What's In The Box; Setting Up The Delphi Audio System - Delphi SA10201 - Boom Box Audio System Installation And Operation Manual

What's in the Box

Your Delphi Audio System Kit contains the following components:
Battery compartment and
antenna cable storage

Setting up the Delphi Audio System

Set up your Delphi Audio System by
following these steps:
1. Connect the supplied 12V DC power
adaptor to the jack on the rear of
the Delphi Audio System, and the
other end to a wall outlet.
2. Connect the XM Antenna to the
antenna jack located inside the bat-
tery compartment and antenna
cable storage located on the bottom of the Delphi
Audio System. The cover must first be removed
by pressing down on the two tabs with your
thumbs and then sliding it away from the front of
the Delphi Audio System. The antenna cable can
either be completely wound around the two cable
hooks in the compartment, leaving just enough
cable to attach the antenna to the four tabs on
the back of the Delphi Audio System, or the
entire 20' cable can be used to position the
antenna away from the Delphi Audio System for
better reception. To reattach the panel, line up
all six tabs and then slide the panel toward the
front of the unit until a click is heard. Make cer-
tain that all six tabs are engaged and the rear of
the panel is aligned with the rear cover.
4
12V DC adaptor
12V DC jack
XM Antenna
