CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity.
High temperatures could cause a fire.
INSTALLER: Leave this manual with the appliance, not inside the appliance.
CONSUMER: Retain this manual for future reference. Do not store inside the appliance.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Model(s):
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com.
Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner's Manual • 2558-981 Rev. H • 8/24
Owner's Manual
Operation and Maintenance
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
Decorative barrier front must be ordered separately at
time of appliance purchase.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CERONA-36-IFT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Heat & Glo CERONA-36-IFT

  • Page 1 Pour demander un exemplaire en français de ce Manuel Decorative barrier front must be ordered separately at du propriétaire, visitez www.heatnglo.com. time of appliance purchase. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 2: Welcome

    Serial Number CANADA (Modèle): XXXXXXXXX ALTITUDE:......0-2000 FT....0-4500 FT. MAX. INPUT BTU/h ....xx,xxxx ....xx.xxx Serial: MIN. INPUT BTU/h ....xx.xxx......xx.xxx (Série): ORIFICE SIZE ......#xx DMS ....#xx DMS Xxxx-xxx Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 3: Table Of Contents

    C. Contact Information ......30  = Contains updated information. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 4: Limited Warranty

    Firebox and heat exchanger All purchased replacement parts and optional accessories None 1 Year All purchased replacement parts and optional accessories Page 1 of 2 4021-645N 12/23 Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 5: Warranty Conditions

    THE EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. 4021-645N 12/23 Page 2 of 2 Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 6: Product Specific Information

    Replace glass only with 5 mm ceramic glass. Replace glass only with glass with identical specification. Please contact your dealer for replacement glass. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 7: Important Safety And Operating Information

    • Keep remote controls out of reach of children. • Never leave children alone near a hot fireplace, whether operating or cooling down. • Teach children to NEVER touch the fireplace. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 8: General Operating Parts

    • Conversions must be made by a qualified service technician using Hearth & Home Technologies specified and approved parts. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 9: Wall And Mantel Temperatures

    Use appropriate finishing materials that are able to withstand these conditions. For additional finishing guidelines, see Section 10 in Installation Manual. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 10 Sugges ons on how to further reduce TV temperatures: Increase “A” dimension. Increase “C” dimension, however, increasing “B” dimension beyond maximum recommended typically results in higher temperatures. Figure 3.5. Good Faith TV Guidelines Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 11 “D” dimension taken from the top of mantel to bottom of TV. “E” dimension taken from the front of TV to front of the mantel. Figure 3.6 Good Faith Guidelines - Passive Heat Kit Installed Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 12: Before Lighting Appliance

    • Ensure that the glass is sealed and in the proper position and that the integral barrier is in place. WARNING! Risk of Fire or Asphyxiation! DO NOT op- erate fireplace with fixed glass assembly removed. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 13: For Your Safety Read Before Lighting

    For additional information on operating your Keep burner and control compartment clean. See installation and operating instructions Hearth & Home Technologies fireplace, please 593-913K accompanying appliance. refer to www.hearthnhome.com. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 14: Appliance Break-In

    Passive Heat can be used in conjunction with HEAT-ZONE -GAS or HEAT- ® OUT-GAS kit. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 15: Operation During A Power Outage

    Slide the ON/REMOTE/OFF switch to the ON position. NOTICE: Some functionality will be lost when using battery backup including fan, lights, or any other auxiliary functions that require household 110-120 VAC power. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 16: Detailed Component Operating Instructions - Intellifire Touch

    IFT-RC400 or IFT-RC150. The wired wall switch is NOT available if a Power Vent is used. - Set the IFT-ECM 3-position selector switch to OFF position. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 17 - If the IFT-ECM re-enters the lock-out condition after these steps, call your dealer for service. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 18: Maintenance And Service

    • Reinstall decorative barrier front. CAUTION! Risk of Burns! The fireplace shall be turned off and cooled before servicing. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 19: Remote Control

    • Inspect draft shield to verify it is not damaged or missing. Figure 4.2. Surface plane of firebox is compromised and should be replaced. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 20: Led Replacement

    • Inspect pilot flame pattern and strength. See Figure 4.3 type 105º C rated wire. Wire must have high temperature for proper pilot flame pattern. Clean or replace orifice insulation. spud as necessary. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 21: Frequently Asked Questions And Troubleshooting

    Installer’s Manual for this the touch. appliance. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.heatnglo.com to locate a dealer. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 22: Frequently Asked Questions - Intellifire Touch

    Verify home circuit breaker is on and master reset is on (if No power to appliance. message on-screen: equipped). “Remote Control Communication Power outage. Install new batteries in battery backup. Error.” Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 23: Troubleshooting

    If open or shorted, replace valve. Check valve harness wire continuity, if open replace 6-pin harness. Pilot won’t light, there is no noise Spark coil failure. Replace ECM. or spark, 2 Red/2 Green Lockout. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 24 IFT- Damaged pilot assembly. sistance between tip of sense rod and ECM connector, should be less than 1 ohm. Replace pilot assembly if damage is detected. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 25: Reference Materials

    • Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. Contact your dealer if you have questions. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 26: Service Parts

    Grate Assembly SRV2106-006 Glass Door Assembly GLA-CERONA36 Fan Kit GFK-160A Junction Box SRV2326-013 Heat Shield, Junction Box 2106-130 Additional service part numbers appear on following page. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 27 Grate Assembly SRV2106-006 GLA-CERONA42 Glass Door Assembly Fan Kit GFK-160A Junction Box SRV2326-013 Heat Shield, Junction Box 2106-130 Additional service part numbers appear on following page. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 28 16.21 Module, B Type AC SRV2326-150 16.22 Cable, B Type AC Module SRV2326-152 16.23 Light Tub Assembly 2558-016 Additional service part numbers appear on following page. Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 29 Conversion Kit Propane LPK-CERONA36IFT Conversion Kit NG NGK-CERONA42IFT Cerona-42-IFT Conversion Kit Propane LPK-CERONA42IFT Pilot Orifice NG SRV593-528 Pilot Orifice Propane SRV593-527 Regulator NG NGK-DXV-50 Regulator Propane SRVLPK-DXV-50 Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
  • Page 30: Contact Information

    This product may be covered by one or more of the following patents: (United States) 7077122, 7074035, 7234932, 7322819, 7422011, 7726300, 8147240, 9625149 or other U.S. and foreign patents pending. 2000-945F Printed in U.S.A. - Copyright 2024 Heat & Glo • CERONA-36-IFT, CERONA-42-IFT Owner’s Manual • 2558-981 Rev. H • 8/24...
