Cross Technologies 2016-1351 Instruction Manual

Downconverter
Hide thumbs

Advertisement

Table of Contents

Instruction Manual
ALARM
REMOTE
POWER
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be
reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating
the equipment.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number,
equipment serial number, and a description of the part.
F=512
G=+0.0
MENU
EXECUTE
C
T
ROSS
ECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
Phone (770) 886-8005
FAX (770) 886-7964
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL info@crosstechnologies.com
Model 2016-1351
Downconverter
SEPTEMBER 2024, Rev. C
MODEL 2016
DOWNCONVERTER
C
ROSS
T
ECHNOLOGIES INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2016-1351 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cross Technologies 2016-1351

Summary of Contents for Cross Technologies 2016-1351

  • Page 1 ALARM REMOTE POWER Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating the equipment. When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number, equipment serial number, and a description of the part.

  • Page 2: Table Of Contents

    All Cross Technologies, Inc. products are warranted against defective materials and workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall not be liable for any special, indirect, or consequential damages.

  • Page 3: General

    1.0 General 1.1 Equipment Description The 2016-1351 Downconverter converts 130 to 512 MHz to 70 ± 10 MHz in 1 MHz steps with low group delay and flat frequency response. Synthesized local oscillators (LO) provide frequency selection. Multi-function push button switches select the input frequency, gain, and other parameters. Front panel LEDs provide indication of DC power, PLL alarm or Remote operation.
  • Page 4 1.2 Technical Characteristics TABLE 1.0 2016-1351 Downconverter Specifications* Input Characteristics (RF) Impedance/Return Loss 50Ω /12 dB Frequency 130 to 512 MHz Noise Figure, max. 15 dB (max gain) Input Level Range -30 to -20 dBm Input 1dB compression -10 dBm...
  • Page 5 A) Remote serial interface Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit. (RS-232C, RS-422, or RS-485 - option -Q) M&C Cable Diagram - Cross Technologies Frequency Converters Male DB-9 Female DB-9 2015/16/17 M&C Port...
  • Page 6 B) Status Requests Table 1.1 lists the status requests for the 2016-1351 and briefly describes them. PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below, should be used ONLY when RS-485, (OPTION-Q), is selected. TABLE 1.1 2016-1351 Status Requests TABLE 1.1 2016-1351 Status Requests...
  • Page 7 C) Commands Table 1.2 lists the commands for the 2016-1351 and briefly describes them. After a command is sent the 2016-1351 sends a return “>” indicating the command has been received and executed. General Command Format - The general command format is {aaCND...}, where:...

  • Page 8: Installation

    16 inch deep) chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assemblies. The 2016-1351 can be secured to a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2016-1351 is assembled.
  • Page 9 RF IN, J2, center pin. 3 ± 3 dBm, 75Ω, BNC female connector. 3 ± 3 dBm, 75Ω, BNC female connector. FIGURE 2.1 2016-1351 Rear Panel I/Oʼs TABLE 2.1 J10 Pinouts (RS-232C/422/485*) TABLE 2.1 J10 Pinouts (RS-232C/422/485*) Function...
  • Page 10 Menu items when in controls which values are being program mode. Does not function in adjusted. Does not function in the the normal display mode normal display mode FIGURE 2.2 2016-1351 Front Panel Controls and Indicators 2016-1351 Manual, Rev C Page 10 09/11/24...

  • Page 11: Operation

    2.4 Installation / Operation 2.4.1 Installing and Operating the 2016-1351, Downconverter Section 1. Connect a -30 to -20 dBm signal to IF In, J4 (Figure 2.1). 2. Connect the RF OUT, J5, to the external equipment. 3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC1 on the back panel.

  • Page 12: Menu Settings

    If programming is initiated and no operator action takes place for approximately 12 seconds (before the final press of the Menu/Execute switch) the display will revert to its previous status and you will need to start over. 2016-1351 Manual, Rev C Page 12 09/11/24...
  • Page 13 For other functions such Mute on/off, the vertical switch will alternately turn the function on or off regardless of the direction operated. b. During frequency, gain changes, the vertical movement will raise or lower the number in the direction of the arrows. 2016-1351 Manual, Rev C Page 13 09/11/24...
  • Page 14 Selecting Y will save the new settings. Selecting N will revert to the previous settings. Pushing the Menu/Execute switch then takes you to the : F=512 G=+0.0 Figure 2.4 gives the menu items and how to make changes. 2016-1351 Manual, Rev C Page 14 09/11/24...
  • Page 15 Selecting Y will save the new settings. Selecting N will revert to the previous settings. Pushing the Menu/Execute switch then takes you to the: F=512 G=+0.0 Figure 2.4 gives the menu items and how to make changes. 2016-1351 Manual, Rev C Page 15 09/11/24...
  • Page 16 Menu 7 Set RS-485 Address ADDRESS = 00 SCROLL <> (option -Q) SCROLL PUSH BUTTON Save? When go to end SCROLL <> SAVE SETTINGS? SCROLL PUSH BUTTON FIGURE 2.4 Menu Display and Sequences 2016-1351 Manual, Rev C Page 16 09/11/24...

  • Page 17: Environmental Use Information

    G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed. If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS emission problems. 2016-1351 Manual, Rev C Page 17 09/11/24...
  • Page 18 ROSS ECHNOLOGIES, INC. 6170 Shiloh Road Alpharetta, Georgia 30005 Phone (770) 886-8005 FAX (770) 886-7964 Toll Free 888-900-5588 WEB www.crosstechnologies.com E-MAIL info@crosstechnologies.com Printed in USA 2016-1351 Manual, Rev C Page 18 09/11/24...
