Beton Trowel nv
INSTRUCTION MANUAL
RIDE ON POWER TROWEL
–
BT120H-2/5/PFV37
Nijverheidsstraat 10, 1840 Londerzeel/Belgium
Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359
E-mail:
info@betontrowel.com
-
www.betontrowel.com
BE 0821.249.312
BNP FORTIS:
BE81 0015 9813 5624
BBRUBEBB
Page 1
Advertisement
Table of Contents
Related Manuals for Beton Trowel BT120H-2/5/PFV37
Summary of Contents for Beton Trowel BT120H-2/5/PFV37
-
Page 1: Instruction Manual
Beton Trowel nv INSTRUCTION MANUAL RIDE ON POWER TROWEL – BT120H-2/5/PFV37 Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624... - Page 2 Use this guide along with the parts lists attached to locate and identify components of your trowel. When ordering replacement parts, be sure to provide the model number and serial number from the trowel. Copyright © Copyright 2011 by Beton Trowel. Contact BETON TROWEL...
-
Page 3: Foreword
We thank you for the confidence you have placed in us by purchasing a Beton Trowel Ride-on Trowel and wish you many years of satisfied use. -
Page 4: Table Of Contents
Beton Trowel nv 2. T ABLE OF CONTENTS INSTRUCTION MANUAL ............................. 1 Foreword ..............................3 Table of contents ............................4 Safety Precautions ............................. 6 Operating Instructions ..........................7 Starting procedures – warm temperatures ....................7 Starting procedures – cold temperatures ..................... 7 To Stop engine ............................... - Page 5 Beton Trowel nv Gearbox Assembly (Left) ......................... 24 Gearbox Assembly (Right) ........................27 Fuel- & Water System ..........................30 Declaration of Conformity / Certificat de conformite / Gelijkvormighheidscertificaat / Declaracion de Conformidad / Declaracao de Concormidade / Dichiarazione Di Conformita ..........35...
-
Page 6: Safety Precautions
Beton Trowel nv 3. S AFETY RECAUTIONS ❖ Always keep unauthorized, inexperienced, untrained people away from this machine. ❖ Rotating and moving parts will cause injury if contacted. Make sure guards are in place. Keep hands and feet away from moving parts. -
Page 7: Operating Instructions
Beton Trowel nv 4. O PERATING NSTRUCTIONS – TARTING PROCEDURES WARM TEMPERATURES ❖ Ensure the Battery Isolator switch is turned on. It is a Red Key located on top of the machine to the left of the operator ❖ Prior to starting the trowel, check the engine and gearbox oil levels. Be sure the fuel tank is full. -
Page 8: Steering
Beton Trowel nv TEERING Guiding the machine on the slab is quite simple but does require some familiarity before actually working with the machine. The controls respond as shown in figure 2a below. Test the machine on a finished Section of the floor, with the... -
Page 9: Float/Trowel Pitch Setting
After reading through this manual thoroughly, you will find that you can do some of the regular maintenance yourself. However, when in need of parts or major service, be sure to see Beton Trowel. GENERAL •... -
Page 10: Air Cleaner
Beton Trowel nv AIR CLEANER Maintaining a clean engine will extend engine life. Keep air filter clean at all times. Clean air filter using the recommended solvent. See engine manual for proper cleaning procedure. Let the filter dry before reinstalling. -
Page 11: Lubrication
Beton Trowel nv UBRICATION ENGINE OIL The long life and successful operation of any piece of machinery is dependent on frequent and thorough lubrication. Before using the trowel, always check your engine for oil. Use proper engine oil as recommended in the engine manufacturer’s manual. -
Page 12: Service
Beton Trowel nv ERVICE Due to the nature and environment of use, power trowels are exposed to severe operating conditions. Some general maintenance guidelines will extend the useful life of your trowel. ❖ The initial service for your power trowel should be performed after 25 hours of use, at which time your mechanic (or authorized repair shop) should complete all of the recommended checks in the schedule above. -
Page 13: Labels
Beton Trowel nv 6. L ABELS Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 13... -
Page 14: Electrical Wiring Scheme
Beton Trowel nv LECTRICAL WIRING SCHEME Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 14... -
Page 15: Parts
Beton Trowel nv 7. P ARTS RAMEWORK Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB... - Page 16 Beton Trowel nv Item No. Part No. Description Qty. 836H0453F SEAT 846G8200 SEAT PLATE 9271 BLOCKING SWITCH 9641 LIGHT SWITCH 846GH8100 UPPER FRAME 846B080021 SCREW 9909 HOUR METER 846GH8405 FRONT PANEL 9678 GRIP 9346 QUICK RELEASE HASP 1046H8301 SEAT FASTERNER...
-
Page 17: Guard Ring
Beton Trowel nv UARD Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 17... - Page 18 Beton Trowel nv Item No. Part No. Description Qty. 8360592a THROTTLE PEDAL 8360592C PEDAL CONNECTING 846G4200 SUPPORT 846G4001 CONNECTING ROD 846GH8504 PLATE 8361426 CONNECTOR 8361431 CONNECTOR 8361428 CONNECTOR 846G7111 PLATE 9970 LED LIGHT 846GH1100 GUARD RING 846G8404 PANEL 8360464 BATTERY BOX...
-
Page 19: Power System
Beton Trowel nv OWER YSTEM Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 19... - Page 20 Beton Trowel nv Item No. Part No. Description Qty. 31000046 VANGUARD 37HP 846A030005 BUSHING 846G8500 BELT GUARD 846G3100 TENSIONER MOUNTING 846A030200 TENSIONER ADJUSTING 9974 BELT 9101 SCREW 846G3002 PULLEY 846A030003 TENSIONER 8360529 BOLT 846A030006 SPACER 84603A0 CLUTCH 9471 CIRCLIP 84603A1...
-
Page 21: Steering System
Beton Trowel nv TEERING YSTEM Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 21... - Page 22 Beton Trowel nv Item No. Part No. Description Qty. 846A055000 PITCH CONTROL ASSY B8360470 PITCH HANDLE 9157A 9025 BEARING 846A050004 BUSHING 4365504 SPACER 9027 CIRCLIP 4365503 ADJUST SHAFT 9033 WASHER 846GH5400 BRACKET, LEFT 846G5100 HANGING BRACKET, LEFT 846A060000L GEARBOX, LEFT...
- Page 23 Beton Trowel nv 9022 SPRING WASHER 9093 BOLT 846A050007 CONNECTOR Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624...
-
Page 24: Gearbox Assembly (Left)
Beton Trowel nv EARBOX SSEMBLY Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 24... - Page 25 Beton Trowel nv Item No. Part No. Description Qty. 846A060001 GEARBOX CASING, LEFT 846A060003 GEARBOX COVER 846A060100 BRONZE GEAR, LEFT 846A060009 COUNTER SHAFT, LEFT 846A060005 MAIN SHAFT, LEFT 846A060011 SHIMMING 846A060004 PRESSURE WASHER 846A060012 SHIMMING 846A060007 BEARING FLANGE 846A060008 BEARING FLANGE...
- Page 26 Beton Trowel nv 9540 SCREW 9066 BOLT 9037 SPRING WASHER 9046 SPRING WASHER 9059 9067 SCREW 9068 SCREW 9069B GREASE NIPPLE 9469 BEARING 9040 BOLT 9215 BOLT 9072 PLUG 9147 SCREW 4466100G BLADE 9038 WASHER 846A060013 RELEASE VALVE 846A060014 846A060000L...
-
Page 27: Gearbox Assembly (Right)
Beton Trowel nv EARBOX SSEMBLY IGHT Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 27... - Page 28 Beton Trowel nv Item No. Part No. Description Qty. 846A060002 GEARBOX CASING, RIGHT 846A060003 GEARBOX COVER 846A060200 BRONZE GEAR, RIGHT 846A060010 COUNTER SHAFT, RIGHT 846A060006 MAIN SHAFT, RIGHT 846A060011 SHIMMING 846A060004 PRESSURE WASHER 846A060012 SHIMMING 846A060007 BEARING FLANGE 846A060008 BEARING FLANGE...
- Page 29 Beton Trowel nv 9540 SCREW 9066 BOLT 9037 SPRING WASHER 9046 SPRING WASHER 9059 9067 SCREW 9068 SCREW 9069B GREASE NIPPLE 9469 BEARING 9040 BOLT 9215 BOLT 9072 PLUG 9147 SCREW 4466100G BLADE 9038 WASHER 846A060013 RELEASE VALVE 846A060014 846A060000R...
-
Page 30: Fuel- & Water System
Beton Trowel nv - & W ATER YSTEM Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624... - Page 31 Beton Trowel nv Item No. Part No. Description Qty. FT8360710 TANK HOOP B8361073PL FUEL TANK B8360731 MOUNTING PLATE 8361071 JOINT 10202003 WATER PIPE 9516 SCREW 9517 SOLENOID PILOT ACTUATED 8361142 VALVE 9230 SCREW 9128 SPRING WASHER 8361067 WATER PUMP 8361476...
- Page 32 Beton Trowel nv Nijverheidsstraat 10, 1840 Londerzeel/Belgium Tel: +32 (0)52 315 350 - Tel: +32 (0)52 315 351 - Fax: +32 (0)52 315 359 E-mail: info@betontrowel.com www.betontrowel.com BE 0821.249.312 BNP FORTIS: BE81 0015 9813 5624 BBRUBEBB Page 32...
- Page 33 Beton Trowel nv Item No. Part No. Description Qty. 846GH2800 HYDRAULIC OIL TANK 846G2200A CONNECTING PLATE 9500 BEARING 9501 BEARING 836H2600A HYDRAULIC CYLINDER 1046H2600C HYDRAULIC CYLINDER 836H-FJ8 SHIMMING 836H-FJ3 PLATE 846A020003 SHAFT 9827 CONNECTOR 9817 CONNECTOR 9822 JOINT 9823 JOINT...
- Page 34 Beton Trowel nv 846GH2805 OIL PIPE 846GH2806 OIL PIPE 846GH2807 OIL PIPE 846GH2808 OIL PIPE 846GH2809 OIL PIPE 846GH2810 OIL PIPE 846GH2811 OIL PIPE 846GH2812 OIL PIPE 846GH2813 OIL PIPE 846GH2814 OIL PIPE 846GH2815 OIL PIPE 9801Y HYDRAULIC CONTROL LEVER...
-
Page 35: Declaration Of Conformity / Certificat De Conformite / Gelijkvormighheidscertificaat / Declaracion De Conformidad / Declaracao De Concormidade / Dichiarazione Di Conformita
ECLARACAO DE ONCORMIDADE ICHIARAZIONE ONFORMITA Model : BT120H-2/5/PFV37 We Beton Trowel NV Declare under our sole responsibility that the product to which this declaration relates is in conformity with the following standards or other normative documents. Declarons sous notre responsabilite que le produit cette declaration est conforme aux norms suivantes ou d’autres documents habituels.
