Summary of Contents for Zotac ZBOX PRO PI336 pico PLUS
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Table of Contents Specifications ----------------------------------------------------------------------------------------------------3 Safety instructions----------------------------------------------------------------------------------------------5 Package contents -----------------------------------------------------------------------------------------------6 Port layout ---------------------------------------------------------------------------------------------------------7 Using your ZP-PI336 -------------------------------------------------------------------------------------------9 Configuring wireless connection -------------------------------------------------------------------------9 Configuring audio output -----------------------------------------------------------------------------------9 Watch Dog Timer function -----------------------------------------------------------------------------------10... -
Page 4: Specifications
Specifications Microprocessor Support • Intel Celeron N6211 (1.2GHz/3.0GHz, 1.5MB cache) Onboard Graphics Support • Integrated Intel UHD Graphics for 10th Gen Intel Processors • HDMI 2.0 (max resolution: 4096x2160 @60Hz) • DP 1.2 (max resolution: 4096x2160 @60Hz) Memory • Onboard 4GB/8GB LPDDR4X USB Ports •... -
Page 6: Safety Instructions
Safety instructions ZP-PI336 is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instruc- tions. Read and follow all instructions in the documentation before you operate your system. ™... -
Page 7: Package Contents
Package contents Thank you for choosing our ZP-PI336. The following illustration displays the package contents of your new ZP-PI336. If any of the below items are damaged or missed, contact your retailer. • 1 x ZP-PI336 • 1 x L-shaped mounting kit •... -
Page 8: Port Layout
Port layout 1. USB 3.1 Type-C port The USB 3.1 type-C port supports the SuperSpeed USB 3.1 devices. Use this port for USB 3.1 devices for maximum performance with USB 3.1 compatible devices. 2. DisplayPort DisplayPort supports external connection up to DP1.2, max resolution 4096x2160 @60Hz. 3. - Page 9 7. Clear CMOS hole Insert a pin into the Clear CMOS hole for 3 seconds to clear CMOS. 8. Power input (DC 5V, 4A) The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the mini-PC.
-
Page 10: Using Your Zp-Pi336
Using your ZP-PI336 Configuring a wireless connection Please follow the instructions below to connect to a wireless network: Double-click the wireless network icon in the notification area. Select the wireless network you want to connect to from the list and click Connect. After connection is established, you will see “Connected.”... -
Page 11: Watch Dog Timer Function
Watch Dog Timer function This device support Watch Dog Timer. The detail of Watch Dog Timer function, user manual, demonstration application and source code for Windows and Linux can refer to the Watch Dog Timer driver folder on the USB driver.
