Dual Motor Electric 4-Leg Desk
Instruction Manual
for the following SKUs
OR
Desk Frame Only [ DESK-E4B/W ]
Desk Frame + Top [ DESK-KIT-E4BB/WW]
DESK-E4B/W + DESK-TOPE4B/W-72
Assembly Video & Product Info
Assembly Video & Product Info
www.vivo-us.com/products/desk-kit-e4bb
www.vivo-us.com/products/desk-kit-e4bb
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-E4B
Summary of Contents for Vivo DESK-E4B
- Page 1 Dual Motor Electric 4-Leg Desk Instruction Manual for the following SKUs Desk Frame Only [ DESK-E4B/W ] Desk Frame + Top [ DESK-KIT-E4BB/WW] DESK-E4B/W + DESK-TOPE4B/W-72 Assembly Video & Product Info Assembly Video & Product Info www.vivo-us.com/products/desk-kit-e4bb www.vivo-us.com/products/desk-kit-e4bb...
- Page 2 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 3 7AM - 7PM Monday-Friday Give us a Call: Chat Us: Email Us: 309-278-5303 www.vivo-us.com help@vivo-us.com We’re Here for You! Our customer-minded support team is here for YOU, Monday-Friday 7am-7pm CST. We offer immediate assistance with rapid response times from customer service agents and product techncians to...
- Page 4 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 5 This manual includes instructions for different product variations, some of which are desk frame only. Please check your ordering SKU before proceeding to ensure you follow the correct instructions. Desk Frame Only [ DESK-E4B/W ] NOTE: This SKU does not include a desktop pg. 7-16...
- Page 6 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts.
-
Page 7: Package Contents
Package Contents A (x2) B (x1) O (x4) Outer Desktop Middle Desktop C (x2) Connecting Plate Panel Panel Motorized Leg DESK-KIT-E4BB/WW ONLY [not included with frame only] D (x2) E (x2) F (x2) G (x2) Non-Motorized Left Crossbar Right Crossbar Middle Crossbar J (x1) K (x1) - Page 8 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 9 Option A Desk Frame Only | DESK-E4B/W NOTE: This SKU does not include a desktop...
- Page 10 Desk Frame Only [DESK-E4B/W] STEP 1 Attach Right Crossbars (F) to Motorized Legs (C) and Left Crossbars (E) to Non-Motorized Legs (D) using M6x11mm Screws (S-A) tightening with 5mm Allen Wrench (T-B).
- Page 11 STEP 2 Attach Motorized Legs (C) to Non-Motorized Legs (D) using Side Brackets (H), M6x11mm Screws (S-A), and 5mm Allen Wrench (T-B).
- Page 12 STEP 3 1. Loosen the coupling nut on Sync Rods (I). 2. Insert the hex shaft end into the Non-Motorized Legs (D). Ensure all of the legs are at the same height. If they are not, rotate the sync rod clockwise to raise and counterclockwise to lower the legs.
- Page 13 STEP 4 Slide Middle Crossbars (G) into the Left and Right Crossbars (E,F) making sure the slots on Crossbar are facing inwards towards the motors on Motorized Legs (C). CAUTION Be careful not to extend the Crossbars (G) past the Max markings when adjusting for your desktop.
- Page 14 STEP 5 Place the frame assembly of your desktop (not included) and secure using ST5x15mm Screws (S-B) tightening with a Phillips screwdriver or drill. Install the M6x11mm Screws (S-A) into the Left and Right Crossbars (E,F) and tighten using the 5mm Allen Wrench (T-B) to secure the crossbar location.
- Page 15 STEP 6 Secure the Power Adapter (J) and Control Panel (K) to your desktop using ST5x15mm Screws (S-B)and a Phillips screwdriver or drill.
- Page 16 STEP 7 1. Connect the Extension Cables (L) to the cable on the Motorized Leg (C) furthest from the Control Panel (K). 2. Connect the motor cable from the closest leg, Extension Cable (L), and cable from Power Adapter (J) to the Control Panel (K). 3.
- Page 17 Option B Desk Frame + Desktop | DESK-KIT-E4BB/WW DESK FRAME: DESK-4B/W | DESKTOP: DESK-TOPE4x-72...
- Page 18 b. Desk Frame + Desktop (DESK-KIT-E4BB/WW) STEP 1 Attach Right Crossbars (F) to Motorized Legs (C) and Left Crossbars (E) to Non-Motorized Legs (D) using M6x11mm Screws (S-A) tightening with 5mm Allen Wrench (T-B).
- Page 19 STEP 2 Attach Motorized Legs (C) to Non-Motorized Legs (D) using Side Brackets (H), M6x11mm Screws (S-A), and 5mm Allen Wrench (T-B).
- Page 20 STEP 3 1. Loosen the coupling nut on Sync Rods (I). 2. Insert the hex shaft end into the Non-Motorized Legs (D). Ensure all of the legs are at the same height. If they are not, rotate the sync rod clockwise to raise and counterclockwise to lower the legs.
- Page 21 STEP 4 Slide Middle Crossbars (G) into the Left and Right Crossbars (E,F) making sure the slots on Crossbars are facing inwards towards the motors on Motorized Legs (C). CAUTION Be careful not to extend the Crossbars (G) past the Max markings when adjusting for your desktop.
- Page 22 STEP 5 Layout the Outer and Middle Desktop Panels (A,B) as shown with the pilot holes facing up. Press Wooden Dowels (S-C) into the sides of Middle Desktop Panel (B) and then slide the Outer Desktop Panels (A) over the Wooden Dowels (S-C) closing the gap. Secure the Panels together using Connecting Plates (O) and ST5x15mm Screws (S-B) tightening with a Phillips screwdriver or drill.
- Page 23 STEP 6 Place the frame assembly on top of the desktop assembly and secure using ST5x15mm Screws (S-B) tightening with a Phillips screwdriver or drill. Install the M6x11mm Screws (S-A) into the Left and Right Crossbars (E,F) and tighten using the 5mm Allen Wrench (T-B) to secure the crossbar location.
- Page 24 STEP 7 Secure the Power Adapter (J) and Control Panel (K) to the desktop using ST5x15mm Screws (S-B) tightening with a Phillips screwdriver or drill.
- Page 25 STEP 8 1. Connect the Extension Cables (L) to the cable on the Motorized Leg (C) furthest from the Control Panel (K). 2. Connect the motor cable from the closest leg, Extension Cable (L), and cable from Power Adapter (J) to the Control Panel (K). 3.
- Page 26 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
-
Page 27: Control Panel Instructions
Control Panel Instructions... -
Page 28: Reset Procedure
Control Panel Instructions Operating Instructions Height Adjustment Press and hold either the buttons to raise or lower the desk. Saving Height Settings To save a preferred height setting for easy recall, press the button until the display flashes. Then press any of the numbered buttons and the current height will be programmed to that button. To return desk to a saved height, press the corresponding button. -
Page 29: Advanced Settings
Advanced Settings Change Displayed Unit (UN) Long press the button until the screen shows , then release button. Short press again and the screen will display Short press to select. Use the arrow keys to switch between (metric) (imperial/inches). Short press to save your selection. - Page 30 WHO WE ARE VIVO is more than a brand of ergonomic office furniture. We are a team of creative and innovative indivuduals working together to offer high quality, affordable ergonomic solutions. We think and work outside of the box to serve...
-
Page 31: Need Assistance
Call Us: 309-278-5303 Average Resolution Time: 5m 4s Chat Us: www.vivo-us.com Average Resolution Time: < 15m Email Us: help@vivo-us.com Average Resolution Time: 1HR 8M 23% within < 15m 38% within <... - Page 32 LAST UPDATED: 6/19/24 REV2 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
