2. Attach four screws to the wall using the screw-locator pattern shown here. Photocopy the pattern to use
as a template. Use screws with head sizes small enough to fit in the center of each of the four holes but
large enough not to pop out of the elongated sections. Leave 1/8" of the screw shanks behind the heads
sticking out of the wall.
3. Tilt the antenna fully back on the base. Place the antenna base on the four screw heads with the antenna
pivot at the top and pull down approximately 1/4" until the base is firmly secured. Note that the XM
logo will be upside down when the antenna is properly installed.
4. Tilt the antenna away from the wall/base until the signal is optimized.
Note: Do not cut the antenna cable and attempt to splice it or attach alternative connectors or cable. The cable and connectors
used in your receiver's home kit are specially chosen and attached at the factory to ensure that they will work with XM's
unique frequency band. Use an XM-approved extension kit (Delphi model number SA10006) with your receiver.

Using the Delphi Audio System

Once the Delphi Audio System is set up and the SKYFi/SKYFi2 or roadyXT Receiver installed, the complete
setup can be controlled as described in the receiver's operating guide.
Unique Delphi Audio System features include the following:

Volume

Volume can be adjusted using the volume knob on the Delphi Audio System. In addition, when the receiver
is connected to the Delphi Audio System, the + and - controls on the remote control can also be used to
increase (+) and decrease (-) volume.
8
Photocopy this diagram of the screw-locator
pattern on the bottom of your XM Antenna to use
as a template for wall attachment.
