- Page 1 PI221 pico 291-MB307-02M9F...
- Page 2 ZOTAC ZBOX pico User’s Manual No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except by the purchaser for backup purposes, without the express written permission of ZOTAC.
-
Page 3: Table Of Contents
Welcome ------------------------------------------------------------------------------------------------ 5 Package contents --------------------------------------------------------------------------------- 5 Port Layout --------------------------------------------------------------------------------------------- 6 Getting started with Windows 10 --------------------------------------------------------------- 8 Using your ZOTAC ZBOX pico ------------------------------------------------------------------12 Configuring a wireless connection -----------------------------------------------------------12 Configuring an Ethernet connection ---------------------------------------------------------12 Using a static IP ------------------------------------------------------------------------------12 Using a dynamic IP (PPPoE connection) ----------------------------------------------13... -
Page 4: Product Specifications
USB ports • One USB 3.0 port Storage • 32GB eMMC • 2-in-1 card reader (Micro SD/SDHC/SDXC) Networking • 10/100Mbps Ethernet Wireless networking • 802.11ac Wi-Fi • Bluetooth 4.0 Operating System • Windows 10 Home (x86) preinstalled ZOTAC ZBOX pico... -
Page 5: Safety Information
Safety information Your ZOTAC ZBOX pico is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before you operate your system. -
Page 6: Welcome
Welcome Congratulations on your purchase of the ZOTAC ZBOX pico. The following illustration displays the package contents of your new ZOTAC ZBOX pico. Please contact your retailer if any of the below items are damaged or missed. Package contents • 1 x ZOTAC ZBOX pico •... -
Page 7: Port Layout
Port Layout ZOTAC ZBOX pico... - Page 8 1. MicroSD memory card slot The built-in memory card reader supports Micro SD/SDHC/SDXC cards to expand the storage capabilities of the ZOTAC ZBOX pico. 2. Wi-Fi antenna connector The Wi-Fi antenna connector supports the included Wi-Fi antenna. 3. HDMI port The HDMI (High Definition Multimedia Interface) port supports a Full HD 1080p displays such as an HDTV or monitor.
-
Page 9: Getting Started With Windows 10
Getting started with Windows 10 Please follow the steps below to begin using your ZBOX pico with Windows 10. 1. Power on the system. 2. Connect to the Internet via Ethernet or Wi-Fi. 3. Select the language and region. ZOTAC ZBOX pico... - Page 10 4. Read and accept the license terms. 5. We recommend using the express settings. ZOTAC ZBOX pico...
- Page 11 6. Create a Microsoft new account if you don’t have one. Otherwise, select “Sign in”. 7. Setup your account. ZOTAC ZBOX pico...
- Page 12 8. Wait for the initial system setup to complete . ZOTAC ZBOX pico...
-
Page 13: Using Your Zotac Zbox Pico
Using your ZOTAC ZBOX pico Configuring a wireless connection Please follow the instructions below to connect to a wireless network: Double-click the wireless network icon (pic) in the notification area. Select the wireless network you want to connect to from the list and click Connect. -
Page 14: Using A Dynamic Ip (Pppoe Connection)
Password. Click “Next”. 10. Click “Finish” to finish the configuration. 11. Enter your user name and password. Click “Connect” to connect to the internet. Note: Contact your internet Service Provider (ISP) if you have problems connecting to the network. ZOTAC ZBOX pico... -
Page 15: Configuring Audio Output Via An Hdmi Device
Configuring audio output via an HDMI device Follow the steps below to enable audio output via HDMI when connecting the ZOTAC ZBOX pico to a TV or receiver via HDMI. Access the Sound settings via the system Control Panel. Under Playback devices, click the display... - Page 16 ZOTAC ZBOX pico...
- Page 17 ZOTAC ZBOX pico 291-MB307-02...
