Specifications - Zotac ZBOX PRO PI336 pico PLUS User Manual

Specifications

Microprocessor Support
Onboard Graphics Support
Memory
USB Ports
Audio
Storage
Network
WiFi Support
Operating Systems
H/W watchdog timer
Case Dimension
• Intel Celeron N6211 (1.2GHz/3.0GHz, 1.5MB cache)
• Integrated Intel UHD Graphics for 10th Gen Intel
Processors
• HDMI 2.0 (max resolution: 4096x2160 @60Hz)
• DP 1.2 (max resolution: 4096x2160 @60Hz)
• Onboard 4GB/8GB LPDDR4X
• 2x USB 3.1 Type-A ports
• 1x USB 3.1 Type-C port
• 1x 3.5mm stereo out & microphone combo
• Onboard 128 GB eMMC 5.1
• MicroSD/microSDHC/microSDXC card reader slot
• 1x Gigabit Ethernet LAN
• Supports Wake-on-LAN
• WIFI 6E, IEEE 802.11 a/b/g/n/ac/ax
• Bluetooth 5.2
• Supports Windows 11, Windows 10,
Windows 10 IoT ENT LTSC and Ubuntu 20.04 LTS Linux
• Timeout value = 0 ~ 65,535. Unit: minute/second
• 115.0mm x 76.0mm x 26.7mm
3
