Summary of Contents for Jupiter Avionics wiJAC2
- Page 1 -D01 (JB68/JB69) Wireless Intercom Dropcord System N America Operating Manual Rev C Jupiter Avionics Corporation 1959 Kirschner Road Kelowna BC Canada V1Y 4N7 Tel: +1 778 478 2232 Toll-Free: 1 855 478 2232 www.jupiteravionics.com Rev B Page i...
- Page 2 All rights reserved Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for the express use of an installing agency. Any such electronic or printed copy of this manual must contain the complete text of this copyright notice.
-
Page 3: Table Of Contents
Wireless Intercom System - Wireless Dropcord - N America Operating Manual Table of Contents Introduction ..................................1 Unpacking ................................1 Verify Operating Region ............................2 Verify Pairing Registration Number ......................... 2 The wiJAC2-D01 Components ............................2 JB68-001 Headset Adapter (JB68) ......................... 3 Note: The unit is shown in grey for clarity. -
Page 4: Introduction
Not Allocated 1 = N America 2 = Europe North America: The wiJAC2-D01 consists of one JB69-001 Wireless Aircraft Intercom Adapter with TX PTT, and one JB68-001 Wireless Aircraft Headset Adapter with TX PTT. RF output power is 21dBm (125mW peak) -
Page 5: Verify Operating Region
Verify Pairing Registration Number The wiJAC2™ Wireless Intercom System consists of one set of paired Adapters. The JB68-001 Headset Adapter and JB69-001 Intercom Adapter will only operate together when paired. Refer to the Pairing Instructions in section 3.2. -
Page 6: Jb68-001 Headset Adapter (Jb68)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual JB68-001 Headset Adapter (JB68) Fig 2-1, JB68 Front View Fig 2-2, JB68 Back View VOX (Microphone Voice Operated (Phones Volume Switch Control) Control) Product Label LOW BATT PWR ON... -
Page 7: Jb68 Connectors
TX Key output is also activated. This is the user’s Transmit ‘Push To Talk’ (TX PTT) button. While this button is pressed, the wiJAC2™ system will allow the user to transmit on the transceiver selected on the audio controller. If the TX PTT button is used, the VOX threshold will be overridden (see section 2.1.1.2 above). -
Page 8: Jb68 Internal Adjustments, Annunciators And Connectors
Annunciators Battery Charge The WIJAC2-001 Battery Charge annunciators are two LEDs at the top right of the battery compartment. The Charging annunciator (CH) is a red LED that will illuminate when the batteries are being charged at the maximum charge current, and the Full Charge (F) annunciator is a green LED that will illuminate when the batteries are fully charged. -
Page 9: Jb69-001 Headset Adapter (Jb69)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual JB69-001 Headset Adapter (JB69) PWR ON Annunciator 10 Pin Hirose connector LOW BATT Annunciator ON/OFF Control Note: The units are shown in grey for clarity. Battery Lid Release... -
Page 10: Jb69 Internal Adjustments, Annunciators And Connectors
Wireless Intercom System - Wireless Dropcord - N America Operating Manual When the JB69 battery voltage is low the LOW BATT annunciator will flash once every 1.5 s and output a low battery notification (a triple beep) in the headphones once every minute until the battery charge reaches critical voltage level.(A similar but lower pitched tone will be heard if the paired JB68 Headset Adapter battery charge is low.) -
Page 11: Other Features (Both Units)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.2.4.3 Controls These buttons are recessed to prevent accidental activation. The Boot (BT) and Reset (RST) buttons should only be adjusted by qualified technical personnel. The Pair (PR) button is used during the pairing process (section 3.2.1). -
Page 12: Batteries (For Both Jb68 And Jb69)
The JB68-001 and JB69-001 each require three AA batteries. JAC recommends Duracell 800 mAh (or higher) NiMH or Duracell alkaline batteries for use in the wiJAC2™ system to obtain the typical battery life. Removal of the batteries WILL NOT change any internal configuration of the unit. -
Page 13: Battery Cautions And Warnings
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.4.4 Battery Cautions and Warnings CAUTION: Follow these guidelines to prolong battery life and minimize the risk of unit malfunction. Do not leave battery uncharged for long periods of time. -
Page 14: Connecting The Wijac2™ System
Wireless Intercom System - Wireless Dropcord - N America Operating Manual Connecting the wiJAC2™ System Note: The wiJAC2-D01 Wireless Intercom Dropcord System consists of one JB68-001 Headset Adapter 3.2.1) and one JB69-001 Intercom Adapter. Only paired units will operate together (see... -
Page 15: Wijac2™ Set-Up And Connection
Wireless Intercom System - Wireless Dropcord - N America Operating Manual wiJAC2™ Set-up and Connection 3.1.1 Insert Batteries Ensure the batteries for both units are either fully charged, and installed in the battery compartment with the correct polarity, and that the battery lid is secured (section 6). -
Page 16: Wijac2™ Adjustments And Pairing
3.2.1 Pairing Process The wiJAC2-D01 Wireless Intercom System consists of one JB69 Intercom Adapter, and one factory-paired JB68 Headset Adapter. If either the JB68 or JB69 has been replaced, it will be necessary to re-pair the units. This may also be necessary if either of the units has undergone maintenance. -
Page 17: Wijac2™System Operation
Wireless Intercom System - Wireless Dropcord - N America Operating Manual wiJAC2™System Operation Overview When both units are turned on and connected, phones audio from the aircraft audio system is transmitted from the Intercom Adapter, received by the Headset Adapter and output on the headset's phones. Microphone audio from the headset's microphone is transmitted from the Headset Adapter, received by the Intercom Adapter and output to the aircraft's audio system. -
Page 18: Battery Life
Adapter and the JB69-001 Intercom Adapter if they appear to be the cause of the fault. 4.1.8 Battery Life The operating duration of the wiJAC2-D01 system with fully charged batteries before battery replacement is required depends on the following factors: •...
