QUICK REFERENCE
Turn on the platform:
• Position patient's armpits
at platform's yellow line.
• Close band and press firmly
to attach.
• Press Start.
1
Power button: Green = on
2
Mute: Illuminates green when Mute is activated.
Press the Mute button to silence the platform.
Alerts will resume:
• 30 seconds after pressing the Mute button.
• When Mute button is pressed again.
3
Compression mode: Green = continuous mode; otherwise
30:2 mode is active. Press to change compression mode.
Battery indicator: Indicates battery charge status.
4
One bar will flash when 10% or less of charge remain.
5
Start: Press to start compressions
4
1
2
3
7
8
5
6
9
Advertisement
Related Manuals for ZOLL AutoPulse NXT
Summary of Contents for ZOLL AutoPulse NXT
- Page 1 QUICK REFERENCE Turn on the platform: • Position patient’s armpits at platform’s yellow line. • Close band and press firmly to attach. • Press Start. Power button: Green = on Mute: Illuminates green when Mute is activated. Press the Mute button to silence the platform. Alerts will resume: •...
- Page 2 Stop: Press once to stop compressions. Note: Platform will power off after 15 minutes of inactivity. Stop button can be pressed to reset inactivity timer. USB indicator only: Flashes green when data is transferring to a thumb drive. Alert Indicator: a.
