Invacare matrx SEATING Series Installation Instructions Manual

Fixed Lateral Support Installation Instructions:
Instructions for Installing Fixed Lateral Supports (
1 Pull up the bottom of the cover (release velcro fasteners) to expose the mounting slots/channels in the back pan.
2 Determine the desired mounting height/orientation for the lateral pads (upper or lower mounting slot position).
3 If applicable, carefully bend the lateral support(s) to the desired contour (prior to installation).
4 Loosely install the lateral supports onto the back pan using the hardware provided. (Note: the backing plate is installed
from the inside of the back pan through the lateral support brackets and secured to the back pan via the washer
plates and locking nuts - refer to images below).
5 Adjust laterals to the desired position via the mounting slots on the backpan and via the slots in the lateral support
bracket. Secure each lateral support into place.
6 Re-attach the back cover via the velcro fasteners.
Upper
Mounting
Slots
REAR VIEW
1 Note: lower mounting slots not available on 12" (31
Standard
Lateral
(large)
vertical ad-
justmenty
3" (76
horizontal adjustment
3" (76 )
mm
) high MaTRx-PB elite backs
cm
Standard
Lateral
(small)
)
mm
FRONT VIEW
- 1 -
Standard and
Standard
Lower
Mounting
Slots 1
Inverted
Position
*note: offset laterals may also be mounted in the inverted
position (as shown) to provide extended support
Matrx Elite
EN
Offset):
Offset
Lateral Support
Bracket
FRONT VIEW
Offset
Lateral*
TRD0193 Rev A
