- Page 1 -002 (JB60/JB69) Wireless Intercom System - Europe Operating Manual Rev A Jupiter Avionics Corporation 1959 Kirschner Road Kelowna BC Canada V1Y 4N7 Tel: +1 778 478 2232 Toll-Free: 1 855 478 2232 www.jupiteravionics.com Rev B Page i...
- Page 2 All rights reserved Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for the express use of an installing agency. Any such electronic or printed copy of this manual must contain the complete text of this copyright notice.
-
Page 3: Table Of Contents
Wireless Intercom System - Wireless Dropcord - N America Operating Manual Table of Contents Introduction ..................................1 Unpacking ................................1 Verify Operating Region ............................2 Verify Pairing Registration Number ......................... 2 The wiJAC2-002 Components ............................2 JB60-002 Headset Adapter (JB60) ......................... 3 2.1.1... -
Page 4: Introduction
Wireless Dropcord Intercom System - N America Introduction This manual contains the operating instructions for the wiJAC2-002 Wireless Intercom Dropcord System. The diagram below describes the naming method for the different systems. System Type: 0 = Base Model wiJAC2-0 0 2... -
Page 5: Verify Operating Region
3.2. The wiJAC2-002 Components Headset Adapter Cable (CAB-HSET-0001) Audio Panel Adapter Cable (CAB-WJ2-0004) The wiJAC2-002 consists of two main components – the JB60-002 Headset Adapter and the JB69-002 Intercom Adapter. The headset is not included. Rev A Page 2... -
Page 6: Jb60-002 Headset Adapter (Jb60)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual JB60-002 Headset Adapter (JB60) JB60 Front View JB60 Back View VOX (Microphone Voice Operated (Phones Volume Switch Control) Control) Product Label LOW BATT PWR ON Annunciator Battery Lid... -
Page 7: Jb60-002 Connectors
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.1.1.3 VOL (Phones Volume Control) WARNING: Loud noise can cause hearing damage. Before using the headset, set the volume to minimum, and then slowly increase it to a comfortable listening level. -
Page 8: Jb60-002 Internal Adjustments, Annunciators And Connectors
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.1.4 JB60-002 Internal Adjustments, Annunciators and Connectors To reveal the internal adjustments, annunciators and connectors, remove the battery cover by unfastening the thumbscrew on the rear of the unit and raising the top of the cover until it can be lifted clear of the retaining tabs. -
Page 9: Jb69-002 Intercom Adapter (Jb69)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual JB69-002 Intercom Adapter (JB69) PWR ON Annunciator 10 Pin Hirose connector LOW BATT Annunciator ON/OFF Control Note: The units are shown in grey for clarity. Battery Lid Release Belt Clip 2.2.1... -
Page 10: Jb69 Internal Adjustments, Annunciators And Connectors
Wireless Intercom System - Wireless Dropcord - N America Operating Manual When the JB69 battery voltage is low the LOW BATT annunciator will flash once every 1.5 s and output a low battery notification (a triple beep) in the headphones once every minute until the battery charge reaches critical voltage level.(A similar but lower pitched tone will be heard if the paired JB60 Headset Adapter battery charge is low.) -
Page 11: Other Features (Both Units)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.2.4.3 Controls These buttons are recessed to prevent accidental activation. The Boot (BT) Pair (PR) and Reset (RST) buttons should only be adjusted by qualified technical personnel. 2.2.4.4... -
Page 12: Batteries (For Both Jb60 And Jb69)
Wireless Intercom System - Wireless Dropcord - N America Operating Manual Batteries (for both JB60 and JB69) ARNING: Charging battery types other than NiMH or NiCad may cause the batteries to leak or explode and cause damage or injury. If non-NiMH or non-NiCad batteries are installed, do not connect the Charging Port to a USB power source. -
Page 13: Battery Cautions And Warnings
Wireless Intercom System - Wireless Dropcord - N America Operating Manual 2.4.4 Battery Cautions and Warnings CAUTION: Follow these guidelines to prolong battery life and minimize the risk of unit malfunction. Do not leave battery uncharged for long periods of time. -
Page 14: Connecting The Wijac™ System
Wireless Intercom System - Wireless Dropcord - N America Operating Manual Connecting the wiJAC™ System Note: The wiJAC2-002 Wireless Intercom Dropcord System consists of one JB60-002 Headset Adapter and one JB69-002 Intercom Adapter. Only paired units will operate together (see section 3.2.1) -
Page 15: Wijac™ Set-Up And Connection
Wireless Intercom System - Wireless Dropcord - N America Operating Manual wiJAC™ Set-up and Connection 3.1.1 Insert Batteries Ensure the batteries for both units are either fully charged, and installed in the battery compartment with the correct polarity, and that the battery lid is secured (section 6). -
Page 16: Wijac™ Adjustments And Pairing
3.2.1 Pairing Process The wiJAC2-002 Wireless Intercom System consists of one JB69 Intercom Adapter, and one factory-paired JB60 Headset Adapter. If either the JB60 or JB69 has been replaced, it will be necessary to re-pair the units. This may also be necessary if either of the units has undergone maintenance. -
Page 17: Wijac™System Operation
Wireless Intercom System - Wireless Dropcord - N America Operating Manual wiJAC™System Operation Overview When both units are turned on and connected, phones audio from the aircraft audio system is transmitted from the Intercom Adapter, received by the Headset Adapter and output on the headset's phones. Microphone audio from the headset's microphone is transmitted from the Headset Adapter, received by the Intercom Adapter and output to the aircraft's audio system. -
Page 18: Battery Life
Adapter and the JB69-002 Intercom Adapter if they appear to be the cause of the fault. 4.1.8 Battery Life The operating duration of the wiJAC2-002 system with fully charged batteries before battery replacement is required depends on the following factors: Distance between Headset Adapter and Intercom Adapter: •...
