- Page 1 Beton Trowel nv INSTRUCTION MANUAL POWER TROWEL BT90H160 – BT90H270 – BT90E Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com...
- Page 2 Use this guide along with the parts lists attached to locate and identify components of your trowel. When ordering replacement parts, be sure to provide the model number and serial number from the trowel. Copyright © Copyright 2011 by Beton Trowel. Contact BETON TROWEL Nijverheidsstraat 11...
-
Page 3: Foreword
We thank you for the confidence you have placed in us by purchasing a Beton Trowel machine and wish you many years of satisfied use. Nijverheidsstraat 11 BNP FORTIS:... -
Page 4: Table Of Contents
Beton Trowel nv Table of contents Foreword Operation Safety precautions ASSEMBLY INSTRUCTIONS OPERATION (Floating) OPERATION (Finishing) STARTING PROCEDURE: *WARM CLIMATE STARTING PROCEDURE: *COLD CLIMATE STOPPING PROCEDURE TRANSPORTING Lubrication Storage Maintenance Preventative maintenance and routine service plan Maintenance plan Service Labels... -
Page 5: Operation
Beton Trowel nv Operation The trowel has been developed to float and finish the edges of concrete floors, up to perimeter walls, around columns and small areas, eliminating tiring hand troweling and increasing overall productivity and quality. Safety precautions Always keep unauthorized, inexperienced, untrained people away from this machine. -
Page 6: Assembly Instructions
Beton Trowel nv ASSEMBLY INSTRUCTIONS Your new trowel has been shipped to you fully assembled. All you need to do is unfold the handle and fasten the knob. Remove any shipping or packing materials. Be sure to remove and discard the band securing the safety/stop switch to the left handle. This serves only to facilitate shipping and is not intended to be a permanent feature. -
Page 7: Operation (Finishing)
Beton Trowel nv OPERATION (Finishing) When starting the finishing operation, never set the trowels up over 1/4” pitch. After the floating operation, the first thing to do is to remove the floating disc from the blades. Clean the blades, spider plate and disc from cement paste collected during the floating operation. -
Page 8: Lubrication
Beton Trowel nv Lubrication ENGINE OIL: The long life and successful operation of any piece of machinery is dependent on frequent and thorough lubrication. Before using the trowel, always check your engine for oil. Use proper engine oil as recommended in the engine manufacturer’s manual. -
Page 9: Maintenance
Beton Trowel nv Maintenance Preventative maintenance and routine service plan. This trowel has been assembled with care and will provide years of service. Preventative maintenance and routine service are essential to the long life of your trowel. Your dealer is interested in your new machine and has the desire to help you get the most value from it. -
Page 10: Maintenance Plan
Beton Trowel nv Maintenance plan Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. -
Page 11: Service
Beton Trowel nv Service Due to the nature and environment of use, the machines could be exposed to severe operating conditions. Some general maintenance guidelines will extend the useful life of your trowel. The initial service for your trowel should be performed after 25 hours of use, at which time your mechanic (or authorized repair shop) should complete all of the recommended checks in the schedule above. -
Page 12: Labels
Beton Trowel nv Labels Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. 12/19... -
Page 13: Specifications
Beton Trowel nv Specifications Technical data sheet MODEL BT90H160 BT90H270 BT90E OPERATING 90 CM (36”) 90 CM (36”) 90 CM (36”) DIAMETER ELECTRIC 3 PHASE HONDA GX160 HONDA GX270 ENGINE OPTIONS 2.2 KW 5.5 HP 9 HP VARIABLE SPEED RIGID TRI-TUBE... -
Page 14: Parts
Beton Trowel nv Parts Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. 14/19... - Page 15 Beton Trowel nv Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. 15/19...
- Page 16 Beton Trowel nv Nijverheidsstraat 11 BNP FORTIS: BE81 0015 9813 5624 GEBABEBB 1840 Londerzeel/Belgium ING: BBRUBEBB Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 Fax: +32 (0)52 303 739 E-mail: info@betontrowel.com BE 0821.249.312 www.betontrowel.com Pag. 16/19...
-
Page 17: Bnp Fortis: Be81 0015 9813 5624 Gebabebb
Beton Trowel nv PART NO. DESCRIPTION QTY. 4365000 HANDLE ASSY COMPLETE 4365100 HANDLE BAR 4365200 SAFETY SWITCH CENTRIFUGAL 4365301 UPPER HANDLE BRACKET 4365302 LOWER HANDLE BRACKET 4365400 THROTTLE CONTROL ASSY 4365501 PITCH CONTROL KNOB 4365502 BEARING 4365503 THREADED ROD 4365504... - Page 18 Beton Trowel nv 9039 WASHER 9040 BOLT 9041 BOLT 9042 SCREW 4364000 GEARBOX ASSY 4364003 GEARBOX CASING 4364005 GEARBOX COVER 4364006 WASHER 4364007 FLAT HEAD SCREW, MAIN SHAFT 4364008 PLASTIC SHIMMING 4364010 BRONZE GEAR 4364011 MAIN SHAFT 4364012 LEFT BEARING FLANGE...
- Page 19 Beton Trowel nv 4363000 CLUTCH ASSY 4363001 SPINDLE 4363002 DRUM 4363003 FACE PLATE 4363004 WEIGHT 9075 BEARING 9076 9077 SPRING 9079 LOCK SCREW 4366000A SPIDER ASSY COMPLETE 4366001 TROWEL ARM 4366004 BUSHING, SPIDER RETAINER BOLT 4366005 SPIDER PLATE 4366006 LIFT LEVER...
