Using SKYFi/SKYFi2 with the Delphi Audio System

1. Insert the SKYFi/SKYFi2 Receiver (sold separately)
into the cradle by first pressing in on the back of the
black inset cradle in the Delphi Audio System. Then
letting the cradle tilt forward, carefully slide the
SKYFi/SKYFi2 Receiver down into the tray so that the
alignment tabs on the sides of the tray line up with
the slots on SKYFi/SKYFi2 and the connector is com-
pletely seated. Push on the top center above the
display of the SKYFi/SKYFi2 Receiver so that it tilts
back into the Delphi Audio System until a click is
heard. The SKYFi/SKYFi2 Receiver can be removed by
reversing this process.
2. Power up the Delphi Audio System combination by
powering up the SKYFi/SKYFi2 Receiver using the power
button on the receiver or on the remote control.
3. If the display reads "ANTENNA" after powering up,
check that the antenna connection is secure and
completely pushed in. Next, change channels (from 0 to 1 or from 1 to 0 if the receiver is not authorized
yet). If the "ANTENNA" message remains, power down the radio, unplug the antenna, and look for any
obvious damage in the connector, jack, or antenna cable. If no damage is detected, reconnect the
antenna, turn the unit back on, and change channels again. If the message still appears, contact your
retailer.
4. If the display reads "NO SIGNAL" after powering up, follow the instructions in "Setting up the Antenna"
on page 6.

Using roadyXT with the Delphi Audio System

1. Insert the roadyXT Receiver (sold separately) into the adaptor included with the Delphi Audio System
until snug.
Caution: Do not use excessive force when inserting the receiver into the cradle. Doing so could cause
damage to the unit.
2. Insert the adaptor containing the roadyXT into the cradle by first pressing in on the back of the black
inset cradle in the Delphi Audio System. Then letting the cradle tilt forward, carefully slide the adaptor
down into the tray so that the alignment tabs on the sides of the tray line up with the slots on the
adaptor and the connector is completely seated. Push on the top
center above the display of the adaptor so that it tilts back into the
Delphi Audio System until a click is heard. The roadyXT Receiver
adaptor can be removed by reversing this process.
3. Power up the Delphi Audio System combination by powering up the
roadyXT Receiver using the power button on the receiver or on the
remote control.
4. If the display reads "ANTENNA" after powering up, check that the
antenna connection is secure and completely pushed in. Next,
change channels (from 0 to 1 or from 1 to 0 if the receiver is not
authorized yet). If the "ANTENNA" message remains, power down
the radio, unplug the antenna, and look for any obvious damage in
the connector, jack, or antenna cable. If no damage is detected,
reconnect the antenna, turn the unit back on, and change chan-
nels again. If the message still appears, contact your retailer.
5. If the display reads "NO SIGNAL" after powering up, follow the
instructions in "Setting up the Antenna" on page 6.
