SE1 50, 80, 100-SEV 65, 80, 100
1.1 to 11 kW
Service instructions
SE1 50,80,100, SEV 65,80,100
Installation and operating instructions
Other languages
http://net.grundfos.com/qr/i/96046675
SE1, SEV with sensor
SE1, SEV with sensor Service video,
YouTube
GRUNDFOS INSTRUCTIONS
SE1, SEV without sensor
SE1, SEV without sensor Service video,
YouTube

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE1 50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grundfos SE1 50

Summary of Contents for Grundfos SE1 50

  • Page 1 GRUNDFOS INSTRUCTIONS SE1 50, 80, 100-SEV 65, 80, 100 1.1 to 11 kW Service instructions SE1 50,80,100, SEV 65,80,100 SE1, SEV without sensor Installation and operating instructions SE1, SEV without sensor Service video, Other languages YouTube http://net.grundfos.com/qr/i/96046675 SE1, SEV with sensor...
  • Page 3 SE1 50, 80, 100-SEV 65, 80, 100 chapter[en-GB]................4...

  • Page 4: Table Of Contents

    Maintenance schedule ..... . 20 The symbols and hazard statements below may appear in Grundfos installation and operating instructions, safety instructions and Servicing Grundfos pumps with explosion-proof motors .

  • Page 5: Transporting The Product

    /h Insul.class: Cosφ : Tips and advice that make the work easier. Motor: P1/P2: IP68 Weight II2G U.K Importer: Grundfos Pumps ltd. Grovebury Road Leighton Buzzard Bedfordshire LU74TL 100197 0344 8505 DK-8850 Bjerringbro, Denmark 2. Transporting the product 13 20...

  • Page 6: Type Key

    4.2 Type key 5. Service tools Example: SE1.80.80.40.A.Ex.4.51D.B 5.1 Special tools Code Explanation Designation Sewage and wastewater pump Pump type ® S-tube impeller Impeller type SuperVortex impeller Maximum solids size [mm] Pump passage Nominal diameter [mm] Pump outlet Output power P2/10 Power [kW] Standard (without sensor) Sensor version...

  • Page 7: Service Sledge

    5.2 Service sledge Pump to be installed Service sledge Pump passage Power Pump/Impeller type Pump outlet Poles Service sledge type key Product number [mm] [kW] SE sledge: B.SE1.50.2.2-3.2.50 DIN SE sledge: SE1.50.65.2.2.2.50 DIN SE sledge: SE1.50.65.3.2.50 DIN 98827089 SE sledge: SE1.50.80.2.2.2.50 DIN SE sledge: SE1.50.80.3.2.50 DIN SE sledge: B.SEV.65.2/SE1.80.4.50 DIN SE sledge: SEV.65.65.2.2.2.50 DIN...
  • Page 8 Pump to be installed Service sledge Pump passage Power Pump/Impeller type Pump outlet Poles Service sledge type key Product number [mm] [kW] SE sledge: C.SEV.80.SE1.80.50 DIN SE sledge: SEV.80.80.4.4.50 DIN SE sledge: SEV.80.80.4.2.50 DIN SE sledge: SEV.80.80.6.2.50 DIN SE sledge: SEV.80.80.7.5.2.50 DIN SE sledge: SEV.80.100.4.4.50 DIN SE sledge: SEV.80.100.4.2.50 DIN SE sledge: SEV.80.100.6.2.50 DIN...

  • Page 9: Horizontal Bracket Installation

    5.3 Horizontal bracket installation Pump to be installed Horizontal bracket installation Pump passage Power Frequency Pump/Impeller type Pump outlet Poles Product number [mm] [KW] [Hz] Horizontal bracket installation B.65.50 DIN 98902621 Horizontal bracket installation B.80/100.50 DIN 98902622 Horizontal bracket installation C.65.50 DIN 98902623...
  • Page 10 Pump to be installed Horizontal bracket installation Pump passage Power Frequency Pump/Impeller type Pump outlet Poles Product number [mm] [KW] [Hz] Horizontal bracket installation C.80/100.50 DIN 98902625 Horizontal bracket installation C.150.50 DIN 98902626 Horizontal bracket installation C.80/100.50 DIN 98902628 Horizontal bracket installation D.150.50 DIN 98902630...

  • Page 11: Lifting Tools

    5.4 Lifting tools Puller tool, DN 100 Pos. Designation Pump type Part number Crane for service sledge 98902631 5.5 Seal ring mounting tool Mounting tool for seal ring Ø20 Puller beam Threaded rod Puller tool, DN 50 Puller tool, DN 80...

  • Page 12: Torques And Lubricants

    6. Torques and lubricants This section indicates the screws and nuts that must be tightened to a certain torque and the lubricants to be used. 6.1 Special torques and lubricants Pos. Pump type Description Quantity Size Torque [Nm] Lubricant Screw (clamp) M8 x 70 12 ±...

  • Page 13: Electrical Connection

    • Make sure that all protective equipment has been 7.1 Pump controllers connected correctly. The pumps can be controlled by the Grundfos LC 231, LC 241, DC • Float switches used in potentially explosive and DCD controllers. environments must be approved for this application.
  • Page 14 G1 A1 G2 A2 K1 K2 R1 R2 Float switches used in potentially explosive environments must be approved for this application. They must be connected to the Grundfos LC 231 or LC 241 level A Y B D1 D2 D3 D4 D5 D6 D7 D8 controller by an intrinsically safe barrier to ensure a safe circuit.

  • Page 15: Switches And Sensors

    See electrical data in the IO 113 installation and operating Pos. Description instructions. Terminals for measurement of stator insulation resistance Do not install the separate motor-protective circuit breaker Terminals for connection of pump sensors or control box in potentially explosive environments. DIP switch for configuration 7.2.2 WIO sensor Indicator light for motor temperature...

  • Page 16: Frequency Converter Operation

    7.3 Frequency converter operation In principle, all three-phase motors can be connected to a frequency converter. However, frequency converter operation often exposes the motor insulation system to a heavier load and causes the motor to be more noisy due to eddy currents caused by voltage peaks. In addition, large motors operated with a frequency converter are loaded by bearing currents.

  • Page 17: Wiring Diagrams

    7.4 Wiring diagrams 7-core cable The figure below shows the wiring diagrams for SE1, SEV pumps with 7-core cable in three versions, one without sensors and two with WIO sensor and moisture switch. Y&G L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 1 2 3...
  • Page 18 10-core cable The figures below show the wiring diagrams for SE1, SEV pumps with 10-core cable in three versions, one without sensors and two with WIO sensor and moisture switch. Y&G L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 U1 V1 W1 U2 V2 W2...
  • Page 19 Y&G L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2 L3 U1 V1 W1 U2 V2 W2 U1 V1 W1 U2 V2 W2 U1 V1 W1 U2 V2 W2 U1 V1 W1 U2 V2 W2 Wiring diagram, 10-core cable, delta-connected (D) Pos.

  • Page 20: Storing The Product

    Do not stand near or under the pump when it is lifted. cable is not sharply bent or pinched. WARNING Electric shock The cable must be replaced by Grundfos or an authorised Death or serious personal injury service workshop. ‐...

  • Page 21: Cleaning And Inspecting The Pump

    5. Clean the faces for the gaskets for oil screws. while the other end of the cable is connected to the pump. In case the pump cable is longer than 10 m, contact Grundfos for correct values. Dispose of used oil in accordance with local regulations.
  • Page 22 9.5.1 Checking with Test Box 9.5.2 Checking with a multimeter Do not use a megaohmmeter for checking the sensor as it will damage the control circuit. If the measured value is Ω, disconnect the conductors from IO 113. If the measured value is mA, disconnect conductor 6 (9) from P5 and connect the standard instrument to 6 (9) and P5.

  • Page 23: Assembly

    Value Response IO 113 ● ● > 3000 Ω Alarm ● ● 0 Ω Alarm WIO sensor Value Response IO 113 ● ● 4 mA (new oil) ● ● 3.5 mA (air) Alarm ● ● 22 mA (water) Warning ● ●...

  • Page 24: Fitting The Stator Housing

    10.2 Fitting the stator housing 10.6 Fitting the WIO sensor 1. Place the motor in horizontal position on wooden bars. Fit the sensor next to one of the shaft seal openings. The 2. Fit the moisture switch in the stator housing (55), if any. sensor must be tilted into the motor’s direction of rotation to ensure that oil is led into the sensor.

  • Page 25: Fitting The Moister Switch

    Pos. Description Micro switch Washer Washer Clearance gouge: 0.19 ± 0.007 " (5 ± 0.2 mm) L4 is to be cut Loctite 290 - thread locking compound 0.55 " (14 mm) 1. Connect the moisture switch in the test bell. 2.

  • Page 26: Fitting The Seal Ring And Wear Ring

    10.9 Fitting the seal ring and wear ring 10.10 Fitting the impeller 1. Lubricate the seal ring (46) with oil. 1. Fit the corrugated spring (157) and the key (9a). Keep the key (9a) in position while fitting the impeller (49). 2.

  • Page 27: Fitting The Cable

    The product is classified as contaminated if it is used for contagious or toxic liquid. Before returning the product for service, contact Grundfos with details about the pumped liquid. Otherwise, Grundfos can deny to service the product. Any application for service must include details about the pumped liquid.

  • Page 28: Removing The Wio Sensor

    5. Clean the impeller (49) where the wear ring (49c) was fitted. 12.8 Removing the rotor 1. Remove the screws (182). 2. Remove the lower bearing cover (59). 3. Fit two screws (182) in the upper bearing cover (60), and tighten them until the rotor (172) is free.

  • Page 29: Removing The Sleeve

    12.12 Removing the sleeve 12.14 Removing the stator 1. Pull the sleeve (150) free of the stator housing (55) with two 1. Remove the pin housing (176), using the pin pusher (B). crowbars. 2. Remove the plug protector (177), using the multiplug pliers (C). 3.

  • Page 30: Start-Up

    13. Start-up WARNING Electric shock Death or serious personal injury The pump must not run dry. ‐ Before starting up the product for the first time, check the power cable for visible defects to avoid short circuits. ‐ If the power cable is damaged, it must be replaced by Dry running can cause ignition hazard.

  • Page 31: Starting Up The Sev Pump

    Check that there is positive inlet pressure before http:// starting up the pump. net.grundfos.com/qr/i/ 96046675 9. Dry-installed pumps with inlet pipe and foot valve: • Open the isolating valve on the outlet side to let the water above the valve run backwards to prime the inlet pipe.

  • Page 32: Drawings

    15. Drawings 15.1 SE1 183a 190b 173a 184a 153b 188a ® Sectional drawing, SE1 pump with S-tube impeller...
  • Page 33 190b 183a 174a 153b 193a 173a 150a 184a 188a ® Exploded view, SE1 pump with S-tube impeller...
  • Page 34 190b 183a 150a 173a 184a 153b 188a ® Sectional drawing, SE1 pump with S-tube impeller, sensor version...
  • Page 35 190b 183a 174a 524a 153b 193a 173a 150a 184a 520a 188a 520b 37 a 37 a ® Exploded view, SE1 pump with S-tube impeller, sensor version...

  • Page 36: Sev

    15.2 SEV 183a 190b 173a 184a 153b 188a Sectional drawing, SEV pump with SuperVortex impeller...
  • Page 37 190b 183a 174a 153b 193a 173a 188a 184a Exploded view, SEV pump with SuperVortex impeller...
  • Page 38 190a 183a 150a 173a 184a 153b 188a Sectional drawing, SEV pump with SuperVortex impeller, sensor version...
  • Page 39 190b 183a 174a 524a 153b 173a 193a 150a 184a 188a Exploded view, SEV pump with SuperVortex impeller, sensor version...

  • Page 40: Material Specification

    EN 1.4408 EN 1.4517 Earth screw Stainless steel EN 1.4301 173a Lock washer Stainless steel EN 1.4301 Available only on request. For more information, contact Grundfos. Earth screw, external Stainless steel EN 1.4301 174a Washer Stainless steel EN 1.4301 Plug protector Stainless steel EN 1.4408...

  • Page 41: Sensor Positions

    15.4 Sensor positions Sensor positions Pos. Description Water-in-oil sensor (WIO) Positioning area of the WIO sensor Moisture switch Thermistor, Pt1000 or thermal switch are factory-braided inside the stator windings.
