Tektronix MSO70000 Series Instructions Manual page 14

Clear and Sanitize Procedures
Table 4: Nonvolatile memory devices (DPO7000C, DPO70000C/D/DX, DSA70000C/D, and MSO70000C/DX Series
Instruments) (cont.)
Type and
minimum
size Function
NVRAM,
Calibration data
16 Megabits
NVRAM, Motherboard
4 Megabytes BIOS and BIOS
settings
Table 5: Nonvolatile memory devices (DPO5000/B and MSO5000/B Series Instruments)
Type and
minimum
size Function
Removable Holds all
hard drive user-storable
(See data (waveforms
page 15, and instrument
Removable settings)
Hard
Drive/Solid
State Drive.)
EEPROM, PCI/PCIe bus
1024 bits settings
6
Type of Method Data
user info of input
stored modification method
None User Programmed
cannot at factory
modify
None Directly BIOS UI.
User can
change
BIOS
settings.
Type of Method Data
user info of input
stored modification method
User data Directly Windows
and user and UI and
settings indirectly TekScope
UI
None User Programmed
cannot at factory
modify
User
Location accessible To clear
Acquisition No Not applicable,
board does not
contain
user data
or settings.
Clearing
would disable
instrument
functionality
PC Yes Not applicable,
motherboard does not
contain
user data
or settings.
Clearing
would disable
instrument
functionality
User
Location accessible To clear
Side Yes (See page 15,
panel Removable
Hard
Drive/Solid
State Drive.)
Main No Not applicable,
Acquisition does not
board contain user
data or setting.
Clearing
would disable
instrument
functionality.
Declassification and Security
To sanitize
Not applicable, does
not contain user
data or settings.
Sanitizing would
disable instrument
functionality
Not applicable, does
not contain user
data or settings.
Sanitizing would
disable instrument
functionality
To sanitize
(See page 15,
Removable Hard
Drive/Solid State
Drive.)
Not applicable, does
not contain user
data or settings.
Sanitizing would
disable instrument
functionality
