- Page 1 SKYFi Audio System & Installation Operation Guide This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Delphi could void the user’s authority to operate this equipment.
-
Page 3: Table Of Contents
Table of contents SKYFi Audio System Set-Up……….……………..…….….4 Antenna Set-Up……………......……..…...….….6 Using the SKYFi Audio System………..………..…..…...……8 Precautions………….. …………………………...….…..……...10 Troubleshooting…………………………………..……..……...11 Maintenance……………………………………...………..…..11 Specifications……………….………………………...….……...12... -
Page 4: Skyfi Tm Audio System Set-Up
SKYFi Audio System Set-Up Your SKYFi Audio System Kit contains the following components: 12V. DC Adaptor Antenna Battery compartment and 12V. DC jack antenna cable storage Set-up your SKYFi Audio System as follows: 1. Connect the supplied 12V DC power adapter to the socket on the rear of the Audio System, and the other end to a wall outlet. - Page 5 3. Insert the SKYFi Receiver (sold separately) by first pressing in on the back of the black inset cradle in the Audio System and then letting the cradle tilt forward, carefully slide the SKYFi Receiver down into the tray so that the alignment tabs on the sides of the tray line- up with the slots on SKYFi and the connector...
-
Page 6: Antenna Set-Up
3. Insert six D size (R20) batteries into the battery compartment. Make sure that the batteries are facing the correct direction by verifying that the positive (+) and negative (-) symbols in the battery compartment match up with the same symbols on the batteries. 4. - Page 7 Your antenna comes with 20 feet of cable. If that is not sufficient to locate the antenna where there is a strong XM signal, purchase a 50-foot cable extension (Delphi model number SA10006) from your SKYFi retailer. Up to eight extensions can be used together for up to 40 0 total feet of cable.
-
Page 8: Using The Skyfi Audio System
2. Attach four screws to the wall using the screw-locator pattern in figure 6. Photocopy the pattern to use as a template. Use screws with head sizes small enough to fit in the center of each of the four holes but large enough not to pop out of the elongated sections. - Page 9 Volume Volume can be adjusted using the volume knob on the SKYFi Audio System. In addition, when the SKYFi Receiver is con- nected to the Audio System, the + and – controls on the remote control can also be used to increase (+) and decrease (-) the volume.
-
Page 10: Precautions
Precautions: 1. On power sources. For AC operation, it is recommended that only the supplied AC power adaptor is used; If you need to use another one, make sure it is a 12V, 1500mA DC adaptor with a unified polarity-type jack. The satellite radio unit (SKYFi ) is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet, even if the satellite radio unit (SKYFi... -
Page 11: Troubleshooting
The supplied AC power adaptor is not water resistant. To prevent shock hazard, avoid using the SKYFi Audio System near water during AC operation. Water in the headphone jack may cause rusting and possible malfunction. Troubleshooting General: 1. The power is not on. Connect the AC power adaptor to a wall outlet securely and make sure the wall outlet has the 110V AC output. -
Page 12: Specifications
Specifications SPECIFICATION ITEM REMARK UNIT Nominal Limited Continuous Average power > 4 > 3.5 Rated Output (10%) at 1 KHz Output Total Harmonic Total Harmonic Frequency: Frequency: > 0.6 > 0.6 > 1.0 > 1.0 Output: 0.5w Output: 0.5w Distortion Distortion 70Hz - 20KHz 70Hz - 20KHz... - Page 13 1441 West Long Lake Road Troy, MI 48098-5090 Technical Assistance: [1] 877.GO DELPHI Customer Service: [1] 866.227.9071 www.delphi.com The SKIFi name, XM name, and related logos are trademarks of XM Satellite Radio Inc. 2002 Delphi Corporation. All rights reserved. DAO-02-E-103...
