Erreka PYRENE Installation Manual

Erreka PYRENE Installation Manual

Articulated arm opener 24v dc gear motor
Hide thumbs

Advertisement

Quick Links

Download this manual
PYRENE
ARTICULATED ARM OPENER
24V DC GEAR MOTOR
RESIDENTIAL USE
INSTALLATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PYRENE and is the answer not in the manual?

Questions and answers

Related Manuals for Erreka PYRENE

Summary of Contents for Erreka PYRENE

  • Page 1 PYRENE ARTICULATED ARM OPENER 24V DC GEAR MOTOR RESIDENTIAL USE INSTALLATION MANUAL...
  • Page 2 (10) The system can only work in good working condition. Always follow standard procedures following the instructions in this installation and operation manual. ERREKA will not be responsible for any injury, damage, or any claim to any person or property that may result from the improper use or installation of this system.

  • Page 3: Outward Opening

    2x1.5 mm² 4x0.5 mm² TX- 2x0.5 mm² RX- 4x0.5 mm² 3x1.5 mm² 2x1 mm² + 3x0.5 mm² 1. 24V DC flashing lamp(LUMI) IMPORTANT: Gate TC stop on closing and TA stops on opening must be 2. Push Button installed. 3. Photocells(FT06) * Using an electrolock for full panel leaves 4.
  • Page 4 Straight arm 1 pce Curved arm 1 pce U-shaped fixing plate 1 pce Mechanical stopper 2 pcs Front-end fixing bracket 1 pce Screw 4 pcs Nut Ø10 2 pcs Screw 2 pcs Gasket 2 pcs Screw 2 pcs Spring washer 4 pcs Nut Ø8 4 pcs...
  • Page 5 3) Install the motor on the U-shaped fixing 4) After positioning the front of curved arm on the bottom of motor, plate with corresponding screws and nuts. release the motor and position the straight arm on the end of curved arm and mounting bracket with corresponding screws and nuts.

  • Page 6: Specification

    1) Insert the release key to the release slot 2) Turn the release key anti-clockwise 3) Pull out the release bar 4) Turn the release key clockwise to fix the release bar, the release bar has to be in pulled out position when turning the release key clockwise The safety photocells are security devices for control automatic gates.
  • Page 7 A.P. Single-leaf opening pushbutton DEST Flashing light (ERREKA LUMI) Configure DIP1 as shown in figure DEST (LUMI) Exterior safety device (ERREKA FT06 photocell) Interior safety device (ERREKA FT06 photocell) (FT06) (FT06) P307Z Please kindly notice that the operation of power connection...
  • Page 8 Figure 2(1) Connections photocells in detail, see page 5 Push Button ST2 Key Switch ST1 Lock Lamp 25 24 22 21 20 19 17 16 14 13 11 10 PhVcc Ph2 GND PhVcc Ph1 GND SKey DKey GND Lmt4 Lmt3 GND Lmt2 Lmt1 GND S2 M2- M2+ M1- M1+ Lat- Lat+ Lit- Lit+ LED3 LED4 LED2...
  • Page 9 2.1.1 Figur 2(2) Motor1 Power Motor2 Power Motor Motor Motor (standard) Figur 2(3) Limit Switch Limit Switch Motor1 Power Motor2 Power Limit1 Limit2 Limit4 Limit3 Remark: i L L i L L ARTICULATED ARM OPENERS - INSTALLATION MANUAL...
  • Page 10 2.1.2 Figur 2(5) Motor2 Power Motor1 Power Mo o o tor otor (standard) Figur 2(6) Limit Switch Limit Switch Motor2 Power Motor1 Power Limit4 Limit3 Limit1 Limit2 Remark: ) t i ARTICULATED ARM OPENERS - INSTALLATION MANUAL...
  • Page 11 LED Blue on receiver: Flashes 3 times when transmitter memory has completely expired. LED2 External device: When key switch or push button is activated, LED2 will light. LED3 Photocells Ph2: LED3 will light when first pair of photocells FT2 were activated. LED4 Photocells Ph1: LED4 will light when first pair of photocells FT1 were activated.
  • Page 12 Figur 2(8) A. Double leaf (1) Slave Gate (M2) Close → (2) Master Gate (M1) Close → (3) Master Gate (M1) Open → (4) Slave Gate (M2) Open → (5) Slave Gate (M2) Close → (6) Master Gate (M1) Close B.
  • Page 13 Press the “A” button on the transmitter for double leaf operation. Press the “B” button on the transmitter for single leaf operation in either single or double leaf installations. (A) During door opening: the doors stop if the transmitter/pushbutton/key selector button is activated, and close when it is pressed again.
  • Page 14 Safefy Device1 Safefy Device2 Photocell FT1-CLOSE Photocell FT2-OPEN Safefy Device1 Photocell FT1-CLOSE Safefy Device1 Photocell FT1-CLOSE Safefy Device1 Safefy Device2 Photocell FT1-CLOSE Photocell FT2-OPEN/CLOSE ARTICULATED ARM OPENERS - INSTALLATION MANUAL...
  • Page 15 (1) Press “SET” 3 seconds, and the screen will show F1. (*) To enter “F2” function or other function, press “UP” button to 1. select parameters between F2 and FI. (2) After completing step (1) press “SET” button again, the second option will appear.
  • Page 16 F11 : F12 : (standard) F13 : F21 : F22 : F31 : 2A F32 : 3A F33 : 4A F34 : 5A F41 : 100% F42 : 80% F51 : F52 : F61 : 70% F62 : 50% F63 : 35% F64 : 25% F71 : 2 F72 : 3...
  • Page 17 FA0 : FA1 : open the single leaf with the B button on the emitter FB0 : without pre-warning; the lamp lights up and the door starts to move simultaneously FB1 : with 3 second pre-warning; the lamp lights up and the door does not start to move until 3 seconds have passed FT1 photocells (external)
  • Page 18 Leaves stop suddenly during operation ARTICULATED ARM OPENERS - INSTALLATION MANUAL...

  • Page 19: Technical Characteristics

    5.2 Technical Characteristics PY2524EC (with control)+ PY2524C (without control) Model Motor 24Vdc motor Gear type Electromechanical worm gear Nominal thrust 2500N Maximum Gate Weight 250 kg per leaf Maximum Gate Length 2.5 meters per leaf Operating Temperature C~+50 Dimension 256 x 187 x 267mm Weight 6 kg (Kg)
  • Page 20 ERREKA GROUP ERREKA CONNECTED ACCESS Bº Ibarreta s/n 20577 Antzuola (Gipuzkoa) España Polig. Ind. San Juan, T.(+34) 943786009 B. San Juan, 93 info@erreka.com 20570 Bergara (Gipuzkoa) España www.erreka.com T. (+34) 943769900 MSB-033/00 ARTICULATED ARM OPENERS - INSTALLATION MANUAL...
