OPERATING & PARTS MANUAL
Nijverheidsstraat 10
1840 Londerzeel/Belgium
Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351
Fax: +32 (0)52 315 359
E-mail: info@betontrowel.com
BE 0821.249.312
www.betontrowel.com
Beton Trowel nv
BTSP10H – BTSP10E
BNP FORTIS:
BE81 0015 9813 5624
ING:
-
GEBABEBB
BE
BBRUBEBB
Pag. 1/18
Advertisement
Table of Contents
Related Manuals for Beton Trowel BTSP10H
Summary of Contents for Beton Trowel BTSP10H
- Page 1 Beton Trowel nv OPERATING & PARTS MANUAL BTSP10H – BTSP10E Nijverheidsstraat 10 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com BE 0821.249.312...
-
Page 2: Table Of Contents
Beton Trowel nv Table of Content QUALITY ASSURANCE / MACHINE BREAK IN ........... 3 SURFACE PREPARATION SYSTEM WARRANTY ........3 MAINTENANCE RECORD ................... 4 Routine Service Intervals .................. 5 FOREWORD ......................7 SAFETY PRECAUTIONS ..................7 OPERATING PRINCIPLE ..................9 WORKING WITH THE SPS ................... -
Page 3: Quality Assurance / Machine Break In
90 days from date of purchase, provided that notice of such defective part or portion thereof is given to Beton Trowel nv Ltd. within the said period of 90 days. No further or other guarantee or warranty expressed or implied in connection with the sale of the SPS Machine is given and our sole liability consists in replacing defective parts or portions aforesaid. -
Page 4: Maintenance Record
3. MAINTENANCE RECORD PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN This Beton Trowel Preparation System has been assembled with care and will provide years of service. Preventative maintenance and routine service are essential to the long life of your SPS Machine. Your dealer is interested in your new machine and has the desire to help you get the most value from it. -
Page 5: Routine Service Intervals
Beton Trowel nv 4. Routine Service Intervals After 1.5 Each 3 Each 6 Each 9 Each 12 Each months months months months months Routine Service Intervals 50 hrs 100 hrs 200 hrs 300 hrs 400 hrs General Inspection: Guards Check... - Page 6 Beton Trowel nv The machine is generally run in very dusty conditions. Engine life will be extended by maintaining a clean engine and using a proper dust control system. Keep the air filter clean at all times. Wash the element in a non-oil based solvent. Squeeze out any residue and allow the filter to dry before reinstalling the air cleaner.
-
Page 7: Foreword
Beton Trowel nv 5. FOREWORD It is important that the following information be read carefully in order that the operational characteristics and performance of the Surface Preparation System be fully understood. Proper adherence to operation and maintenance procedures will ensure long life and top performance of your equipment. -
Page 8: Explosion Hazard
Beton Trowel nv SAFETY PRECAUTIONS DANGER EXPLOSION HAZARD Never operate the machine in an explosive atmosphere, near combustible materials or where ventilation does not clear exhaust fumes. WARNING BURN HAZARD Never come into contact with the engine or muffler when engine is operating or shortly after it is turned off. -
Page 9: Operating Principle
Beton Trowel nv 7. OPERATING PRINCIPLE The SPS employs a belt-pulley drive, for the cages which contact the surfaces to be prepared. The hand knob adjustment allows the cages to be raised or lowered as necessary to perform efficient work. The vibration isolators on the bridge make it easier on the operator and the machine, while the hexagonal drive bearing produces more positive cutter engagement. -
Page 10: Maintenance
Beton Trowel nv STARTING PROCEDURE (GAS OPERATED): * COLD CLIMATE With the machine in upright position, follow same procedure as above but allow longer warm-up period – 3 to 5 minutes. In cold weather, oil is much heavier to move and requires more time to work its way into the moving parts. -
Page 11: Storage
Beton Trowel nv DRIVE SHAFT Keep a coating of grease on the drive shaft and threads for easy installation or removal and longer bushing life. SPOT CHECKS Perform as required. Machine should be inspected with ignition in “OFF” position or power disconnected. -
Page 12: Assembly Drawings And Parts List
Beton Trowel nv 14. ASSEMBLY DRAWINGS AND PARTS LIST Nijverheidsstraat 10 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com BE 0821.249.312... -
Page 13: Handle Assembly
Beton Trowel nv HANDLE ASSEMBLY Item Description Part No. RUBBER PLUG 1001-00024-4 HANDLE WHEEL 1001-00027-4 SCREW 16060805 CYLINDER 1001-00018-1 13160004 SET SCREW 150802016 13080000 BOLT 15080300 12080000 WASHER 11082403 ADJUSTMENT TUBE 1001-02000-3 SPRING PIN 19031601 ADJUSTMENT BAR 1001-00017-1 LIFT-OFF HANDLE... - Page 14 Beton Trowel nv SPACER TUBE 1001-00013-1 BOLT 15100350 WASHER 11103003 BUSH 1001-00035-4 WHEEL SHAFT 1001-07000-3 WHEEL BALANCE 1001-00003-2 HOLDER SPRING PIN 19061603 BOLT 15100300 1001-09000-3 SPRING 1001-00023-4 KNOB 1001-00026-4 HANDLE 1001-03000-3 GRIP 70220000 Nijverheidsstraat 10 BNP FORTIS: BE81 0015 9813 5624...
- Page 15 Beton Trowel nv Nijverheidsstraat 10 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. 15/...
- Page 16 Beton Trowel nv HOUSING FOR CUTTER Item Description Part No. HONDA GX160 25160001 13080000 12080000 WASHER 11080000 NYLON WASHER 13100001 12100000 WASHER 11100000 BOLT 15080450 BASE PLATE FOR ENGINE 1001-00015-2 13100000 HANDLE BAR 1001-01000-3 BOLT 15100700 WASHER 11103003 HOUSING COVER RIGHT...
- Page 17 Beton Trowel nv BOLT 15100300 BELT COVER 1001-05000-3 WASHER 11104005 BELT 27HTD720-8M HEXAGON SHAFT 1001-00009-4 HOUSING FOR CUTTER 1001-08000-3 BOLT 15100400 BASE PLATE SUPPORT 1001-00002-2 BASE SUPPORT 1001-00001-2 GEAR 1001-06000-4 WASHER 11083003 Nijverheidsstraat 10 BNP FORTIS: BE81 0015 9813 5624...
-
Page 18: Declaration Of Conformity
Declaration of Conformity / Certificat de conformite / Gelijkvormighheidscertificaat / Declaracion de Conformidad / Declaracao de Concormidade / Dichiarazione Di Conformita Model : BTSP10H We Beton Trowel NV Declare under our sole responsibility that the product to which this declaration relates is in conformity with the following standards or other normative documents.
