PM Series Power Module
Power Supply/Battery Charger
INSTALLATION / OPERATION MANUAL
www.newmartelecom.com
Page
2
3
3
3
3
4
4
4
4
4
5
5
6
6
6
7
7
8
8
8
8
8-9
9
Advertisement
Table of Contents
Related Manuals for NewMar PM-24-80
Summary of Contents for NewMar PM-24-80
-
Page 1: Table Of Contents
PM Series Power Module Power Supply/Battery Charger INSTALLATION / OPERATION MANUAL MODELS: PM-24-80, PM-48-50 Table Of Contents Topic Page QUICK REFERENCE CONTENTS I) OVERVIEW II) AC POWER QUALITY AND EMI COMPATIBILITY B) EMI (Electro-magnetic Interference) C) Other Factors III) INSTALLATION... -
Page 2: Quick Reference Contents
Quick Reference Contents The front and rear panel features of the Power Modules are illustrated below, along with the page number where information on each particular feature is located. Figure 1: Power Module – Front Panel (2500W models) Status Indicator Lamp Power Module “On”... -
Page 3: I) Overview
filters. Power Modules may be used separately as a power source, or they may be integrated with NEWMAR’s Power Function An optional a.c. transient suppressor (see OPTIONS section) is Manager (model PFM-400; rated to 400 amps maximum) to... -
Page 4: Iii) Installation
Model Minimum Wire Size per N.E.C. AWG (mm) C) A.C. Input Wiring PM-48-50 #8 (10 mm) PM-24-80 #4 (25 mm) Input Voltage: the PM is designed to accept 207-253 VAC, 50/60 HZ, single phase input. FIGURE 3: a.c. Input Wiring Compartment (PM rear view;... -
Page 5: E) Parallel Wiring
E) Parallel Wiring To minimize line loss at lengths greater than 5 feet, it is recommended to increase wire size one gauge for each additional 5 feet of cable run. Positive and negative ground applications (with The internal oring/isolation diode of the PM allows parallel n+1 battery) –... -
Page 6: Iv) Operation
Model Output Voltage Adjustment Range the front panel. When this switch is in the on position and d.c. is PM-24-80 27.2V d.c. 24.4 - 30V d.c. available at the output terminal, the “ON” indicator L.E.D. on the left PM-48-50 54.4V d.c. -
Page 7: C) Cooling Fans
(Replacement fans available screws that attach the fan mounting bracket- do not remove these from NEWMAR. Replacement Fan with inline connector: screws. The fan mounting bracket can now be removed from the old 999-3148-0Z). -
Page 8: D) Indicators And Alarms
Note: This option is available only for systems which incorporate the FIGURE 8: “FAIL” and “OK” Relay Contact Positions NEWMAR Power Function Manager Model PFM-400. For complete information on this product, please contact the factory. A d.c. wiring harness quick connect kit model CCK-4 is available from NEWMAR which simplifies parallel wiring installation of... -
Page 9: Vii) Troubleshooting
4. Replace blown fuse (See section IV-B, 4. Blown output fuse DC fuse) 5. Defective Power Module 5. Return entire unit to place of purchase for repair/replacement or contact NEWMAR for return authorization. B. PM repeatedly trips Internal Short Return to place of purchase for...
