Summary of Contents for Delphi SA10034-11B1
- Page 1 CD audio system Owner’s Manual This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. SA10034-11B1 Requires a subscription from XM Satellite Radio.
-
Page 2: Owner's Record
The model number is located at the bottom and the serial number is located on the label at the back of the Delphi CD Audio System. Record the serial number in the space provided below. Refer to these numbers when contacting your dealer regarding this product. -
Page 3: Table Of Contents
Reference Caring for Your Delphi CD Audio System ..12 Precautions ......12 Troubleshooting . -
Page 4: Delphi Cd Audio System
• Retract the telescoping FM antenna and snap it into its storage well COMPONENTS The following components are included with your Delphi CD Audio System: Figure 1: Delphi CD Audio System – Front View (SKYFi Module) Speakers (L and R) SKYFi cradle (SKYFi Receiver sold... -
Page 5: Key Functions
Volume key. SNOOZE stops CD/MP3 or AM/FM play for 7 minutes when the Delphi CD Audio System is set to function as an alarm clock. NUMBER KEYS 0-9 provide direct access to stored stations in AM/FM mode and programmed tracks in CD/MP3 mode. -
Page 6: Cd/Mp3, Am/Fm, Clock Module Playing Audio Cd Or Mp3 Files
Total directory numbers 22 DIR Total track numbers 185 TRK Figure 7: Initial MP3 Display **Recording MP3 files for the Delphi CD Audio System may require the use of “Full Version” CD-burning software packages (e.g., EasyCD Creator or Nero ™... -
Page 7: Random Play (Remote Control Only)
Figure 11: Elapsed Playback Time – MP3 Playback Display ID3 Information (MP3 Only) The Delphi CD Audio System conforms to Version 1.1 of the ID3 tag format. ID3 information (song title, artist name, and album name) can be displayed for CD/MP3 files created with this information. -
Page 8: About Mp3
Each file, or track, is compressed to one-tenth of its original size. In order to play MP3 files in the Delphi CD Audio System, files must have been created according to the following requirements: Usable media –... -
Page 9: Clock Functions
OFF or to program to shut off after playing for 30, 60, 90, or 120 minutes. SKYFI MODULE With the Delphi CD Audio System and your XM SKYFi Receiver (Delphi model number SA10000, sold separately), it’s easy to enjoy XM Satellite Radio programming wherever you go! (Subscription required. -
Page 10: Positioning The Xm Antenna
9 for positioning the XM antenna and optimizing its signal. Once the Delphi CD Audio System is set up and the SKYFi Receiver is inserted in its cradle, refer to the SKYFi Operating Guide for complete system opera- tion and control information. -
Page 11: Optimizing Antenna Signal
XM repeater coverage, or when receiving a strong signal indoors, you can mount the XM antenna directly on the back of the Delphi CD Audio System. 1. Wind the antenna cable around the tab on the back of the lower tube, leaving several inches of cable free. -
Page 12: Controlling Volume, Bass, And Treble
Note that the “Line Out” level cannot be reset while the SKYFi Receiver is in the Delphi CD Audio System since the volume control should be used to control the audio output. If the line out setting is adjusted... -
Page 13: System Sound Output Options
To preserve battery life, the A/C adaptor is recommended as the primary power source for the Delphi CD Audio System. A 12V D/C adaptor (Delphi model number SA10033) is also available for use with 12V D/C portable power sources or from a parked vehicle. -
Page 14: Reference Caring For Your Delphi Cd Audio System
30 days when left unused in the Delphi CD Audio System.) Placement • Place the Delphi CD Audio System on a flat and stable surface to reduce the risk of the unit falling and breaking. • Protect the Delphi CD Audio System from the direct rays of the sun, which can damage the unit. -
Page 15: Troubleshooting
• Check battery strength; if they are weak, replace all batteries with new ones. • Confirm that the desired function appears in the display; if not, adjust the mode of your Delphi CD Audio System. • Adjust the volume. • Unplug the headphones. -
Page 16: Contacting Customer Service
Wait until the CD panel or SKYFi Receiver display clears completely, then plug the A/C power adaptor back in and re-insert batter- ies. If this does not fix the problem, contact Delphi at 1.877.GO DELPHI (1.877.463.3574) Monday through Friday. -
Page 17: Warranty
CONSUMER WARRANTY Delphi Product and Service Solutions (“Delphi”) warrants all Portable XM Satellite Radio Products sold by Delphi (“Products”) to be free of defects in material and workmanship, subject to the following conditions. The duration of Delphi’s warranty with respect to... -
Page 18: For Customers In The United States
Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Delphi could void the warranty. - Page 19 1441 West Long Lake Road Troy, Michigan 48098-5090 U.S.A. Customer Service: [1] 877.GO DELPHI www.delphi.com The SKYFi name, XM name, and related logos are trademarks of XM Satellite Radio Inc. Printed on Recycled Paper ©2003 Delphi Corporation. All rights reserved. DPSS-03-E-XXX...
