c.
-
Page 8: D) D.c. Output Wiring
D) d.c. Output Wiring Important: Ensure that a.c. input to the PM is switched off before working with d.c. wiring. The output terminals are “hot” whenever the unit is switched on. 1) Output terminals for hard-wiring of DC output are located on the rear panel of the PM. Termi- nate wires with 1/4"... - Page 9 Note: 1kW models illustrated here; refer to Figure 2 for output terminal positions of 560 watt models FIGURE 5: Single Power Module, negative ground, with battery: Typical; Fuse per N.E.C. or local codes (+) Positive to Load or Distribution Panel BATTERY (-) Negative to Load or Ground Bus Bar...
-
Page 10: E) Parallel Wiring
E) Parallel Wiring The internal oring/isolation diode of the PM allows parallel n+1 redundant wiring with no modification or other external isolation devices required. Figures 9-10 on the following page illustrate some typical parallel wiring schemes. Important: When wiring two or more units in parallel d.c. wires for all units should be identical in gauge and length and the output voltage of each module should be adjusted (as outlined below) in order to facilitate droop load sharing. - Page 11 Note: 1kW models illustrated here; refer to Figure 2 for output terminal positions of 560 watt models FIGURE 9: Parallel (two to six Power Modules) and N+1 redundancy, negative ground PM # 1 (+) Positive to Distribution Panel or Battery (fuse at battery per PM # 2 N.E.C.
-
Page 12: F) Chassis Grounding
F) Chassis Grounding If grounding of the PM chassis is required for the installation, use the provided 1/4" grounding stud on the rear panel for this purpose (see Figure 2 or 3). OPERATION A) a.c. Input The PM will operate on either 115 or 230 VAC (+15% to -25%) input at 50-60 Hz. Input voltage selection is explained in the INSTALLATION section. -
Page 13: Current Limit Circuit
If the fan fails to operate when the PM is turned on and a load is applied, it may need to be re- placed. (Replacement fans available from NEWMAR. Specify part number 999-1208-0, Replace- ment Fan with PCB connector.) -
Page 14: E) Local/Remote Alarm
2) Feed the (+) and (-) TTL signal wires through the wiring access port on the rear of the unit. 3) On the main printed circuit board, locate terminals J3 and J6 near the front of the unit. (Further identified as “SHUTDOWN” on 560 watt models only.) FIGURE 11: PCB Locations of J3 and J6 560 Watt Models 1,000 Watt Models... -
Page 15: V) Options
A color-coded wire “pigtail” with keyed plug is provided for wiring convenience and to assure proper connections. The plug holds three wires for the output fail relay. The alarm may be wired with the relay “normally open” or “normally closed”, as needed. The position of the contacts during d.c. -
Page 16: Three Stage Charging
B) d.c. Quick Connect Wiring Kit Note: This option is available only for systems which incorporate the NEWMAR Power Function Manager. For complete information on this product, please contact the factory. -
Page 17: C) A.c. Input Transient Suppressor
wiring installation of multiple Power Modules with the Power Function Manager and facilitates “hot change-out” of modules for repair or replacement. The kit consists of two wiring harness; one for positive and negative d.c. output wiring, another for alarm contact wiring. Wires are pre-cut to proper length, all necessary connectors are installed and the bundles are neatly tie-wrapped into proper position for a simple and professional installa- tion. -
Page 18: Vi) Troubleshooting
IV-B, d.c. Output.) 5. Return to place of purchase 5. Defective Power Module for repair/replacement or contact NEWMAR for return authoriza- tion. 1. Set a.c. input select switch to 1. a.c. input select switch set to B. PM repeatedly trips input... - Page 19 PM has caused other components blown blows again, return to place of PM to stop charging purchase for repair/replacement or contact NEWMAR for return authorization. Check for tight connection of D. High output voltage measured Batteries not connected to PM.
-
Page 20: Vii) Specifications
VII) SPECIFICATIONS All Models Input: 85-135/170-270 VAC (selectable), 47-63 Hz. Power Factor: 0.7 Regulation: ± 1% at V2 output; ± 2% at V OUT (through “oring” diode) Ripple P-P: 1% Efficiency: 80-85% @ full load Output Voltage Adjustment Range: ± 10 % Temperature Rating: -40°...
