Installation and Operational Instructions for
®
ROBA-stop
Size 1000
Translation of the Original Operational Instructions
Please read these Operational Instructions carefully and follow them accordingly!
Ignoring these Instructions may lead to malfunctions or to brake failure, resulting in damage to other parts.
These Installation and Operational Instructions (I + O) are part of the brake delivery.
The product must be specially marked for use in areas where there is a danger of explosion.
The product will only be marked if it is ordered especially for an Ex-area.
Contents
Page 1: - Contents
- Safety and Guideline Signs
Page 5: - Safety Regulations
Page 7: - Identification
Page 8: - Brake Illustrations
Page 10: - Table 1: Technical Data
- Table 2: Braking Torque Graduations
Page 12: - Installation
Page 14: - Emergency Hand Release Actuation
- Table 3: Switching Times
Page 16: - Electrical Connection and Wiring
13/06/2023 TK/GH
Page 1 of 26
Please keep them handy and near to the brake at all times.
Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Phone: +49 8341 804-0, Fax: +49 8341 804-421
www.mayr.com, email:
Pages 21 and 22:
in
Areas Where There is a Danger of
Explosion (Dependent on Type)
Explosion and Permitted Types
- Initial Operation in
Pages 23 - 25:
- Malfunctions / Breakdowns
Page 26: - ATEX Declaration of Conformity
Safety and Guideline Signs
DANGER
Immediate and impending danger, which can
lead to severe physical injuries or to death.
CAUTION
Danger of injury to personnel and damage to
machines.
Please Observe!
Guidelines on important points.
Guidelines on explosion protection
