- Page 1 wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Rev. A DRAFT Page 1...
- Page 2 Copyright 2014 Jupiter Avionics Corp. All rights reserved Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for personal use. Any such electronic or printed copy of this manual must contain the complete text of this copyright notice. Any unauthorized commercial distribution of this manual is strictly prohibited.
-
Page 3: Table Of Contents
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Table of Contents Introduction ....................1 1.1 Unpacking ....................1 1.2 Verify Operating Region ................1 JA66-00x Headset Adapter (JA66) ............... 2 JA67-00x Intercom Adapter (JA67) .............. 2 Controls, Annunciators and Connectors ............3 (ON/OFF) Button –... - Page 4 wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual 6.4.6 Low Battery Warning ..............11 6.4.7 Operation during Charging ............11 6.4.8 Loss of Audio ................12 6.4.9 Battery Life ................... 12 Batteries ..................... 13 7.1 Inserting or Replacing the Batteries............13 7.2 Charging Batteries in the Unit ..............
-
Page 5: Introduction
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Introduction This manual contains the operating instructions for the wiJAC-Txx Wireless Intercom Systems. The diagram below describes the naming method for the different systems. wiJAC-T x x Operating Region: 1 = N America Number of Headsets 2 = Europe in the System (2 –... -
Page 6: Ja66-00X Headset Adapter (Ja66)
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual JA66-00x Headset Adapter (JA66) Push To Talk Buttons PWR ON Annunciator (green) ON/OFF Control LOW BATT Battery Lid Annunciator (red) Release Clothing Clip Configuration Port Charging Port Fig 2-2, JA66 Left Side View Fig 2-1, JA66 Right Side View Headset Jack VOL (Phones... -
Page 7: Controls, Annunciators And Connectors
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Controls, Annunciators and Connectors (ON/OFF) Button – Both units The ON/OFF control is a push button switch marked with the symbol and is located on the left side of the unit. To turn the unit on, press the ON/OFF button once. -
Page 8: Headset Jack - Ja66
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Headset Jack – JA66 The headset jack is a TJT120 type connector on the top of the JA66 headset adapter. Insert a U-174/U or U93A/U type Headset plug into the JA66 Headset Adapter headset jack. -
Page 9: Other
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual 4.6.3 Battery Charge (not shown) The JA66 and JA67 Battery Charge annunciators are two LEDs, one on each side of the charging port under the flexible dust cover marked PWR. The Fast Charge annunciator is a red light emitting diode (LED) that will illuminate when the batteries are being charged at the maximum charge current. -
Page 10: Pairing And Purging Process
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Pairing and Purging Process The wiJAC-Txx Wireless Intercom Systems consist of one JA67 Intercom Adapter, and up to four factory-paired JA66 Headset Adapters. Any additional Headset Adapters must be paired with the Intercom Adapter before the expanded system can function correctly. -
Page 11: Purging
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Purging A JA67 that has already been paired with four JA66 headset adapters must be purged to clear any existing pairings if it is necessary to replace one or more of the headset adapters. -
Page 12: Connecting The Wijac™ System
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Connecting the wiJAC™ System Note: The wiJAC-Txx Wireless Intercom System with Transceiver Connection consists of one JA67 Intercom Adapter and up to four JA66 Headset Adapters. Only paired units will operate together (see section The JA67 Intercom Adapter has a Female 6 Pin SR30-10R-6S (71) jack, and should be clipped to a suitable secure point. -
Page 13: Wijac-Txx System Connected To Aircraft Audio System
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual wiJAC-Txx System connected to Aircraft Audio System When connected to an aircraft audio system, the linked Headset Adapters are in an intercom loop which allows full duplex communication between the operators of each JA66. -
Page 14: Wijac™ Set-Up And Connection
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual wiJAC™ Set-up and Connection 6.3.1 Insert Batteries Ensure the batteries for all units are fully charged and installed in the battery compartment with the correct polarity, and the battery lid is secured (section 6). 6.3.2 Attach JA66 Headset Adapter and JA67 Intercom Adapter Insert a headset with a U-174/U or U93A/U type plug into the JA66 Headset... -
Page 15: Wijac™System Operation
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual wiJAC™System Operation 6.4.1 System Overviews Refer to section 6.1 for a non-aircraft radio system overview, and to section 6.2 for an Aircraft audio system overview 6.4.2 Listening Operation The Headset Adapter's Phones Volume (VOL) controls the level of audio heard in the headset's ear phones. -
Page 16: Loss Of Audio
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual 6.4.8 Loss of Audio If there is no audio heard in the headset, check the PWR ON annunciator on the JA66 Headset Adapters and the JA67 Intercom Adapter. If a unit is off, turn it on and verify connection and operation. -
Page 17: Batteries
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Batteries WARNING: Charging battery types other than NiMH or NiCad may cause the batteries to leak or explode and cause damage or injury. If non-NiMH or non-NiCad batteries are installed, do not connect the Charging Port to a USB power source. -
Page 18: Charging Operation - Via Battery Charger
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Charging Operation – via Battery Charger The batteries may be removed from the unit for charging in a separate battery charger. Removal of the batteries WILL NOT change any internal configuration of the unit. -
Page 19: Accessories
wiJAC-Txx Wireless Intercom System with Transceiver Connection Operating Manual Accessories JA72-005 Glove Box with USB connector The JA72 Glove Box with USB Charger allows the aircraft owner/operator to utilize an empty portion of the instrument panel for storage. A USB 2.0 Type A receptacle is provided to supply 5 Vdc power up to 2 Amps, and a 3.5mm stereo jack can be connected to the aircraft's audio system. -
Page 20: Warranty
• Turn the equipment off and remove from the aircraft audio system. Connect the headset to the aircraft audio system. • Consult Jupiter Avionics Corp or an experienced avionics technician for help. Note: Privacy of communications may not be ensured when using this equipment. - Page 21 Jupiter Avionics Corporation 1959 Kirschner Road Kelowna BC Canada V1Y 4N7 Tel: +1 778 478 2232 Toll-Free: 1 855 478 2232 www.jupiteravionics.com...
