SportsPlay Equipment 561-506 Quick Start Manual

561-506 Official Aluminum Soccer Goal (Permanent - Pair)
PLEASE RETAIN THIS INSTRUCTION SHEET IN YOUR FILES.
PARTS INFORMATION.
INSTRUCTIONS.
IT IS IMPORTANT TO USE AND MAINTAIN ALL PUBLIC PLAYGROUND EQUIPMENT PROPERLY.
EQUIPMENT, WHICH IS IMPROPERLY MAINTAINED, CAN CAUSE SERIOUS INJURY.
INSPECTIONS, MAINTENANCE, REPAIR AND/OR REPLACEMENT OF DAMAGED PARTS IS NECESSARY FOR
SAFE OPERATION OF EQUIPMENT AND SAFETY OF USERS.
UNDER ALL PLAYGROUND EQUIPMENT.
THE CONSUMER PRODUCT SAFETY COMMISSION, INCLUDE "A HANDBOOK FOR PUBLIC PLAYGROUND
SAFETY." YOU CAN RECEIVE YOUR FREE COPY BY CALLING 1-301-504-7908.
PACKING LIST
1 CTN
1 CTN 2 503-509L
2 503-509R
8 503-510
1 POST 2 503-506
1 POST 4 803-511
1 POST 4 563-602
*Left and Right are designated from behind the goal looking out, NOT looking in.
SportsPlay Equipment, Inc
* IMPORTANT *
ALL EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THESE
APPROPRIATE PUBLICATIONS, AVAILABLE AT NO CHARGE, FROM
Hardware Bag
Left Upper Corner*
Right Upper Corner*
Inner Sleeve
Top Rail
Upright
Net Support – soccer
1 SKID 2' x 26' 416 Cu. Ft.
., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
www.sportsplayinc.com
IT CONTAINS IMPORTANT REPLACEMENT
RESILIENT SURFACING SHOULD BE USED
HARDWARE BAG
16 116-601 ½" x 2 ¾" Button Head Bolt
8 116-625 3/8" x 1 ½" Hex Tap Bolt
8 316-601 3/8" Flat Washer
16 316-801 ½" Flat Washer
1 416-500 5/16" Socket Key
72 905-523 ½" Plastic Clamp
72 905-524 Self Tapping Screw
1 905-525 ¼" Magnetic Nut Driver
WT 546# CLASS 70
1 of 2
Page
Rev 09/15/2005
