LCD TELEVISION

INSTRUCTION MANUAL

DLP-2612
DLP-3212
PAL B/G , D/K, I/I,
SECAM B/G , D/K, L/L' , NTSC(AV)
TELETEXT
SCART/VIDEO/S-VIDEO/COMPONENT/PC/DVI-D
MULTI-LANGUAGE OSD
Help line Number: 0870 100 2525

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLP-2612 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DLP-2612

Summary of Contents for Daewoo DLP-2612

  • Page 1: Instruction Manual

    LCD TELEVISION INSTRUCTION MANUAL DLP-2612 DLP-3212 PAL B/G , D/K, I/I, SECAM B/G , D/K, L/L’ , NTSC(AV) TELETEXT SCART/VIDEO/S-VIDEO/COMPONENT/PC/DVI-D MULTI-LANGUAGE OSD Help line Number: 0870 100 2525...
  • Page 2 Caution RISK OF ELECTRIC SHOCK CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Safety Precautions

    1. CLEANING Unplug this TV equipment from the AC power outlet before cleaning. Do not use liquid cleaner or aerosol cleaners. Use a soft and damp cloth for cleaning. 2. ATTACHMENTS Do not use attachments not recommended by the TV equipment manu- facturer as they may result in the risk of fire, electric shock or other injury.

  • Page 4: Table Of Contents

    Contents Important Safeguards ............5 Supplied Accessories .

  • Page 5: Important Safeguards

    Heat, Moisture, Dust, Vibration Position your set so that bright light or sunlight doesn’t fall directly onto the screen. Care should be taken not to expose the set to any unnecessary vibration, moisture, dust or heat. Do not expose the set to dripping or splashing. Ventilation Also ensure that the set is placed in a position to allow a free flow of air.

  • Page 6: Supplied Accessories

    Supplied Accessories Make sure that the following accessories are provided with the product. AC cord POWER STILL RECALL LOCK SLEEP SOUND EDIT MODE PICTURE ASPECT PREV PR MENU POSTION SWAP INPUT Remote controller Instruction manual Batteries (Option) (2 x 1,5V, AAA)

  • Page 7: Functional Overview

    Front <LED Indicator> : Lights up red in Stand-By mode and Lights up green in TV on mode. When TV is Child Lock mode, LED will cycle through red / green. TIMER <LED Indicator> : When On time/Off time in time setting mode is selected, the LED is red. Remote Sensor : Receives signals from the remote controller.

  • Page 8: Remote Controller

    Functional Overview Remote Controller POWER STILL RECALL Note: When the current state is ST-BY, you turn on the 3. STILL : Press this button to freeze the picture. 4. RECALL : The present modes(TV, Video, Component, PC) and Signal information for 4 seconds. LOCK SLEEP In TV mode, the Programme number, Signal, PIP/POP,...
  • Page 9 Remote Controller 12. ASPECT : Select screen aspect ratio : 16:9 / Zoom1 / Zoom2 / Panorama / Auto / 4:3 POWER 13. PREV PR : Previous PROGRAMME button. STILL RECALL 14. MENU : Menu display button. 16. MULTIMEDIA : Each time you press this button, the TV will cycle through: LOCK SLEEP...

  • Page 10: Preparation

    Preparation Inserting Batteries into the Remote Control Unit To load the batteries, turn the remote control handset over and open the battery compartment. Insert the batteries (Two 1.5v, type R03 or AA). Make sure that the polarity matches with the (+) and (-) marks inside of the battery compartment.

  • Page 11: Aerial Connection With Vcr

    Aerial Connection with VCR Connect your ① aerial cable to the RF(aerial) IN terminal on the VCR. Connect the RF OUT terminal of the VCR to the Aerial terminal on the TV set with ② RF cable. NOTE: If you wish to use only the Aerial (RF) connection to match the VCR, then you should store the VCR channel on the TV to programme number “ZERO”...

  • Page 12: Connecting Pc(15Pin D-Sub)

    Preparation Connecting PC(15Pin D-SUB) 1. Prepare the PC cable (D-sub 15pin) and the PC audio cable(Sold separately). 2. Connect the PC(Output) to the LCD(Input) as shown below. 3. Turn on the LCD and PC. 4. INPUT SELECT : Select [PC] by pressing the “MULTIMEDIA” button of the Remote Control or LCD unit.

  • Page 13: Connecting Dvi

    1. Prepare the DVI cable and the PC audio cable(Sold separately). 2. Connect the PC(Output) to the LCD(Input) as shown below. 3. Turn on the LCD and PC. 4. INPUT SELECT : Select [DVI] by pressing the “MULTIMEDIA” button of the Remote Control or LCD unit.

  • Page 14: Connecting Component Or Video Or S-Video From A Dvd

    Preparation Connecting Component or VIDEO or S-VIDEO from a DVD 1. Prepare the AV cable. 2. Connect the DVD(Output) to the LCD(Component or Video Input) as shown below. 3. When connecting to an external AV source, be sure to match the colors. 4.
  • Page 15 NOTES: 1) Y/Cb/Cr, which stands for DVD Player’s Output Terminal, can also be written as Y/B-Y/R-Y, Y/Pb/Pr depending on the kinds of DVD devices. 2) The way of connecting the DVD to the LCD is as follows: Y <---> Y Cb <---> Pb, B-Y, Cr <---> Pr, R-Y 3) The DVD output can be Video, S-Video and/or Component Video depending on the DVD devices.
  • Page 16 Preparation Source Mode Selection Press the AV button on the TV control panel repeatedly to select the source. You can also select the source using AV button or Multimedia button on the remote controller. AV button on the control panel : TV >...
  • Page 17 DVD or DTV Set-Top Box Input Jack (Component1, Component2) These jacks have Y/Pb(Cb)/Pr(Cr) inputs and Audio inputs. These jacks are used to connect a DVD player, DTV Set-Top Box. (Available input mode : 480i, 480p, 576i, 576p, 720p 60Hz, 720p 50Hz, 1080i 50Hz, 1080i 60Hz) Headphone Input Jack Insert the headphone plug (3.5 mm ) into this jack.

  • Page 18: Installation

    Installation Language Menu 1. When you turn on the TV set for the first time, the Language menu appears as the on-screen display. If not, (1) Press the MENU button to call up the menu. (2) Move the selection bar to the Feature menu with ▼PR▲buttons.

  • Page 19: Channel Edit

    Channel Edit Select the Channel Edit menu from the Install menu. Moving the programme 1. Select the programme to move with the ▼PR▲ buttons. 2. Press GREEN button and the selected programme is highlited. 3. Using the ▼PR▲ buttons, select programme you want to change.

  • Page 20: Manual Tune

    Installation Manual Tune 1. Press the ▼PR▲ buttons to select a programme number you want. 2. Select the Manual from the Install menu. 3. Press the VOL► button and the manual tuning window appears. 4. Press the ◄VOL► buttons to search up or down.

  • Page 21: Basic Operation

    SWITCHING ON 1. If the Indicator is not lit, then the TV set is powered off. You must press the On/OFF button on the TV set. The set will switch to stand-by mode and then the Indicator will illuminate in Red. 2.

  • Page 22: Programme Selection

    Basic Operation The set has 99 programme numbers, PR01..PR99. The Number buttons are used for direct programme selection. To select a two-digit programme, press the second numbered button within 2 seconds. (EX. When you want to select PR10, you should press down “1” and “0” within 2second. If you only press down “1”...

  • Page 23: Menu Opreration

    Picture Control 1. Press the MENU button to call up the menu. 2. Move the selection bar to the Picture menu with the ▼PR▲ buttons. 3. Press the VOL► button. 4. Select the item to adjust with the ▼PR▲ buttons. 5.

  • Page 24: Screen

    Menu Operation Screen Control Aspect Ratio Control 1. Press the MENU button to call up the menu. 2. Move the selection bar to the Screen menu with the ▼PR▲ buttons. 3. Press the VOL► button. 4. Select the Mode menu with ▼PR▲ buttons. 5.

  • Page 25: Auto Adjust

    1. Select the PC from the Screen menu. 2. Press the VOL► button and the PC mode appears. H Size 1. Move to H Size by pressing the ▼PR▲ buttons. 2. Press the ◄VOL► buttons to adjust the horizontal size of displayed image. V Size 1.
  • Page 26 Menu Operation PC/DVi Mode input format If the signal from the PC system equals one of the standard signal modes, the screen will automatically adjust and display image. If the signal from the PC system doesn’t equal any of the modes, adjust the Video card setting on the computer.
  • Page 27 PIP/POP 1. Select the PIP/POP from the Screen menu. 2. Press the VOL► button and the PIP/POP mode appears. Mode 1. Use the ◄VOL► buttons to select either on or off. Sub Input 1. Select the Sub Input menu with ▼PR▲ button.
  • Page 28 Menu Operation PIP : Along with the main window program, you can have another small sub window simultaneously. POP : Main window moves to the left side of the screen and sub window appears on the right side at the same time.( When main mode is PC & DVI , this function cannot operates.) Sub/Main Video1 ×...
  • Page 29 Colour Temp 1. Move to the Colour Temp menu with ▼PR▲ buttons. 2. Using the ◄VOL► buttons, Select the desired Colour Temperature. Note : Through Colour Temperature Control you can change the tone of colour. Normal: Normal white Warm: Reddish white Cool: Bluish white Note: Colour Temp are operated only in PC/DVI mode.

  • Page 30: Sound

    Menu Operation Sound Mode 1. Press the MENU button to call up the menu. 2. Move the selection bar to the Sound menu with ▼PR▲ buttons 3. Press the VOL► button. 4. Select the Mode menu with ▼PR▲ buttons. 5. Using the ◄VOL► buttons, Select the desired sound mode.
  • Page 31 1. Move to the MPX menu with ▼PR▲ buttons. 2. Press the ◄VOL► buttons to select one of the Stereo, Mono, Dual 1, Daul 2. Note: MPX only works in RF mode. Spatial 1. Move to the Spatial menu with ▼PR▲ buttons.

  • Page 32: Feature

    1. Move to the MGDi menu with ▼PR▲ buttons. 2. Press the ◄VOL► buttons to select among on, off and Demo. DAEWOO’s new technology , MGDI , brings viewers more detailed, clearer and more natural im- age with picture compensation algorithm.

  • Page 33: Time Setting

    Time Setting 1. Select the Time Setting from the Feature menu. 2. Press the VOL► button and the Time Setting mode appears. Setup the Clock, Wake up Time and Off Time. 1. Start to set up by pressing the VOL► button. 2.

  • Page 34: Teletext (Option)

    Menu Operation Teletext SWITCHING TELETEXT ON/OFF Press the TELETEXT button ( ). The index page or the page viewed last will appear. Press the TELETEXT button again to return to the TV mode. NOTE: Teletext works only in TV/AV mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue field is shown at the bottom of the screen.
  • Page 35 Menu Operation CALLING UP SUBPAGE DIRECTLY Pressing the SUBPAGE button ( ) , “ - - - - ” appears. Enter the subpage number that you want to call up with the NUMBER button, for example, the 2nd page, sequence 0002. The desired subpage will eventually be displayed on the screen and holds it there.

  • Page 36: Trouble Shooting

    Trouble Shooting Please check the following items before asking for repair service. Symptom Neither picture nor sound Picture is OK but no sound Sound is OK, but no color. The picture is overlapped image. Picture has “snow noise” . Stripes on picture.
  • Page 37 IN PC/DVI MODE Symptom “OUT OF RANGE” appears on the OUT OF RANGE screen “NO SIGNAL” appears on the NO SIGNAL screen. Image is not clear. Image is not centered. • AFTER SALES SERVICE Do not hesitate to contact your retailer or service agent if a change in the perfomance of your product indicates that a faulty condition may be present.

  • Page 38: Product Specifications

    Max. Power Source Dimension Set Dimension (W x H x D) (Contain Stand) ★ Owing to our policy of continuous improvement, specifications may change. Specifications DLP-2612 26” 32” 16:9 16:9 1366 x 768 (WXGA) 1366 x 768 (WXGA) 0.4215 mm 0.51075 mm...
