Black 63" x 55" Corner Electric Desk
Instruction Manual
SKU: DESK-E3CTB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e3ctb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the DESK-E3CTB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo DESK-E3CTB

Summary of Contents for Vivo DESK-E3CTB

  • Page 1 Black 63" x 55" Corner Electric Desk Instruction Manual SKU: DESK-E3CTB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-e3ctb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Electrical Safety Instructions

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.

  • Page 3: Tools Needed

    TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 176lbs Failure to do so may result in serious injury. (80kg) Level Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Attach Left Crossbar (J) to Left Leg (D) and Right Crossbar (M) to Leg With Motor (E) with M8x47 Screws (S-A).
  • Page 4 STEP 1 (Continued) Attach Side Brackets (B) to Left Leg (D) and Leg With Motor (E) using M6x10 Screws (S-B) and 4mm Allen Wrench (T-C). Mount Feet (C) to Left Leg (D) and Leg With Motor (E) using M6x35 Screws (S-D) and tighten using 5mm Allen Wrench (T-A).
  • Page 5 STEP 3 - OPTION A: Left Side Extension Slide Inner Crossbar (N) into Right Crossbar (M) and Inner Right Crossbar (L). Secure using M6x12 Screw (S-C) and 4mm Allen Wrench (T-C). Attach Crossbar Connector (O) to Inner Left Crossbar (K) and Left Crossbar (J) using M6x12 Screw (S-C) and 4mm Allen Wrench (T-C).
  • Page 6 STEP 5 - OPTION A: Left Side Extension Position Desktops (A) on frame assembly with center section aligned lengthwise with left section. Mount Desktops (A) to frame assembly using M5x16 Screws (S-E) and a Phillips screwdriver. Connect Desktop (A) sections using Connecting Plates (I) and M5x16 Screws (S-E). Tighten using Phillips Screwdriver.
  • Page 7 STEP 6 - OPTION A: Left Side Extension Connect the AC Adapter (Q) to the cable from the motor and Control Panel (P), then plug the AC Adapter (Q) into a wall outlet to power on the desk for operation. Organize cables using the Cable Clips (S-G).
  • Page 8 STEP 7 - OPTION B: Right Side Extension Slide Inner Crossbar (N) into Left Crossbar (J) and Inner Left Crossbar (K). Secure using M6x12 Screw (S-C) and 4mm Allen Wrench (T-C). Attach Crossbar Connector (O) to Inner Right Crossbar (L) and Installation steps for right Right Crossbar (M) using M6x12 Screw (S-C) and 4mm Allen Wrench (T-C).
  • Page 9 STEP 8 - OPTION B: Right Side Extension Position Desktops (A) on frame assembly with center section aligned lengthwise with right section. Mount Desktops (A) to frame assembly using M5x16 Screws (S-E) and a Phillips screwdriver. Connect Desktop (A) sections using Connecting Plates (I) and M5x16 Screws (S-E). Tighten using Phillips Screw- driver.
  • Page 10 STEP 9 - OPTION B: Right Side Extension Connect the AC Adapter (Q) to the cable from the motor and Control Panel (P), then plug the AC Adapter (Q) into a wall outlet to power on the desk for operation. Organize cables using the Cable Clips (S-G).
  • Page 11 STEP 10 - OPTION C: No Extensions Attach Left Crossbar (J) to Left Leg (D) and Inner Left Crossbar (K) to Leg With Motor (E) with M8x47 Screws (S-A). Tighten using 5mm Allen Wrench (T-A). S=5mm S=5mm Foot (x4) S=4mm Attach Side Brackets (B) to Left Leg (D) and Leg With Motor (E) using M6x10 Screws (S-B) and 4mm Allen Wrench (T-C).
  • Page 12 STEP 11 - OPTION C: No Extensions Slide Inner Crossbar (N) into Left Crossbar (J) and Inner Left Crossbar (K). Secure using M6x12 Screw (S-C) and 4mm Allen Wrench (T-C). S=4mm S=4mm Loosen the nut on the Long Sync Rod (H). Insert the Long Sync Rod (H) into the hex hole in Leg (D) and turn it...
  • Page 13 STEP 12 - OPTION C: No Extensions Connect two Desktop (A) sections using Connecting Plates (I) and M5x16 Screws (S-E). Tighten using Phillips Screwdriver. Tighten the screws Position frame assembly upside down on Desktops (A). Mount frame assembly to Desktops (A) using M5x16 Screws (S-E) and a Phillips screwdriver.
  • Page 14 STEP 13 OPTION C: No Extensions Mount Control Panel (P) to the underside Desktop (A) using M5x16 Screws (S-E) and a Phillips screwdriver. Connect the AC Adapter (Q) to the cable from the motor and Control Panel (P), then plug the AC Adapter (Q) into a wall outlet to power on the desk for operation.
  • Page 15 CAUTION! Do not exceed desk Keep area of vertical Keep weight on desk Leave enough slack in weight limit. motion free of balanced for correct cables to allow for full obstacles. operation and longer range of vertical motion. life of components. Failure to follow these instructions may result in property damage and/or personal injury.
